For more information contact our team: service.ec@foagroup.com
CM7393D
DRESSER AND MIRROR ARE SOLD AND PACKED SEPARATELY
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
DIFFICULT
Page 1 of 4
Tools Required For Assembly:
Allen Wrench
2 PERSONS RECOMMENDED
CM7393M
(Included)
Rev: 2017-12-07
Advertisement
Table of Contents
Related Manuals for Furniture of America CM7393D
Summary of Contents for Furniture of America CM7393D
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7393D CM7393M DRESSER AND MIRROR ARE SOLD AND PACKED SEPARATELY ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in...
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 4...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1 pc #A x 8 pcs Dresser Bolt Ø1/4" x 1.6" #2 x 1 pc #B x 8 pcs Mirror Lock Washer Ø1/4"...
- Page 4 #A x 8 pcs #B x 8 pcs #C x 8 pcs Prepare 8 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A). Align mirror support (#3) to the holes of the mirror (#2) and dresser (#1). Secure by using bolts (#A). ASSEMBLY IS COMPLETED Page 4 of 4...
