FLOTATION TUB
PJYD2200PWEE
Please explain the FLOTATION TUB functions and operation to the customers.
Keep the power turned off when there is time until handing over the product in a new home.
To service installers
Installation Guide
2
5
6
7
8
9
10
11
11
12
15
16
Advertisement
Table of Contents
Related Manuals for Toto PJYD2200PWEE
Summary of Contents for Toto PJYD2200PWEE
-
Page 1: Table Of Contents
Installation Guide FLOTATION TUB PJYD2200PWEE ● Cautions and warnings ● Included parts ● Required tools ● Specifications ● Dimension drawings ● Electrical construction ● Installation procedures ● Meaning of the indications ● Building a base for the bathtub ● Installing the bathtub ●... -
Page 2: Cautions And Warnings
Cautions and warnings Please read the installation manual and follow these cautions and warnings carefully before beginning the construction. Follow all safety precautions and warnings. When this appears next to a topic, this indicates that misoperation WARNING could result in death or serious injury. When this appears next to a topic, this indicates that misoperation CAUTION may result in injury or physical damage. - Page 3 WARNING Protect the product with a wiring circuit breaker (I⊿n 0.03A and 25A differential switch, 20A magnetic thermal switch) and ground fault circuit interrupter (GFCI). Install both switches outside of the bathroom. Attach the tap water supply equipment to the bathtub. Make sure to connect the ground wire (ground).
- Page 4 CAUTION Do not place a stepladder inside the bathtub or place heavy objects on the edge the bathtub. ● This may cause damage. Do not drop or bump anything hard or heavy onto the bathtub. ● This may cause the bathtub to crack and result in an injury, or leakage that could wet and cause damage to household property.
-
Page 5: Included Parts
Included parts : Bathtub : Polyethylene foamed sheet : Instruction manual : Installation guide : Cleaning spatula for NECK BATH : Bathtub fixing plate set : Drain trap (PP) : Flathead screwdriver (small) *Hand over A-3, 5 to the customer after the construction is completed. -
Page 6: Required Tools
Required tools φ8.5 mm B-11 H05VVF 3 x 1.5 mm φ8~9 mm B-12 B-13 B-14 PVC adhesive PVC primer Silicone B-15 B-16 Water detection sheet B-19 B-17 B-18 Soft cloth that will not damage the bathtub... -
Page 7: Specifications
Specifications Item Specifications External dimensions 2200 mm (L) × 1050 mm (W) × 780 mm (H) Bathtub depth 394 mm Capacity 293 L Weight 170 kg GALALINE Materials (GALALINE is an artificial marble made of GFRP sandwich structure.) Normal drainage (partial electrical valve automatic drainage) Drainage method + Overflow drainage Drain plug... -
Page 8: Dimension Drawings
Dimension drawings [In case of attaching an option (floor standing bathtub filler)] For an optional water faucet, ask the dealer,contractor from whom you purchased the product,or TOTO. -
Page 9: Electrical Construction
Electrical construction B-11 25A I∆n 0.03A H05VVF 220-240V 50Hz 850W B-11 L=700~800 mm Waterproof H=100~120 mm Tile Turn the wiring circuit breaker off during operation. Protect the product with a wiring circuit breaker (I⊿n 0.03A and 25A differential switch, 20A magnetic thermal switch) and ground fault circuit interrupter (GFCI). Install both switches outside of the bathroom. -
Page 10: Installation Procedures
Installation procedures >>P.11 >>P.12 >>P.12 >>P.14 >>P.15 ② ① >>P.16... -
Page 11: Meaning Of The Indications
Meaning of the indications This operation must be conducted by a contractor. Operation that must be checked. Indicates the work flow. Building a base for the bathtub B-11 L=700~800 mm Waterproof H=100~120 mm Tile Please conduct site operation directly on the drain. When embedding a power cable for the bathtub on the installation side, please use a sheath tube with an inner diameter of 20 mm or more. -
Page 12: Installing The Bathtub
Installing the bathtub B-14 Lift up Lift up Other Choices B-17 B-18 Cardboard box, etc., for packaging the bathtub... - Page 13 Power supply B-11 Brown Blue Green/ Yellow IPX5 B-4 M12...
- Page 14 B-12 A(40mm) A(40mm) B-15 B-4 M10 WARNING Check to see that the hole positions are not overlapping with the cavity portions of the tile base. ● If there are cavities, use an adhesive anchor to stabilise.
-
Page 15: Conduct A Trial Run
Conduct a trial run Check to see that there is no water leakage when the B-16 product is operating or stopped. Conduct a trial run for 10 minutes. If trouble occurs during the trial run Symptoms Processing The controller does not light Is power being supplied? up, or operate any functions. -
Page 16: Finishing
WARNING Stabilise the bathtub with a fixing plate. ● The bathtub may shake if it is not properly stabilised. Finishing B-13 WARNING Secure enough space between the bathtub and tiles, and fill that space with silicone that does not contain alcohol. - Page 17 MEMO...
- Page 18 MEMO...
- Page 19 MEMO...
- Page 20 2018. 1 Printed in China ©TOTO Ltd. All rights reserved. NTE185...
