- Page 1 Operating & Service Manual Airetool ® 90120-IM 05/25/2011 PATP-9400-P Pneumatic Powered Hydraulic Pump Model Number Part Number (Order) PATP-9400-P 2999307 For additional product information visit our website at http://www.apextoolgroup.com...
-
Page 2: Important Receiving Instructions
IMPORTANT RECEIVING WARNING: The system operating pressure must not exceed the pressure rating of the INSTRUCTIONS lowest rated component in the system. Install Visually inspect all components for shipping damage. pressure gauges in the system to monitor Shipping damage is not covered by warranty. If shipping operating pressure. -
Page 3: Installation
PATP 9400 P Pump Specifications: 100 PSI @ 40 SCFM Air Requirement for maximum Pressure @ 50 PSI (3.5 bar) 850 in /min (13.9 1/min) Hydraulic Flow @ 1000 (69bar) 105 in /min (1.72 1/min) @ 10000 PSI (690 bar) 30 in /min (0.5 1/min) External Relief Valve Adjustment 1100 10000 PSI... -
Page 4: Maintenance
MAINTENANCE 1. Maintain proper oil level. 2. When the pump is run for prolonged periods of time, ice may form on the muffler element and must be removed. 3. Change the oil every 250 hours or more frequently if used in dirty environments. To remove the oil from the pump, remove the vent/fill/gauge cap and insert a siphon tube to siphon the oil from the pump. -
Page 5: Troubleshooting
TROUBLESHOOTING Only qualified hydraulic technicians should service the pump or system components. The following information is intended to be used as an aid in determining if a prob- lem exists. For repair service, contact the Authorized Enerpac Service Center in you area. Symptom Possible Cause Pump will not start... - Page 6 PATP 9400P PARTS LIST ITEM MODEL NUMBER DESCRIPTION ITEM MODEL NUMBER DESCRIPTION DA10001401 ENCLOSURE ZB2BZ009P BASE DA10597101 MOUNTING PLATE KDVF5/7562 CONNECTOR DA10526660 AIR PILOTED VALVE KDV-1/8-242697 INSERT DA10527660 AIR PILOTED VALVE MAV 4 VALVE DA10528660 SHUTTLE VALVE MSV1 SHUTTLE VALVE DA10596095 FITTING MPA 5P...
- Page 7 PATP HT Hose Tube Assembly 5524903 ITEM PART NO. PART NAME 2999929 HYD HOSE ASSY 10000 5525236 PATP TUBE ASM W/ SLEEVE HYD HOSE ASSY 10000 REPLACEMENT HYD FITTINGS ITEM PART NO. PART NAME 2900094 10,000 PSI NIPPLE 2900095 10,000 PSI COUPLING PATP TUBE ASM REPLACEMENT PARTS ITEM PART NO.
- Page 8 PATP HDP PENDANT ASSEMBLY 5524904 ITEM PART NO. PART NAME 2999646 PATP 13 PENDANT BODY 2999647 PATP 14 VALVE 2999648 PATP 15 TUBE FITTING 2999649 PATP 16 TOP PLATE 2999650 PATP 17 PLATE RETAINER 2999069 PATP 6 BOX CONNECTOR 2999070 PATP 6 I CON INSERT 2999246 PATP 12 5/32OD X 3/32ID TUBING...
- Page 12 Figure 2...
- Page 13 Figure 3...
- Page 14 Figure 4B...
- Page 15 Figure 4A...
- Page 16 Figure 5...
- Page 17 Figure 6...
- Page 20 Tel: +55 15 2383929 Tel: +36 96 66 1383 Tel: +52 (442) 211-3800 Fax: +55 15 2383260 Fax: +36 96 66 1135 Fax: +52 (442) 103-0443 Apex Tool Group, LLC Airetool 1000 Lufkin Road ® Apex, NC 27539 Phone: 919-387-0099 Fax: 919-387-2614 www.apextoolgroup.com...
