Summary of Contents for ROTONDI LG Series
- Page 1 series ’ anUal All Steam Iron Instruction & Exploded View SHOULD USE OUR PRODUCT AFTER READING INSTRUCTION...
- Page 2 Lg s team onneCting 1_ MAXIMUM STEAM PRESSURE: 8 BAR 2_ CONNECTING STEAM HOSE 1) Connect steam hose (1) to either steam outlet pipe (2) or the steam nipple of boiler. 2) Connect the other end of steam hose (1) to intake nipple of iron (3).
- Page 3 LG 200 DESCRIPTION Base Exit valve set Steam valve set Valve band set Handle set Valve lever Nipple (A) Nipple (C) LG 300 DESCRIPTION Base Exit valve set Steam valve set Valve band set Handle set Valve lever Cover Nipple (A) Nipple (C)
- Page 4 Nipple Components of drain valve Core Copper-washer Teflon Copper-washer Copper nut cap Knob M4X4 screw ROTONDI group srl Via F.lli Rosselli, 14/16 20019 Settimo Milanese (Milano) - Italy Tel. +39 02 33501224 - Fax +39 02 33501329 www.rotondigroup.com - rotondi@rotondigroup.it...
