- Page 1 GE T TING STARTED QUICK REFERENCE GUIDE M ARVEL UNDERCOUNTER REFRIGERATION M L N P 1 1 5 - I G 0 1 A M L N P 1 1 5 - S S 0 1 B M S N P 1 1 5 - S S 0 1 A T H E O R I G I N A L R E F R I G E R AT I O N E X P E R T S S I N C E 1 8 9 2...
-
Page 2: Table Of Contents
WARNING Got a Marvelous Design? State of California Proposition 65 Warning: We would love to see how your Marvel product looks in its This product contains one or more chemicals known new home. Send us photos at marketing@marvelrefriger- to the State of California to cause birth defects or ation.com, and we might feature your Marvel home design... -
Page 3: Unpacking Your Appliance
Keep your carton and packaging until your appliance has been thoroughly inspected and found to be in good condi- tion. If there is damage, the packaging will be needed as proof of damage in transit. Afterwards please dispose of all items responsibly. MARVEL WARNING XXXXXXXXXXXX XXXXXXXXXXXX WARNING -... -
Page 4: Installing Your Appliance
CAUTION floor and level from side to side and front to back. The over- all height of your Marvel appliance may be adjusted higher (by turning the leveling leg out, CCW) and lower (by turning Front Grille the leveling leg in, CW). -
Page 5: Electrical
ELECTRICAL Electrical Connection A grounded 115 volt, 15 amp dedicated circuit is required. This product is factory equipped with a power supply cord that has a three-pronged, grounded plug. It must be plugged into a mating grounding type receptacle in accor- dance with the National Electrical Code and applicable Do not remove local codes and ordinances (see Figure 6). -
Page 6: Cutout And Product Dimensions
CUTOUT & PRODUCT DIMENSIONS PREPARE SITE 14 ⁄ ” (379 mm) CAUTION Your product has been designed for either free-standing FRONT or built-in installation. When built-in, your unit does not require additional air space for top, sides, or rear. However, 28”... - Page 7 CUTOUT & PRODUCT DIMENSIONS CUTOUT DIMENSIONS - MLNP115 14 ⁄ ” (379 mm) Preferred location for electrical outlet is in an adjacent FRONT 5⁄8" cabinet. (16 mm) Figure 11 34 1⁄₄" 24" 28” Figure 13 (870 mm) (610 mm) 33 ⁄ ” 34 ⁄...
-
Page 8: Door Adjustments
16-1/2" 16-1/2" 90° 90° Door Swing Door Swing DOOR ADJUSTMENTS Black, White and Wood Overlay Stainless Steel 2175R(F) & 2275WC Models Grille Installation Door Swing REMOVING AND INSTALLING GRILLE Wall Wall 1/4" Min. 2-1/8" Min. (6 mm) (54 mm) WARNING WARNING ... - Page 9 DOOR ADJUSTMENTS To align and adjust the door - MSNP115 1. Gently pry off hinge cover from top of unit. 2. Loosen (do not remove) top and bottom hinge screws using a Torx T-25 screwdriver. 3. Align door squarely with cabinet. 4.
- Page 10 DOOR ADJUSTMENTS Door Adjustments - MLNP115 DOOR ALIGNMENT AND ADJUSTMENT Align and adjust the door if it is not level or not sealing properly. If the door is not sealed, the unit may not cool properly, or excessive frost or condensation may form in the interior.
