Specifications - Airetool ATP III Instruction Manual

PL19-6000EN
05/15/2015
Pump Model
Motor
Motor Voltage
Motor RPM
Maximum Current Draw
Output Flow Rate *
Relief Valve Adjusment Range 1,400-10,000 psi (70-700 bar)
Sound Level
Reservoir Capacity
Weight (with oil)
* Note: Output flow rate shown is at 60 Hz.
Figure 1
ATP III Electric/Hydraulic Pump Specifications
Flow rate will be approximately 5/6 of shown values at 50 Hz.
Airetool
®

Specifications

5526244 (ATP III)
1.7 hp (1,25 kW) Electric Motor
115 VAC, Single Phase, 50/60 Hz
1,750
20 Amps
100 psi (7 bar) = 700 in
700 psi (50 bar) = 535 in
5,000 psi (350 bar) = 76 in
10,000 psi (700 bar) = 60 in
85-90 dBA
2 gallons (8 liters)
70 lbs. (31.8 kg)
Page 2
3 /min (11,5 l/min)
3
/min (8,8 l/min)
3
/min (1,2 l/min)
3
/min (1,0 l/min)
