FH-443 XR Front Hitch
Owner's Manual & Parts Book
Grouser Products
755 2nd Ave NW - West Fargo, ND 58078
Phone: 1-701-282-7710
Fax: 1-701-282-8131
E-mail: grouser@grouser.com
Website: www.grouser.com
PN: 43897
Serial Number: 10207474-Current
Purchase Date
Serial Number
Model Number
Tractor Model
Dealer
Date 4-6-2023
Advertisement
Related Manuals for Grouser Products FH-443 XR Front Hitch
Summary of Contents for Grouser Products FH-443 XR Front Hitch
- Page 1 FH-443 XR Front Hitch Owner’s Manual & Parts Book Purchase Date Grouser Products Serial Number 755 2nd Ave NW - West Fargo, ND 58078 Model Number Phone: 1-701-282-7710 Fax: 1-701-282-8131 Tractor Model E-mail: grouser@grouser.com Dealer Website: www.grouser.com PN: 43897 Serial Number: 10207474-Current...
- Page 2 Thank you for your recent purchase of a Grouser FH-443 Front Hitch. Welcome to the family of satisfied Grouser Front Hitch owners. Grouser Products is committed to offering quality products to help professionals in their daily jobs. We are also committed to providing you the highest level of customer satisfaction possible. Again, thank you for your patronage.
- Page 3 4. Make sure the area is clear of people before moving any equipment. 5. Do not modify or permit anyone else to modify or alter the equipment and its components without first consulting Grouser Products. 6. Lower the blade to the ground when not in use.
- Page 4 WARNING: This product can expose you to chemicals including lead and lead compounds, mineral oils, and phthalates which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov 27-40962R1 PN: 27-40962...
- Page 5 Due to the harsh environment this equipment operates in, the following tasks should be performed every 10 hours or less . • Inspect all equipment before operation for existing or potential damage. • Lubricate all joints with high quality grease. See below for grease locations. •...
- Page 6 DETAIL A...
- Page 7 ITEM Qty. PART NO. Item Qty. Part No. DESCRIPTION Description 11-19000 FH-440 Lower Arm 11-42535 XR Lower Arm 11-42540 XR Top Arm 11-19010 FH-440 Top Arm 16-20035 5/16" X 1-1/4" Hex Bolt Gr 5 NC CZ 16-20035 5/16” x 1-1/4“ Hex Bolt Gr 5 NC 16-20125 1/2"...
- Page 8 See Detail A Below 1 or 2 View Detail B Undercarriage May Vary DETAIL A Cylinder View From Right Side...
- Page 9 ITEM HAHT & LIFT HANT & LIFT NANT & LIFT NO. PART NO. DESCRIPTION Qty. QTY. QTY. 16-20046 5/16" X 4" Hex Bolt Gr 5 NC CZ 16-20040 5/16" X 2-1/2" Hex Bolt Gr 5 NC CZ 16-35C612 3/8" x 3/4" Flange Bolt 18-19311-03-P-087 Hose Clamp 18-19312-03...
- Page 10 42720-A ITEM NO. Qty. PART NO. DESCRIPTION 16-20218 3/4" x 2" Hex Bolt Gr.5 NC 18-42720 Bracket, Quick Hook 43-42599 57-20747 3/4" Flat Washer 70-20607 3/4" Center Lock Hex Nut Gr 2 NC Note: After top link is adjusted, torque bolts to 260 ft-lbs. 42710-A ITEM NO.
- Page 11 Tilt Cylinder Angle Cylinder Left Angle Cylinder Right Green Spiral Band Green Spiral Band Red Spiral Band Red Spiral Band & Green Cap & Green Cap & Red Cap & Red Cap Tilt Disconnects Angle Disconnects Green Spiral Band Red Spiral Band Green Spiral Band Red Spiral Band &...
-
Page 12: Warranty
Warranty Grouser Products warrants to the original purchaser of each item that the product be free from defects in material and workmanship under normal use and service for a period of two (2) years for Agriculture Series Blades and one (1) year for Heavy Duty Series from date of original retail delivery.
