OWNER'S GUIDE & SERVICE MANUAL
M A R V E L U N D E R C O U N T E R R E F R I G E R AT I O N
Model: MLNP115-IS01A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MLNP115-IS01A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Marvel MLNP115-IS01A

Summary of Contents for Marvel MLNP115-IS01A

  • Page 1 OWNER’S GUIDE & SERVICE MANUAL M A R V E L U N D E R C O U N T E R R E F R I G E R AT I O N Model: MLNP115-IS01A...

  • Page 2: Warranty Registration

    Got a Marvelous Design? located inside the cabinet on the left side near the top. We would love to see how your Marvel product looks in its new home. You can send us photos of your installed product at marketing@marvelrefrigeration.com, and we...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Tip: Click on any section below to jump directly there Safety Control Operation - Service Important Safety Instructions Service Mode Thermistor Installation Warranty Unpacking Your Appliance Electrical Cutout & Product Dimensions Side-by-Side & Stacking Installations Installing the anti-tip device Door Reversal Integrated Panel Dimensions Integrated Panel Installation...

  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS Important Safety Instructions Warnings and safety instructions appearing in this guide are not meant to cover all possible conditions and situations that may occur. Common sense, caution and care must be exercised when installing, maintaining or operating this appliance. Recognize Safety Symbols, Words and Labels WARNING...

  • Page 5: Unpacking Your Appliance

    UNPACKING YOUR APPLIANCE WARNING CAUTION If the appliance was shipped, handled or stored in other EXCESSIVE WEIGHT HAZARD than an upright position for any period of time, allow the Use two or more people to move product. appliance to sit upright for a period of at least 24 hours Failure to do so can result in personal injury.
  • Page 6 ELECTRICAL Electrical Connection A grounded 115 volt, 15 amp dedicated circuit is required. This product is factory equipped with a power supply cord that has a three-pronged, grounded plug. It must be Do not remove plugged into a mating grounding type receptacle in ground prong accordance with the National Electrical Code and applicable local codes and ordinances.

  • Page 7: Cutout & Product Dimensions

    CUTOUT AND PRODUCT DIMENSIONS ROUGH-IN OPENING DIMENSIONS CABINET DIMENSIONS "A" "B" "C" "D" "E" "F" "G" "H" "J" 14 7/8" 33 3/4” to 34 3/4”" 22 7/8" 37 3/8" 15" 34” to 35" 24" (8.1 cm) (85.7 cm to 88.3 cm) (61 cm) (37.8 cm) (86.4 cm to 88.9 cm)
  • Page 8 CUTOUT AND PRODUCT DIMENSIONS PRODUCT DATA ELECTRICAL PRODUCT REQUIREMENTS # WEIGHT 105 lbs 115V/60Hz/15A (47.6 kg) "J" "H" "D" "G" "E" " (54.6 cm) "F" Glass Door Shown Minimum rough-in opening required is to be larger than the adjusted height of the cabinet. A grounded 15 amp dedicated circuit is required.

  • Page 9: Side-By-Side Installation

    Side-by-Side Installation 3. Place bracket over holes and attach to unit with two screws removed in step 2 using a T-25 Torx driver. Two units may be installed side-by-side. Tighten screws fully. Cutout width for a side-by-side installation is the cutout 4.

  • Page 10: Anti-Tip Bracket

    INSTALLING THE ANTI-TIP DEVICE Anti-Tip Bracket 1. Slide unit out so screws on top of unit are easily accessible. 2. Remove the two screws from the opposite side of the hinge assembly using a T-25 Torx driver (see below). Place bracket over holes and attach to unit with two screws removed in step 2 using a T-25 Torx driver.

  • Page 11: Door Adjustments

    REVERSING THE DOOR Door Adjustments Location of the unit may make it desirable to mount the HINGE COVER door on the opposite side of the cabinet. Hinge cover included with the literature bag is optional. The hinge hardware will be removed and reinstalled on the opposite side of the cabinet.
  • Page 12 Remove door by tilting forward and lifting door off Install top hinge and door: bottom hinge. Retain shoulder washers; they will be reused. Install hinge with longer straight edge aligned to Remove three screws from hinge holes on the outside edge of cabinet. Do not tighten. opposite side.

  • Page 13: Integrated Panel Dimensions

    INTEGRATED PANEL DIMENSIONS Integrated Panel Dimensions BACK SURFACE MUST HAVE AMPLE FLAT SURFACE TO MOUNT OVERLAY PANEL FLAT AND WITHOUT NOTE 3/4" INTERFERENCE (20 mm) 14-3/4" (375 mm) 30-1/4" (768 mm) Integrated Panel Preparation Integrated Panel...

