QMT15 Instruction Manual
We are here to help!
Please contact Customer Service with any questions.
Customer Service
Americas: 800-359-5520 • 651-484-7988 • info@milestone.com
Europe, Middle East, and Africa: + 31 40 2324700 • info@milestone.com
Asia Pacifi c: 86 755 8996 9226 • info@milestone.com
Milestone • 2221 Hwy 36 West • Saint Paul, MN 55113 USA
©2011 Milestone AV Technologies, a Duchossois Group Company. All rights reserved. Secura is a brand of Milestone.
All other brand names or marks are used for identifi cation purposes and are trademarks of their respective owners.
Advertisement
Related Manuals for Secura QMT15
Summary of Contents for Secura QMT15
- Page 1 Milestone • 2221 Hwy 36 West • Saint Paul, MN 55113 USA ©2011 Milestone AV Technologies, a Duchossois Group Company. All rights reserved. Secura is a brand of Milestone. All other brand names or marks are used for identifi cation purposes and are trademarks of their respective owners.
- Page 2 English - How to use this manual Suomi - Oppaan käyttäminen For best results, reference both the text and illustrations. Saavutat parhaan tuloksen tutustumalla sekä tekstiin Cut along the dashed lines to match your language with the että kuviin. Leikkaa katkoviivaa pitkin ja yhdistä kuvat ja illustrations.
-
Page 3: Speci Cations
English IMPORTANT SAFETY INSTRUCTIONS – SAVE THESE INSTRUCTIONS – PLEASE READ ENTIRE MANUAL PRIOR TO USE Speci cations Weight capacity-DO NOT EXCEED: 31.7 kg (70 lb) includes TV and any accessories Ù Tilt: –13° Ù CAUTION: Avoid potential personal injuries and property damage! Do not use this product for any purpose not explicitly speci ed by manufacturer. - Page 4 Select TV Hardware and Mount TV Brackets Select the hardware diameter and length Your TV type will help you determine which hardware con guration to use. Installation option without spacers (TVs with at backs) Installation option using spacers (TVs with irregular backs) Hand thread screws into the threaded inserts on the back of your TV to determine the correct screw diameter (M4, M6, or...
- Page 5 For TVs with an irregular back Ensure the brackets are level on the back of the TV. Standard con gurations are shown. For special applications, or if you are uncertain about your hardware selection, contact Customer Service. M4/M6/M8 [02, 03 ] [03] [02] [14, 15 ]...
- Page 6 Wall Mounting Wood stud 13 mm 5.5mm (1/2 in.) (7/32 in.) Verify the center of the stud(s) using an awl, a thin nail, or an edge to Locate stud(s) edge stud nder. CAUTION: Avoid potential personal injuries and property damage! Any material covering the wall must not exceed 16 mm (5/8 in.).
-
Page 7: Wall Mounting
Wall Mounting Solid concrete or concrete block 13 mm 10 mm (1/2 in.) (3/8 in.) Mark the wall Level the wall plate [01] and mark the hole locations. CAUTION: 406 mm Avoid potential injuries or property damage! (16 in.) Mount the wall plate [01] directly onto the concrete surface. Ù... - Page 8 Hang your TV onto the Wall Plate HEAVY! You will need assistance with this step. [02, 03] [02, 03] [01] [01] Adjust Tilt Tension...
- Page 9 Remove your TV from the Wall Plate To remove the TV from the wall plate, simultaneously pull release straps down and TV out, and then lift the TV up and out away from the wall. HEAVY! You will need assistance with this step.
- Page 10 Suomi English Milestone AV Technologies and its a liated corporations and subsidiaries (collectively, “Milestone”), Milestone AV Technologies sisar- ja tytäryhtiöineen (yhdessä Milestone) on pyrkinyt tekemään intend to make this manual accurate and complete. However, Milestone makes no claim that the tästä...
