Output Characteristics
9-16

Output Waveforms

Tissue Sensing Technology, an automatic adjustment, controls all modes. As
tissue resistance increases from zero, the energy platform outputs constant current
followed by constant power followed by constant voltage. The maximum output
voltage is controlled to reduce capacitive coupling and video interference and to
minimize sparking.
Bipolar
Low
Standard
Macro
Monopolar Cut
Cut
Blend
Valleylab
Valleylab
Monopolar Coag
Fulgurate
Spray
472 kHz sinusoid continuous
472 kHz sinusoid continuous
472 kHz sinusoid continuous
472 kHz sinusoid continuous
472 kHz bursts of sinusoid, recurring at 26.21 kHz
intervals. 50% duty cycle.
472 kHz bursts of sinusoid, recurring at 28.3 kHz
intervals. 25% duty cycle.
472 kHz damped sinusoidal bursts with a repetition
frequency of 30.66 kHz. 6.5% duty cycle.
472 kHz damped sinusoidal bursts with a randomized
repetition centered at 21.7 kHz. 4.6% duty cycle.
