Mongoose MAP77 Installation Manual page 8

A
SCHEMATIC
EN
V. 001/2016
Schematic does not apply to:
- Fiat vehicles with coded pulse via dedicated wire, level 14, 53, 69
- Renault vehicles with single wire bus, level 87
- BMW vehicles with K-bus, level 84 and 85
*1
If STATUS 1 or STATUS 2 wire are drawn on car part of schematic,
brown wire of MAP77 cannot be used as „PAGER output" or
„2nd IMMOBILISER output".
*2
Use diodes only if both STATUS 1 and STATUS 2 wires are drawn on
car part of schematic.
*3
If STATUS 3 wire is drawn on car part of schematic, connect it to
orange wire of MAP77. In such case the orange wire cannot be
connected to ignition signal.
*4
RF module white wires are internally connected to (+) power supply of
MAP77.
