- Page 1 Sultan Sonar Manual Rev 1.0 A Higher Level of Performance Manual OptioLaser L200 > Level, Distance & Position Measurement of Solids and Liquids For more information, please visit > www.hawkmeasurement.com...
-
Page 2: Table Of Contents
Table of Contents OptioLaser L200 Table Of Contents Overview Apendix A Principle of Operation Specifications Applications Apendix B Features Dimension Drawings Quick Start Guide Part Numbering Connections & Instructions for Safe Use Connections & Instructions for Safe Use & Labels >... -
Page 3: Overview
L200 Principle of Operation > The OptioLaser L200 uses time-of-flight laser technology for continuous non-contact distance or level < measurement. Able to measure to any solid or liquid surface, at any angle, the L200 an ideal sensor for level, positioning and detection applications. -
Page 4: Quick Start Guide
Quick Start Guide OptioLaser L200 1. CAUTION - The OptioLaser L200 Sensor contains a laser. Do not look at the beam directly with optical instruments. 2. Download the Laser Terminal Software from hawkmeasurement.com/downloads/ 3. Open the Laser Terminal Package and follow the installation instructions. - Page 5 Quick Start Guide OptioLaser L200 Menu Selection Default Description <O> Measuring meters Enter the required measuring units, either meters or feet. units <P> Zero distance 0.00 m Enter the distance corresponding to the zero datum trim. offset <Q> Lost signal 4.0 sec Enter the lost signal hold time delay in seconds.
-
Page 6: Connections & Instructions For Safe Use
Connections & Instructions for Safe Use OptioLaser L200 > Figure 1 :: Connection diagram Figure 1 :: Connection diagram < The L200 is a laser rangefinder that emits ionizing laser radiation from its measuring laser. The level of the laser emission from the measuring laser is Class 1M which indicates that the laser beam is safe to look at with the unaided eye but must not be viewed using binoculars or other optical devices at a distance of less than 15 meters. -
Page 7: Connections & Instructions For Safe Use & Labels
US: +1(888) 429-5538 (12-28VDC) Laser Safety: Class 1M & Class 2 (aim) hawkmeasurement.com Max Current: 100 mA Enclosure Rating: IP66 Output: 4-20 mA, 2 x Relays (N/O) Temperature: -20 to 60°C (-40 to 140ºF) Figure 2 :: Labelling on the OptioLaser L200... -
Page 8: Apendix A
Apendix A OptioLaser L200 Specifications Performance data Sensing range 0.3 ... 100 m (0.98’ ... 328’) Resolution 10 mm (0.39”) Accuracy <0.1% of full range at 20°C Update rate 5 readings per second Technical data Power supply 220 / 100 V ac or 24 V dc nominal (12 ... 28 V dc) Current consumption 100 mA nominal >... -
Page 9: Apendix B
Apendix B OptioLaser L200 Dimension Drawings L200 Aiming pointer M20 Cable Laser optics gland Receiver optics 3 Equi-spaced holes tapped M5 on 74 PCD for front face mounting > < 88.9 (3.5) L200/DT 4 Holes on 120 PCD Ø8.5 140 (5.51) 120 (4.72) unit in milimeter (inch) Figure 3 :: Dimension drawings of the L200... -
Page 10: Part Numbering
Part Numbering OptioLaser L200 OptioLaser L200 Laser Transmitter for Level Model L100 OptioLaser Laser Level Transmitter (up to 164ft) L200 OptioLaser Laser Level Transmitter (up to 328ft) Dust Tube + USB Programming Cable (Required for every OptioLaser L100/L200) Dust Tube, Stainless Steel...
