CM7394CK/EK
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
For more information contact our team: service.ec@foagroup.com
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 10
CM7395CK/EK
(Included)
(Included)
(Not Included)
Rev: 17-12-15
Advertisement
Related Manuals for Furniture of America CM7394CK/EK
Summary of Contents for Furniture of America CM7394CK/EK
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7394CK/EK CM7395CK/EK ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being Wrench easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 10...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #A x 2 pcs #1A x 1 pc Bolt 1/4" x 1.4" Headboard Panel #B x 6 pcs #1B x 1 pc Bolt 1/4"...
- Page 4 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #8 x 2 pcs #K x 4 pcs Wall Cleat Dowel #L x 6 pcs Screw #M x 6 pcs Fischer Prepare 2 bolts assembly by inserting lock washer...
- Page 5 # CM7394 HEADBOARD PANEL Prepare 6 bolts assembly by inserting lock washer (#C), then flat washer (#D) onto bolts (#B). Align HB legs (#2R/L) to the holes of the headboard (#1). Secure by using bolts (#B). #B x 6 pcs #C x 6 pcs #D x 6 pcs #L x 6 pcs...
- Page 6 Attach threaded bolts (#F) to the holes of the headboard (#1) and footboard (#4). Align side rails (#5) to the threaded bolts (#F), then secure by using washers (#H) and hex nut (#G). #F x 8 pcs #G x 8 pcs #H x 8 pcs Attach support legs (#7) to the holes of the slats (#6).
- Page 7 Align slats (#6) to the side rails (#5), then secure by using screws (#J). #J x 8 pcs ASSEMBLY IS COMPLETED Page 7 of 10...
- Page 8 # CM7395 HEADBOARD w-FABRIC Prepare 6 bolts assembly by inserting lock washer (#C), then flat washer (#D) onto bolts (#B). Align HB legs (#2R/L) to the holes of the headboard (#1). Secure by using bolts (#B). #B x 6 pcs #C x 6 pcs #D x 6 pcs #L x 6 pcs...
- Page 9 Attach threaded bolts (#F) to the holes of the headboard (#1) and footboard (#4). Align side rails (#5) to the threaded bolts (#F), then secure by using washers (#H) and hex nut (#G). #F x 8 pcs #G x 8 pcs #H x 8 pcs Attach support legs (#7) to the holes of the slats (#6).
- Page 10 Align slats (#6) to the side rails (#5), then secure by using screws (#J). #J x 8 pcs ASSEMBLY IS COMPLETED Page 10 of 10...
