Atlantic Furniture BORDEAUX Assembly Instructions Manual

READY
Before assembling your Headboard, please read through these
instructions carefully. Familiarize yourself with the different parts.
please contact Atlantic Furniture at service@atlanticfurniture.com 1-800-955-3726 / M-F 9:00-5:00 EST
PARTS LIST
1 HEADBOARD PANEL 1 PC
2 LEFT LEG 1 PC
3 RIGHT LEG 1 PC
4 SPACER BLOCK 2 PCS
NOTE: WE INCLUDE SPARE HARDWARE IN CASE THE ALLEN WRENCH, JCB , BARREL NUT, WOODEN DOWEL, WOOD BUTTON OR WASHER ARE DAMAGED DURING ASSEMBLY.
Step 1 Insert Wooden Dowels (A) to locator holes on (1)(4) as shown below.
A
4
Attach spacer block (4) to the Legs (2)(3) as shown below, using JCB (B) tighten
Step 2
with Allen wrench (I).
B
4
Bordeaux Headboard & Bed
All manuals and user guides at all-guides.com
BORDEAUX HEADBOARD
ASSEMBLY INSTRUCTIONS
ATTENTION! If you receive a damaged or defective item,
Instructions apply for all sizes of bed
Full > Queen > King
Wooden Dowel 10 X 30mm - 6 pcs
A
JCB M6 X 50mm (2") - 2 pcs
B
Spare - 1 pc
C JCB M6 X 70mm (2 3/4") - 4 pcs
D Barrel Nut - 4 pcs
Spare - 1 pc
E Wood Button - 4 pcs
A
A
2
B
4
Spare - 2 pcs
F
JCB M6 X 25mm (1") - 4 pcs
G Flat Washer - 4 pcs
Spare - 1 pc
Spare - 1 pc
I Allen Wrench - 1 pc
Spare - 1 pc
1
A
3
HARDWARE
Spare - 1 pc
H Split Washer - 4 pcs
Spare - 1 pc
Spare - 1 pc
Adult Assembly
A
Wooden Dowel
B
JCB M6 X 2"
I
Allen Wrench