-
Page 11: Door Reversal
DOOR REVERSAL REVERSING THE DOOR Prepare door for reinstallation: 1. Remove gasket. This will reveal mounting holes for the 1. Open door. magnet assembly. 2. Using T-25 Torx bit loosen screw #1 and remove 2. Remove magnet assembly from door with T-10 TORX screw #2 on top and bottom hinge. -
Page 12: Installing The Anti-Tip Device
INSTALLING THE ANTI-TIP DEVICE Check to be sure the unit is level from front to back Anti-Tip Bracket - MSNP115 and side to side. Make any necessary adjustments. 1. Slide unit out so screws on top of unit are easily The unit’s top surface should be approximately 1/8”... -
Page 13: Integrated Panel Installation
6. Secure integrated panel to door using clamps. A robust tape may also be used. Marvel recommends the use of bar clamps to secure the panel to the door. If using tape, be certain the tape will not damage panel finish upon removal. -
Page 14: Installing The Drain Plumbing
INSTALLING THE DRAIN PLUMBING Drain NOTE This model comes equipped with a factory installed drain pump. The maximum lift for the drain pump is 10 feet. This must be CONNECT DRAIN LINE done as close to the rear of the unit as possible. CAUTION Failure to connect water supply or drain line connections properly can result in personal injury and property damage. -
Page 15: Installing The Water Supply
INSTALLING THE WATER SUPPLY Water Hookup CAUTION PREPARE PLUMBING The water valve uses a standard 1/4” (6.35 mm) compression fitting. Turn off water supply and disconnect electrical supply to unit prior to installation. Use caution when handling back panel. The edges could be sharp. CAUTION 1. -
Page 16: Operation Of Ice Machine
Time 2. Adjust using to reach set point varies based upon ambient temperature, temperature of product loaded, door openings, etc. Marvel 3. Confirm setting by pressing recommends allowing the unit to reach set points before... -
Page 17: Using Your Electronic Control
USING YOUR ELECTRONIC CONTROL CONTROL FUNCTION GUIDE FUNCTION COMMAND NOTES ON/OFF Press and release. Unit will immediately turn On or OFF. Adjust Ice Density See “Ice” section. The o F / o C symbol will flash briefly after 5 sec- Press and hold for 5 seconds and onds. -
Page 18: Cleaning Your Ice Machine
CLEANING YOUR ICE MACHINE Cleaning NUGGET ICE MACHINE CLEANING CYCLE This ice machine has an automatic clean alert function. The EXTERIOR CLEANING control will indicate in the display, approximately every six months with normal use, reminding you to Stainless steel can discolor when exposed to chlorine gas, clean your unit. - Page 19 Clean potable water • SafeCLEAN Plus™ Cleaner (Part No. 41015681 by Marvel) 1-8oz. bottle included with unit. Dispenser Tube Need more cleaner? Call Marvel Customer Service at Figure 41 616.754.5601. Figure 40 Press and release will appear in the display CAUTION b.
- Page 20 CLEANING YOUR ICE MACHINE will appear in the display Cleaning Condenser a. Reinstall shield and close door. b. The machine will circulate water and perform a INTERVAL - EVERY SIX MONTHS series of final rinses for approximately 15 minutes. c. The unit will resume making ice - indicated by 3 sof To maintain operational efficiency, keep the front grille free tones and scrolling in the display.
-
Page 21: Care And Cleaning
3. After water is drained, reinstall the drain pump and reattach all connections. For questions regarding winterization, please call Marvel Refrigeration at 616.754.5601... -
Page 22: Obtaining Service
800.223.3900 for directions on how to obtain warranty coverage in your area. • If the product is outside the first year warranty period, Marvel Customer Service can provide recommendations of service centers in your area. A listing of authorized service centers is also available at www.marvelrefrigeration.com under the... -
Page 23: Warranty
For designated Marvel Professional product, Marvel offers a one year extension of the two year warranty coverage from the date of purchase, free of charge. To take advantage of this third year warranty, you must register your product with Marvel within 60 days from the date of purchase at marvelrefrigeration.com and provide proof of purchase. - Page 24 Marvel Refrigeration 1260 E. Van Deinse St. Greenville MI 48838 616.754.5601 All specifications and product designs subject to change without notice. Such revisions do not entitle 30668 Rev A the buyer to corresponding changes, improvements, additions, replacements or compensation for previously purchased products.
