NTE026
Bathtub
Please install the product properly ,in accordance with the descriptions in this manual
so that full use can be made of the product's functions.
After installing the product,please tell the customer how to use the product fully.
Thank you for choosing to use the TOTO BATHTUB on this occasion.
Please install the product properly, in accordance with the descriptions in this manual so that
full use can be made of the product's functions.
After completing the construction, please explain the operation to the customer and give this
Installation Manual and the accompanying "Instruction Manual" to the customer.
Note also: Please be sure to fill in the required items in the warranty.
Please be aware that the parts numbers listed in the Installation Manual may be revised.
2013.12
Installation Manual
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Toto PJY1804HPWE
Summary of Contents for Toto PJY1804HPWE
- Page 1 After installing the product,please tell the customer how to use the product fully. Thank you for choosing to use the TOTO BATHTUB on this occasion. Please install the product properly, in accordance with the descriptions in this manual so that full use can be made of the product's functions.
- Page 2 1.Important Safety Instructions. Read and follow all instructions.Save this instruction with your instruction manual. INSTALL TO PERMIT ACCESS FOR SERVICING.INSTALL THIS NUIT IN ACCORDANCE WITH THE NATIONAL ELECTRICAL CODE (NEC) NFPA 70 AND CANADIAN ELECTICAL CODE PART 1. Please read these”Important safety instructions”carefully before begining the installation work and install the product correctly. This installation Manual has a number of different symbols intended to allow proper ang safe installation of the product,to prevent harm to the end user,to prevent damage to property and to prevent harm to construction workers.these symbols have the following significance.
- Page 3 2.Construction On The Installation Point Of Attention. Warning Install the product securely,in accordance with the Installation Manual. Improper installation can cause leaks that damage or ruin household property. Install the drainage pipes securely,in accordance with the procedure. Always do this Improper installation could lead to leaks that damage or ruin household property.
- Page 4 3.Parts list Name Quantity Type Remark Bathtub NTE026 Installation manual Operation Installation NTE141 It is used during Ribbon transportation of bathtub. Drainage fittings： Special pedal type drainage fittings Material: FRP, artificial marble etc. Color: Standard bathtub is matt white color. Up to or over light industry standard of People’s Republic of China (JC/T 779-2010) Standard (QB)：...
- Page 5 4.Installation procedure 4-2.Installation of drain tube Drain end of drainage fittings is inserted into ground drain tube for closely connection. If drain end is too short, connection pipe can be used for insertion. ● For direct draining occasions, thread pipe is connected. ①.Connecting PVC pipe ②.Connecting thread pipe glue-water...
- Page 6 2. Adjust leveling of bathtub with adjustable wrench. The adjusting method for supporting foot: Screw off the nut A; ①. Screw off Fasten ut A .Adjust the nut B to the required position. ② ut B Screw off Fasten .Fasten the nut A. ③...
