FLOTATION TUB

WITH RECLINE COMFORT

● Cautions and warnings

● Included parts

● Required tools

●

Please explain the FLOTATION TUB functions and

operation to the customers.

Please install according to all local and applicable

codes.

To service installers

INSTALLATION GUIDE

● Dimension drawings

● Installation procedures

● Installing the bathtub

● Finishing

8,9

10,16

15,20

Need help?

Do you have a question about the PJY1724PW and is the answer not in the manual?

Questions and answers

Summary of Contents for Toto PJY1724PW

Page 1: Table Of Contents
INSTALLATION GUIDE FLOTATION TUB WITH RECLINE COMFORT <INSTALLATION INSTRUCTIONS> ● Cautions and warnings ● Dimension drawings ● Included parts ● Installation procedures ● Required tools ● Installing the bathtub 10,16 ● ● Finishing 15,20 To service installers Please explain the FLOTATION TUB functions and operation to the customers.
Page 2: Cautions And Warnings
Cautions and warnings When this appears next to a topic, this indicates that misoperation could result in death WARNING or serious injury. When this appears next to a topic, this indicates that misoperation may result in injury CAUTION or physical damage. ●...
Page 3 WARNING Make sure to install the bathtub according to the installation guide and in a stable location. ● Ensure that you have an ergonomic working position during transport and assembly. ● Take care at every stage that your move is safe. Ensure that you have assistance to avoid risk of accident Always observe or injury.
Page 4: Included Parts
Included parts : Bathtub : Polyethylene foamed sheet : Instruction manual : Installation guide : Socket : Sleeve (Only PJY1724PW)
Page 5: Required Tools
Required tools PVC adhesive PVC primer Silicone Soft cloth that will not damage the bathtub Water detection sheet B-10 Made by OS&B Ltd: ITD35/ITD5135 Island Tub Drain(shown) Made by CG Air: CG-DID Drop-in Drain (Only PJY1724PW)
Page 6 Item Specifications PJY1724PW PPY1780PT 66-15/16″(L) × 31-1/2″(W) × 22-1/4″(H) 66-15/16″(L) × 29-1/2″(W) × 22-1/16″(H) External dimensions (1700 mm (L) × 800 mm (W) × 565 mm (H)) (1700 mm (L) × 750 mm (W) × 560 mm (H)) Bathtub depth 17-11/16″...
Page 7: Dimension Drawings
Dimension drawings PJY1724PW PPY1780PT...
Page 8: Installation Procedures
Installation procedures for PJY1724PW >>P.7 >>P.10 >>P.10 >>P.11 >>P.11 >>P.12...
Page 9 Installation procedures for PPY1780PT >>P.7 >>P.16 >>P.18 >>P.18 >>P.19 3/16” (5mm) 13/16” (20mm)
Page 10: Installing The Bathtub
Installing the bathtub for PJY1724PW B-20 B-10...
Page 11 B-10...
Page 12 Conduct a fill water...
Page 13 B-2 M12 3/16”(5 mm) 3/16”(5 mm) Fix the bathtub B - 4...
Page 14 CAUTION Fix the bathtub in place with mortar using the provided sleeves (A-6). Required...
Page 15: Finishing
Finishing WARNING that does not contain alcohol.
Page 16 Installing the bathtub for PPY1780PT Preparation prior to the installation of bathtub 1.To confirm the drainage hole position. ①、Ensure the floor is level for placing bathtub. If the floor is not level, pedestals can be built for placing bathtub. Location depends on the position of bathtub feet and height depends on the drainage fittings used.
Page 17 Installing of drain tube ● For direct draining occasions. 1 .Connecting PVC pipe 2 .Connecting thread pipe G1 1/2 rubber gasket teflon tape 　 ● For side draining occasions. 1. Connecting PVC pipe 2. Connecting thread pipe G1 1/2 teflon tape pipe tilt 1/50 or more rubber gasket PVC adhesive and PVC primer must be used for sticking, fixing and sealing the connected...
Page 19 Secure the bathtub 1. Install the adjustable height foot. ① Loosen nut A. ② Install the foot to the bathtub at C (shown below). Nut A Fastening nut Loosening nut Adjustable height bottom foot Note: 1. After nut A is loosened, the distance between nut B and nut A is about 2-3/4” (70mm). 2.
Page 20 Building of ceramic tile Drop-in Installation ● a. Bathtub without skirt: Build a low wall with brick. Build ceramic tile on the outer side of the low wall with mortar (a clearance of at least 3/16”(5mm) is kept between the upper edge surface and bathtub side). Buffer material is used to fill this clearance (such as soft polythene or equiva lent material).
Page 21 MEMO...
Page 22 MEMO...
Page 23 MEMO...