  • Page 14: Integrated Panel Installation

    INTEGRATED PANEL INSTALLATION 5/8" (1.6 cm) or 3/4" (1.9 cm) panel 14 5/8 (37.1 cm) width 29 21/32" (75.3 cm) height NOTE NOTE NOTE...

  • Page 15: Using Your Electronic Control

    USING YOUR ELECTRONIC CONTROL Control Function Guide Function Command Notes ON/OFF Press and release. Unit will immediately turn ON or OFF. Adjust ice density See “Ice” section C symbol will fl ash briefl y after 5 seconds. Interior light and display will go dark and remain so until user resets mode - Enable Sabbath Mode Press and hold for 5 seconds and release...

  • Page 16: Installing The Water Supply

    A TDS meter is included with your unit Water Treatment Options • ◦ TDS level of 200 ppm or higher and/or a hardness of 12-19 gpg can be treated by Marvel’s in-line water filter accessories available at marvelrefrigeration.com: S41016343-ACCY — Standard •...

  • Page 17: Water Hookup

    INSTALLING THE WATER SUPPLY Based upon the TDS measurement, see the below table Water Hookup to determine the correct filter required to protect the ice 1. Turn off water supply and disconnect electrical supply machine. to product prior to attempting installation. Water Quality 1-3 Users 4+ Users...

  • Page 18: Installing The Drain Plumbing

    2. Connect to your local plumbing per the local code. 3. If necessary, insulate drain line to prevent condensation. CAUTION If your Marvel unit did not come with a factory installed CAUTION drain pump you must use a gravity style drain connection.
  • Page 19 INSTALLING THE DRAIN PLUMBING NOTE The maximum lift for the P60 drain pump is 10 feet. This must be done as close to the rear of the unit as possible.

  • Page 20: Care And Cleaning

    CARE AND CLEANING Exterior Cleaning - Stainless Models CAUTION Stainless door panels, handles and frames can discolor when exposed to chlorine gas, pool chemicals, saltwater or Do not use any solvent-based or abrasive cleaners. These cleaners with bleach. types of cleaners may transfer taste and/or odor to the Keep your stainless unit looking new by cleaning with a interior products and damage or discolor the interior.
  • Page 21 Required for cleaning: • Hose and funnel - provided with unit • Bucket and cleaning sponge • Clean potable water • SafeCLEAN Plus™ Cleaner 1-8oz. bottle - Available for purchase from Marvel Need more cleaner? Call Marvel Customer Service at 616.754.5601.
  • Page 22 WARNING NOTE...
  • Page 23 CAUTION...

  • Page 24: Obtaining Service

    If Service is Required: If the product is within the first year warranty period • please contact your dealer or call Marvel Customer Service at 616.754.5601 for directions on how to obtain warranty coverage in your area. If the product is outside the first year warranty period, •...

  • Page 25: Troubleshooting

    Service page to locate a Marvel Authorized servicer. If your product Troubleshooting - What to check when problems occur: is in warranty please make sure to register it at www.marvelrefrigeration.com/warranty-registration.
  • Page 26 If TDS is acceptable, unit must be cleaned and APPENDIX any leakage addressed with a seal kit. (Marvel E11: Sensor in base near fan detecting water service part # 80-55371-13) This sensor is designed to detect water escaping the Area in Front of Sensors (Condenser Side) is Wet product due to any type of malfunction inside the machine.
  • Page 27 If unit fills, the float switch is malfunctioning and d. Check compressor operation. needs to be replaced (part # 80-55538-00). • If unit is not cooling or compressor is not operating, diagnose and fix system problem. If unit is 3 Class product, enter service mode and activate relays 1 and 4 to determine if unit fills with •...

  • Page 28: Product Liability

    The part that caused the damage must be returned to Marvel in its entirety. The part must be clearly labeled with the serial number of the unit it was removed from, the date, and the servicer who removed the part.

  • Page 29: Warranty Claims

    Claims must be submitted online at • Final billing - Remodel www. marvelservice . co m Warranty parts will be shipped at no charge after Marvel • 60 day submittal d eadline from date of completed confirms warranty status. Please provide the model, serial service number, part number and part d escription.

  • Page 30: Ordering Replacement Parts

    Warranty parts will be shipped at no charge after Marvel confirms warranty status. Please provide the model, serial number, part number and part description. Some parts will require color or voltage information.

  • Page 31: R600A Specifications

    PERSONNEL DO HOT PUNCTURE REFRIGERANT TUBING refrigeration system. RISK Of FIRE OR EXPLOSION. FIAMHA_ B LE REFRIGERANT USED. CONSULT Never substitute Marvel OEM replacement parts REPAIR IIANUAVOWHER'S GUIDE BEFORE ATTEMPTING TO SERVICE THIS PRODUCT. ALL SAFETY PRECAUTIONS HUST BE FOUOWEO.
  • Page 32 R-600A SPECIFICATIONS/LABELING WARNING R-600a equipped products are labeled (both the unit and the compressor). Only skilled and well trained service technicians permitted to service R-600a equipped products. R-600a is colorless and odorless. All tools and equipment must be approved for use with R-600a refrigerant.

