INSTALLATION AND OPERATION MANUAL
Thank you for purchasing the Clivus Multrum HP. Please read this manual carefully before installation.
"Clivus Multrum" is a brand of Ecoflo Wastewater Management Pty Ltd.
Visit our website at ecoflo.com.au.
IMCM-204.031121
©Ecoflo Wastewater Management Pty Ltd
Advertisement
Table of Contents
Related Manuals for Ecoflo CM HP
Summary of Contents for Ecoflo CM HP
- Page 1 CM HP INSTALLATION AND OPERATION MANUAL Thank you for purchasing the Clivus Multrum HP. Please read this manual carefully before installation. “Clivus Multrum” is a brand of Ecoflo Wastewater Management Pty Ltd. Visit our website at ecoflo.com.au. IMCM-204.031121 ©Ecoflo Wastewater Management Pty Ltd...
-
Page 2: Table Of Contents
WHAT’S IN THE BOX? TOOLS REQUIRED CM HIGH PROFILE SCHEMATICS INSTALLATION POWERING YOUR FAN EXCESS LIQUID ABSORPTION TRENCH COMPOSTING ACCELERATORS CARE & MAINTENANCE ROTATION OF CHAMBERS TROUBLESHOOTING PRODUCT & COMPONENT WARRANTY MAINTENANCE SCHEDULE APPENDIX 1 IMCM-204.031121 ©Ecoflo Wastewater Management Pty Ltd Page 2... -
Page 3: What's In The Box
• 2.0m length of 100mm diameter agricultural pipe • 2.0m x 0.5m synthetic or Hessian geotextile mat • 0.30 cubic metre 20 mm Aggregate • 50mm PVC pipe to connect the hose to the agricultural pipe Purchase a Drain Kit from Ecoflo. TOOLS REQUIRED Marker Tape Measure... -
Page 4: Cm High Profile Schematics
If you are planning to excavate an area under the house for the compost chambers, please ensure the area is well-drained and any retaining walls are built to the satisfaction of the local authority. IMCM-204.031121 ©Ecoflo Wastewater Management Pty Ltd Page 4... -
Page 5: Installation
NOTE: Due to the pedestals being man made, the distance to the centre may vary from 245 to 255mm. Please check before cutting the hole. STEP 2: POSITION THE WASTE CHUTE A 240mm hole must be cut in the toilet room floor to accommodate the waste chute. IMCM-204.031121 ©Ecoflo Wastewater Management Pty Ltd Page 5... - Page 6 NOTE: If there is a joist in the way, either reposition the waste hole OR install trimmer joists to each end of the cut joist, and fix all connections with galvanised framing anchors with 4 nails each leg (refer to diagram below). View from under floor IMCM-204.031121 ©Ecoflo Wastewater Management Pty Ltd Page 6...
- Page 7 STEP 3: INSTALL THE WASTE CHUTE First ensure the pad or ground level on which the ‘In-service’ chamber will reside is at its final level beneath the toilet room. Insert the chute into the hole Mark position IMCM-204.031121 ©Ecoflo Wastewater Management Pty Ltd Page 7...
- Page 8 The Pad will be factory installed. The Heater Pad runs on 12 Volt Power (refer to the supplementary manual). NOTE: The Heater Pad should not be submerged. Check your ‘Excess Fluid Outlet’ for blockages regularly. IMCM-204.031121 ©Ecoflo Wastewater Management Pty Ltd Page 8...
- Page 9 Compost Mixer to the Mixer Ring. 3. Put the compost mixer in the chamber. 4. Connect the lid to the waste chute, position the chamber under the lid, then hook the bungee loops around the lid. IMCM-204.031121 ©Ecoflo Wastewater Management Pty Ltd Page 9...
- Page 10 Flexible Air Pipe L.I.T Reducer 100-50mm Slotted Pipe Connector Flexible Air Pipe The fan is IP68 rated so will not be effected by moisture. Do not glue the fan housing to the DWV fittings. IMCM-204.031121 ©Ecoflo Wastewater Management Pty Ltd Page 10...
- Page 11 STEP 7: CONNECT THE FLEXIBLE AIR HOSE AND EXCESS FLUID HOSE TO THE CHAMBERS CM HP Chamber Breather Outlet IMCM-204.031121 ©Ecoflo Wastewater Management Pty Ltd Page 11...
-
Page 12: Powering Your Fan
Connect the fans to the transformer as follows: We recommend a spare fan is kept on hand at all times, particularly after a year of use. Shop fans and solar: ecoflo.com.au/products/fans-and-solar Solar Power Refer to Solar Panel Installation Manual. -
Page 13: Composting Accelerators
Any staining of the pedestal can also be removed with the spray. Nature Quick Microbes This should be used each time a chamber is changed to kick start the process in the new chamber. Shop consumables: ecoflo.com.au/products/consumables IMCM-204.031121 ©Ecoflo Wastewater Management Pty Ltd Page 13... -
Page 14: Care & Maintenance
• Check vent pipe & remove any foreign matter. • Check the fan is operating • Check that system is draining correctly 6 MONTHS • Remove and clean fan Shop consumables at ecoflo.com.au/products/consumables IMCM-204.031121 ©Ecoflo Wastewater Management Pty Ltd Page 14... -
Page 15: Rotation Of Chambers
If the ‘Out-of-service’ chamber is to be placed away from the Main Vent assembly, you will need to dig a small second trench (20 x 20 x 20cms) to allow residual liquid to exit the chamber. Connect the second liquid drain hose from the chamber to the trench. IMCM-204.031121 ©Ecoflo Wastewater Management Pty Ltd Page 15... -
Page 16: Troubleshooting
If you need to change your ‘In-service’ chamber and the ‘Out-of-service’ chamber is not yet composted, dispose of the waste as normal and order an extra chamber from Ecoflo. IMCM-204.031121 ©Ecoflo Wastewater Management Pty Ltd... - Page 17 Cover the pedestal with cling film until the power is restored. If you are connected to mains power consider installing an Uninterrupted Power Supply (UPS), available at Ecoflo Wastewater Management. The UPS will cut in with power from a 7Ah battery when there is a loss of mains power.
-
Page 18: Product & Component Warranty
Items subject to a dispute, where photographic evidence is inconclusive, must be sent prepaid to Ecoflo. The cost will be reimbursed by Ecoflo should the claim be found valid. In addition to the above, Ecoflo will only replace a fan that fails during the warranty period under the following conditions: •... -
Page 19: Maintenance Schedule
The ‘Out-of-service’ chamber must compost for a minimum of 6 months from the date it was first rotated ‘Out-of-service’. Date chambers were last rotated: Wear protective clothing including gloves and eyewear when servicing, rotating or emptying chambers. IMCM-204.031121 ©Ecoflo Wastewater Management Pty Ltd Page 19... -
Page 20: Appendix 1
APPENDIX 1 IMCM-204.031121 ©Ecoflo Wastewater Management Pty Ltd Page 20... - Page 21 Ecoflo Wastewater Management Pty Ltd www.ecoflo.com.au www.clivusmultrum.com.au Phone: 1300 138 182 (07) 3889 6144 Email: info@ecoflo.com.au Proudly Designed and Assembled in Australia by Ecoflo Wastewater Management IMCM-204.031121 ©Ecoflo Wastewater Management Pty Ltd Page 21...
