- Page 1 Sultan Sonar Manual Rev 1.0 A Higher Level of Performance Manual OptioLaser L100 > Level, Distance & Position Measurement of Solids and Liquids For more information, please visit > www.hawkmeasurement.com...
-
Page 2: Table Of Contents
Table of Contents OptioLaser L100 Table Of Contents Overview Apendix A Principle of Operation Specifications Applications Apendix B Features Dimension Drawings Quick Start Guide Part Numbering Laser radiation information Labels > < PROPRIETARY NOTICE Handling Procedure: The information contained in this publication is derived in 1. -
Page 3: Overview
L100 Principle of Operation > The OptioLaser L100 uses time-of-flight laser technology for continuous non-contact distance or level < measurement. Able to measure any solid or liquid surface, at any angle, the L100 an ideal sensor for level, positioning and detection applications. -
Page 4: Quick Start Guide
Quick Start Guide OptioLaser L100 1. CAUTION - The OptioLaser L100 Sensor contains a laser. Do not look at the beam directly with optical instruments. 2. Download the Laser Terminal Software from hawkmeasurement.com/downloads/ 3. Open the Laser Terminal Package and follow the installation instructions. Everything needed for communicating with the L100 will automatically be installed. - Page 5 Quick Start Guide OptioLaser L100 Menu Selection Default Description <O> Measuring meters Enter the required measuring units, either meters or feet. units <P> Zero distance 0.00 m Enter the distance corresponding to the zero datum trim. offset <Q> Lost signal 4.0 sec Enter the lost signal hold time delay in seconds.
-
Page 6: Laser Radiation Information
Connections & Instructions for Safe Use OptioLaser L100 unit in milimeter (inch) RS485+ RS485- connector Load Relay B RS485+ + 24 V Load Relay A RS485- + 24 V Load 4...20 mA 4. . 20mA +24 V + 24 V power supply + 24 V dc Earth >... -
Page 7: Labels
Enclosure Rating: IP66 Output: 4-20 mA, 2 x Relays (N/O) Temperature: -20 to 60°C (-40 to 140ºF) Output: 4-20 mA, 2 x Relays (N/O) Temperature: -20 to 60°C (-40 to 140ºF) > < Figure 2 :: Labelling on the OptioLaser L100... -
Page 8: Apendix A
Apendix A OptioLaser L100 Specifications Performance data Sensing range 0.3 ... 50 m (0.98’ ... 164’) Resolution 10 mm (0.39”) Accuracy <0.1% of full range at 20°C Update rate 5 readings per second Technical data Power supply 24 V dc nominal (12 ... 28 V dc) Current consumption 100 mA nominal >... -
Page 9: Apendix B
Apendix B OptioLaser L100 Dimension Drawings L100 34 (1.34) M20 Cable gland M5 Mounting holes > < 63.5 (2.36) L100/DT 4 Holes on 120 PCD Ø8.5 140 (5.51) unit in milimeter (inch) Figure 3 :: Dimension drawings of the L100 RS485+ RS485- connector... -
Page 10: Part Numbering
Part Numbering OptioLaser L100 OptioLaser L100 Laser Transmitter for Level OptioLaser L100/L200 Laser Transmitter Spare Parts Model L100 OptioLaser Laser Level Transmitter (up to 164ft) Model L200 OptioLaser Laser Level Transmitter (up to 328ft) LXDT Dust Tube for L100/L200 Dust Tube + USB Programming Cable...