  • Page 33: Leak Detection

    Evacuate/reclaim via the piecing pliers to ensure the When re-brazing, the system must be purged with dry system is empty of R-600a before any system work is nitrogen and at least one access point open to the performed. atmosphere. When re-brazing, proper ventilation is required along with constant monitoring for the presence of R600a refrigerant.
  • Page 34 The low side of the refrigeration system (evaporator, Proper ventilation during service is required. compressor and suction line) must be leak tested with the compressor off (equalized pressure). Never apply a torch to a charged R-600a refrigeration system. RECHARGING No air is ever to be allowed inside the refrigeration system Use OEM replacement service parts and do not alter the (R-600a refrigerant or dry nitrogen only).

  • Page 35: System Diagnosis Guide

    System Diagnosis Guide REGRIGERATION SYSTEM DIAGNOSIS GUIDE System Suction Suction Compressor Condenser Capillary Evaporator Wattage Condition Pressure Line Discharge Tube Normal Normal Slightly Very hot Very hot Warm Cold Normal below room temperature Overcharge Higher than Very cold Slightly warm Hot to warm Cool Cold...

  • Page 36: Compressor Specifications

    Compressor Specifications FMXA9C REFRIGERANT R600A DANGER VOLTAGE 115 VAC FREQUENCY 60 Hz 5 Ohm at 77 START WINDING ° Electrocution can cause death or serious injury. RUN WINDING 7 Ohm at 77 ° Burns from hot or cold surfaces can cause serious 12 Ohm at 77 °...

  • Page 37: Troubleshooting Extended

    • Automatic Defrost Drain Pan: Water may be heard Marvel Refrigeration, “Customer Care Facility” at dripping or running into the drain pan when the unit is 616.754.5601 for assistance. in the defrost cycle.
  • Page 38 TROUBLESHOOTING GUIDE Concern Potential Causes Action Verify proper air flow through condenser. Is condenser clean? Not Cooling Compressor overheating Confirm condenser fan operation. Compressor not operating Test overload and relay, replace as needed. Compressor operating - no cooling Refer to System Diagnosis Guide. Frozen Product Control set too cold Adjust Set Point Temp accordingly.

  • Page 39: Main Control

    MAIN CONTROL CAUTION The main control board is very robust and is rarely the cause of system issues. It is important to fully diagnose Precautions must be taken while working with the board for any suspected failures before attempting live electrical equipment. Be sure to follow to remove the board for replacement or service.
  • Page 40 Control Operation-Service CONTROL FUNCTION GUIDE FUNCTION COMMAND DISPLAY/ OPTIONS UI BUTTON LAYOUT Unit will immediately Press � and release ON/OFF turn ON or OFF Sabbath Mode See "Sabbath Mode" section Hidden Button SHOWROOM MODE -Access Service Menu This mode is designed to show units in a display -No LED directly above.
  • Page 41 SERVICE MODE GUIDE SERVICE MODE GUIDE THERMISTOR 1 — ZONE THERMISTOR 2 — EVAPORATOR Does not apply to this model. Does not apply to this model. THERMISTOR 1 — ZONE OFFSET 9. Thermistor 2 set point 11. Thermistor 4 set point. This calibration is only to be used if actual to drive the temperature down below the set point.
  • Page 42 E3: Thermistor 3 open. MAIN SOFTWARE 26. Does not apply to this model E5: Thermistor 1 shorted. 27. FACTORY TEST MODEL E6: Thermistor 2 shorted. E7: Thermistor 3 shorted. 28. COMPRESSOR RPM 29. FREEZE TIME ADJUST (MODEL 54 ONLY) HARVEST TIME ADJUST (MODEL 54 ONLY) 31.
  • Page 43 Thermistors Evaporator Thermistor Thermistors are used for various temperature readings. If the evaporator thermistor fails, the unit will rely on a Thermistors provid e reliable temperature readings preset defrost timer during defrost cycles. The unit will using a resistance which varies based on surrounding otherwise operate normally.

  • Page 44: Household Product Warranty

    For designated Marvel Professional product, Marvel offers a one year extension of the two year warranty coverage from the date of purchase, free of charge. To take advantage of this third year warranty, you must register your product with Marvel within 60 days from the date of purchase at marvelrefrigeration.com and provide proof of purchase.
  • Page 45 Marvel Refrigeration 1260 E. Van Deinse St. Greenville MI 48838 616.754.5601 All specifications and product designs subject to change without notice. Such revisions do not entitle the buyer to corresponding changes, improvements, additions, replacements or compensation for previously purchased products.
