Mongoose SG-1100 Instruction Manual

MONGOOSE
Wireless Burglar
Alarm
System
Model SG-1100
Included parts;
1 x SolarGuard Console – SG01
2 x Remote Controls – RM03
1 x PIR Detector _ IR02
1 x Magnetic Detector – MT01
1 x Lead Acid Battery for Console
2 x 9v Alkaline Batteries for detectors
2 x 12v23a Batteries for remote Controls
1 x Console Mounting Template
This manual
Instruction Manual
Please read this manual prior to installation
INTRODUCTION
CONGRATULATIONS
in selecting the SolarGuard Wireless Burglar Alarm
System. The SolarGuard console and wireless detectors provide an extremely easy
installation and are amazingly simple to operate.
The SolarGuard is solar powered with power maintained by an internal sealed
Lead-acid rechargeable battery. The battery has life of approximately 3 years.
The standby current is incredibly small thus allowing the solar panel to maintain the
battery charge. In fact, the solar panel is so sensitive it will even top up the battery in
very cloudy and overcast weather conditions, and even without top-up the system will
operate without light for up to 10 days.
The SolarGuard is fully protected by a tough Polycarbonate UV proof housing. All
electronic components are protected with moisture repellent materials applied during
manufacturing process to ensure long, reliable, trouble free operation. Two integral front
and rear tamper switches give maximum security to the unit. When activated, the
SolarGuard sounds a built-in twin siren system at a powerful 115dBs and strobe will
flash. The siren duration is selectable from between 1 and 8 minutes. If it's allowed to
sound for the full siren duration the strobe will latch and continue for approximately 20
minutes or until the system is disarmed.
The SolarGuard can be set into any one of its active modes which includes Full Arm,
Disarm and Battery Change to allow for replacement of detector batteries without
triggering the tamper switches. The SolarGuard will provide audible chirps when
operated via the Remote Control but the option is included to select an silent LED light
indication instead which flashes behind the strobe lens of the SolarGuard and is fitted
as standard.
Individual zone setting in each detector allows you to customize the installation with
Entry/Exit, Instant and 24H Zone selections. The Instant zone also provides an
Entry/Exit walk-through facility of 20 seconds, automatically allowing instant zone
"entry pass through". This is particularly useful if you have to pass through an Instant
zone to locate and operate the Remote Control when entering the property.
Please read this manual carefully to fully understand installation, setting up and
operation.
Mongoose (New Zealand) Limited
41A View Road, Glenfield, Auckland
Ph: (09) 443 3128
Fax: (09) 443 3129
Email: sales@mongoose.co.nz
Website: www.mongoose.co.nz
