- Page 1 OPERATOR'S MANUAL QC605 / B, QC620 Skid Steer Mounted Backhoe Rev Feb-2019 Part Number: Z97125...
-
Page 2: Foreword
QC605B and QC620. Models can vary from the illustrations shown depending on options. The QC605 and QC620 backhoes are shipped from the factory in a basic, universal configuration that allows them to be mounted to any skid steer model. -
Page 3: Table Of Contents
8.3 Bucket Tooth Replacement ........32 2.11 Sign-Off Form...........15 8.4 Bucket Removal ..........32 3. Safety Signs ............16 8.5 Maintenance Schedule ........33 3.1 Model QC605 & QC605B ........16 9. Trouble Shooting ..........33 3.2 Model QC620 .............18 3.3 Replace Damaged Safety Signs ......20 10. Specifications ............34 3.4 How to Install Safety Signs ........20... -
Page 4: Delivery Inspection Report
QC605 / B, QC620 Foreword Skid Steer Mounted Backhoe 1.2 Delivery Inspection Report WALLENSTEIN QC600–Series Skid Steer Mounted backhoe To activate warranty, register your product online at: http://www.wallensteinequipment.com This form must be filled out by the dealer and signed by both the dealer and the customer at the time of delivery. -
Page 5: Serial Number Location
Skid Steer Mounted Backhoe 1.3 Serial Number Location Always give your dealer the serial number of your Wallenstein product when ordering parts or requesting service or other information. Please record the product Model and Serial Number in the space provided below for future reference. -
Page 6: Warranty
Skid Steer Mounted Backhoe 1.4 Warranty LIMITED WARRANTY Wallenstein products are warranted to be free of defects in materials and workmanship under normal use and service, for a period of Five Years for Consumer Use Two Years for Commercial/Rental Use from the date of purchase, when operated and maintained in accordance with the operating and maintenance instructions supplied with the unit. -
Page 7: Decal Information
(message). messages such as model, serial number, and manufacturer. Safety alert Manufactured by: warning Wallenstein Equipment Inc., 7201 Line 86, Wallestein ON N0B2S0, Canada MODEL: ########## TYPE OF VEHICLE/TYPE DE VEHICLE: TRA / REM GAWR/PNBE (KG): GVWR/PNBV (KG): How the... -
Page 9: Safety
ATTENTION! BE ALERT! YOUR SAFETY IS INVOLVED! The Safety Alert Symbol identifies important safety messages on Wallenstein equipment and in the manual. When you see this symbol, be alert to the possibility of personal injury or death. Follow the instructions in the safety message. -
Page 10: Why Is Safety Important
YOU are responsible for the SAFE operation and know how to use it. maintenance of your Wallenstein Skid Steer Mounted backhoe Attachment. YOU must ensure that you and anyone else who is going to use, maintain or work •... -
Page 11: Safety Training
QC605 / B, QC620 Safety Skid Steer Mounted Backhoe 2.5 Safety Training 6. Before servicing, repairing or maintaining the machine, perform the Safe Condition procedure. 1. Safety is a primary concern in the design See Safe Condition on page 12. -
Page 12: Equipment Safety Guidelines
QC605 / B, QC620 Safety Skid Steer Mounted Backhoe 2.7 Equipment Safety Guidelines If this machine is used by anyone other than a trained operator, or is loaned or rented, it is the machine The safety of the operator and bystanders is one of the owner's responsibility to make certain that prior to main concerns in designing and developing equipment. -
Page 13: Hydraulic System Safety
QC605 / B, QC620 Safety Skid Steer Mounted Backhoe 12. Always use proper tools that are in good condition. Make sure the procedure is understood before performing any service work. 2.9 Hydraulic System Safety 1. Make sure that all the components in the hydraulic system are kept clean and in good condition. -
Page 14: Preparation
QC605 / B, QC620 Safety Skid Steer Mounted Backhoe 2.10 Preparation 8. Keep boom and bucket away from overhead and underground power lines. Electrocution can occur 1. Do not use the backhoe until this manual, the even without direct contact with an overhead skid steer operator's manual, and the safety power line. -
Page 15: Sign-Off Form
2.11 Sign-Off Form Make these periodic reviews of SAFETY and OPERATION a standard practice for all of your Wallenstein follows the general safety standards equipment. An untrained operator is unqualified to use specified by the American Society of Agricultural and this machine. -
Page 16: Safety Signs
3.1 Model QC605 & QC605B Model QC605B is shown. Safety signs and their The types of safety signs and locations on the location are the same for both the QC605 and QC605B equipment are shown in the illustrations that follow. models. - Page 17 QC605 / B, QC620 Safety Signs Skid Steer Mounted Backhoe QC605 and QC605B Safety Sign 7. Warning Explanations Be aware of and stay 50 ft (15 m) or more away from overhead electrical 1. Warning cables. Electrocution is possible with Ensure lock pins are securely out direct contact (arcing).
-
Page 18: Model Qc620
QC605 / B, QC620 Safety Signs Skid Steer Mounted Backhoe 3.2 Model QC620 Z94253 Z94112 Z94239 Z94112 Z94239 Fig. 3 – QC620 Safety Decals... - Page 19 QC605 / B, QC620 Safety Signs Skid Steer Mounted Backhoe QC620 Safety Sign Explanations 7. Warning Be aware of and stay 50 ft (15 m) or 1. Warning more away from overhead electrical Ensure lock pins are securely cables. Serious injury or death from latched before using the equipment.
