ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7362Q
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 7
(Included)
(Included)
(Not Included)
Rev: 18-05-16
Advertisement
Related Manuals for Furniture of America CM7362Q
Summary of Contents for Furniture of America CM7362Q
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM7362Q ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being Wrench easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 7...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #A x 2pcs Headboard Bolt Ø1/4" x 1-1/3" #B x 8pcs #2R x 1pc Right Headboard Leg Bolt Ø1/4"...
- Page 4 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #J x 8pcs #I x 1pc Screw 1-1/4" Wrench #K x 4pcs Dowel Page 4 of 7...
- Page 5 #A x 2pcs #C x 2pcs #D x 2pcs #K x 4pcs Insert dowels (#K) to the holes of the headboard legs (#2L,R), then align leg support (#3) to the headboard legs (#2L/R). Secure by using bolts (#A) with washers (#C,D). Align headboard legs (#2L/R) to the holes of the headboard (#1), then secure by using bolts (#B) #B x 8pcs...
- Page 6 #F x 8pcs #G x 8pcs #H x 8pcs Attach threaded studs (#F) to the holes of the headboard (#1) and footboard (#4), then align side rails (#5) to the threaded studs (#F). Secure by using beveled washers (#H) with hex nuts (#G). Attach support legs (#7) to the slats (#6).
- Page 7 #J x 8pcs Align slats (#6) to the side rails (#5), then secure by using screws (#J). ASSEMBLY IS COMPLETED Page 7 of 7...