-
Page 20: Replace Damaged Safety Signs
Installation area must be clean, dry, and free of grease Many features incorporated into this machine are the or oil. result of suggestions made by Wallenstein customers. Read this manual carefully to learn how to use the Ambient temperature must be above 50 °F (10 °C). -
Page 21: Machine Components
/ motion is controlled by switches on the hand control in the cab. Skid steer must be equipped with hydraulic connections on the front of the frame. Models QC605 and QC605B QC605 is shown, but both models have the same features. Mounting Hydraulic Frame... - Page 22 QC605 / B, QC620 Familiarization Skid Steer Mounted Backhoe Model QC620 Mounting Frame Operator Manual Tube Hydraulic Connections Bucket Cylinder Main Frame Bucket Fig. 5 – QC620 Machine Components...
-
Page 23: Equipment Matching
Skid Steer Mounted Backhoe 4.4 Equipment Matching 4.6 Attaching and Unhooking Backhoe • The QC605 and QC605B back hoes are designed to mount on mini skid steer machines. The 4.6.1 Attaching Backhoe QC605B backhoe is specifically designed to mount on Bobcat® mini skid steers. -
Page 24: Job Site Familiarization
QC605 / B, QC620 Operation Skid Steer Mounted Backhoe 4.7 Job Site Familiarization 7. Level off the work area prior to starting. Rougher surfaces require slow speeds that shorten the work Become thoroughly familiar with the work site prior to cycle times. -
Page 25: Be Prepared
QC605 / B, QC620 Operation Skid Steer Mounted Backhoe 5.1 Be Prepared 5.2 Machine Break-In • Review the section on Safe Condition on page Although there are no operational restrictions on the backhoe when used for the first time, it is recommended that the following items be checked at •... -
Page 26: Digging Action
QC605 / B, QC620 Operation Skid Steer Mounted Backhoe 5.4 Digging Action WARNING! WARNING! Avoid risk of falling into the hole or collapsing the sides of the hole. Back away from the hole Underground utility hazard. Contact an before rotating machine. -
Page 27: Operating Hints
QC605 / B, QC620 Operation Skid Steer Mounted Backhoe 5.4.6 Loads The backhoe can be used to lift and place lines, pipes or other loads into trenches or excavations if it is equipped with a thumb. See Mechanical Thumb. 1. Do not exceed the lifting capacity of the backhoe. -
Page 28: Transporting
QC605 / B, QC620 Transporting Skid Steer Mounted Backhoe 6. Transporting WARNING! Follow the instructions provided in the skid steer Ensure lock pins are securely latched before operator's manual to transport the skid steer machine. operation. Failure to secure pins could result in serious injury or death. -
Page 29: Storage
QC605 / B, QC620 Storage Skid Steer Mounted Backhoe 7. Storage 7.2 Removing from Storage When the backhoe is not going to be used for a period 1. Attach backhoe to the skid steer as indicated on of time, remove it from the skid steer and place it in page 23. -
Page 30: Service And Maintenance
QC605 / B, QC620 Service and Maintenance Skid Steer Mounted Backhoe 8. Service and Maintenance Good maintenance is your responsibility. Poor maintenance is an invitation to trouble. 8.1 Service By following a careful service and maintenance program for your machine, you will enjoy many years or trouble-free operation. -
Page 31: Grease Points
QC605 / B, QC620 Service and Maintenance Skid Steer Mounted Backhoe 8.2 Grease Points Location Every 8 hours or daily IMPORTANT! Do Not over grease. Cylinder pivot points. Bucket linkage pivot points. Look for this decal on your machine. It indicates a grease point and service Every 100 hours or annually interval in hours. -
Page 32: Bucket Tooth Replacement
QC605 / B, QC620 Service and Maintenance Skid Steer Mounted Backhoe 8.3 Bucket Tooth Replacement 8.4 Bucket Removal The bucket teeth are replaceable. Check on their The bucket can be easily changed out with another condition weekly. Replace if damaged or worn out. -
Page 33: Maintenance Schedule
Clean machine 9. Trouble Shooting If a problem encountered that is difficult to solve, contact a Wallenstein distributor or dealer. Have the backhoe serial number handy. The Wallenstein QC600 Series Skid Steer mounted backhoe is designed for light digging and trenching Always wear Personal Protective Equipment (PPE) duties. -
Page 34: Specifications
QC605 / B, QC620 Specifications Skid Steer Mounted Backhoe 10. Specifications Model QC605 QC605B QC620 72 in 72 in 72 in Digging Depth — in (mm) (1829 mm) (1829 mm) (1829 mm) 182 lb 235 lb 296 lb Weight — lb (kg) -
Page 35: Bolt Torque
QC605 / B, QC620 Specifications Skid Steer Mounted Backhoe 10.2 Bolt Torque Checking Bolt Torque Imperial Bolt Torque Specifi cations The tables shown give correct torque values for Torque Value various bolts and capscrews. Tighten all bolts to Bolt the torque values specified in the table, unless SAE Gr. - Page 36 Storing Lubricants ..........30 Informative Labels ............7 Servicing Intervals ............30 Skid Steer Weight ............23 Slopes ................24 Lifting Objects ............24 Specifications .............34 Available Bucket Sizes ..........34 Bolt torque .............35 Machine Components ..........21 Digging Depth............34 QC605/QC605B ............21 Hydraulic Fitting Torque .........34 QC620 ..............22...
- Page 37 Max System Pressure ...........34 Recommended Horsepower........34 Weight ..............34 Storage ...............29 Placing in Storage ..........29 Removing from Storage ........29 Transporting ...............28 Trouble Shooting ............33 Unhooking Backhoe ...........23 Warranty ...............6 Work Site Lay-Out ............24...
