OWNER'S
MANUAL
MODEL NO.
STARTING SERIAL # L117-335001
FC10544BS
FC10544CL
FCE11544BS
IMPORTANT
Read and follow all
Safety Precautions
and Instructions
before operating this
equipment.
Rev 17-335
1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093
8/22/2019
10662
CHANGING YOUR LANDSCAPE SINCE 1945
44" FAST FINISH
TRAIL MOWER
Assembly
Operation
Service and Adjustment
Repair Parts
SWISHER ACQUISITION INC.
PHONE 660-747-8183 FAX 660-747-8650
ade I The
USA
of US and Global Parts
Advertisement
Table of Contents
Related Manuals for Swisher FC10544CL
Summary of Contents for Swisher FC10544CL
- Page 1 Safety Precautions and Instructions before operating this Assembly equipment. Operation Service and Adjustment Repair Parts Rev 17-335 ade I The SWISHER ACQUISITION INC. 1602 CORPORATE DRIVE, WARRENSBURG, MISSOURI 64093 PHONE 660-747-8183 FAX 660-747-8650 of US and Global Parts 8/22/2019 10662...
-
Page 2: Limited Warranty
Should you have any questions concerning this warranty, please contact us toll-free at 1-800-222-8183. The model number, serial number, date of purchase, and the name of the authorized Swisher dealer from whom you purchased the mower will be needed before any warranty claim can be processed. -
Page 3: Safety Precautions
SAFETY PRECAUTIONS This Safety Alert Symbol indicates important messages in this manual. When you see this symbol, carefully read the message that follows and be alert to the possibility of personal injury. Read this manual completely. This machine can amputate hands, feet, and throw objects. - Page 4 • Do not put hands or feet near or under rotating parts. Keep clear of the discharge opening at all times. • Do not mow in reverse. Always look down and behind before and while backing. • Turn off the blades when not mowing. Before leaving the machine, turn off the blades and stop the engine.
-
Page 5: Safety Decals
SAFETY DECALS Replace decal immediately if damaged. Order by part number from Swisher. OD33-Speed Decal Trail Mower Serial # OD55-Triangle Danger Decal (All four deck corners) Engine Serial # OD15-Void Warranty Decal OD11-No Step Decal OD36-Deflector Decal OD99125-Medium Swisher Logo Decal... - Page 6 OPERATING YOUR TRAIL MOWER The operation of any mower can produce foreign objects to be thrown into the eyes, resulting in severe eye damage. Always wear certified safety glasses or wide-vision safety goggles over spectacles before staring any cutting machine and while operating such a machine.
-
Page 7: Starting The Engine
See engine manufacturer’s recommendations for the type and amount of oil and fuel used. Trail Mowers equipped with an electric start engine will need a battery (sold separately). Swisher recommends using a standard “12N12A” battery. • Make sure the tow vehicle parking brake is set, mower is level, and blades are disengaged. - Page 8 When offsetting the mower do so to the side opposite the discharge of the tow vehicle. Ϋ㉆ • Swisher recommends if the tow vehicle is equipped with a mid-mount mower to overlap the cut approximately 6”. This may vary depending on mowing terrain, obstacles, and/or tow vehicle. Always keep SAFETY the first priority.
-
Page 9: General Troubleshooting
SUGGESTED MOWING PRACTICES • Operate mower engine at full throttle to assure the best cutting performance and maximum material discharge. • Allow wet grass to dry. Wet grass will clump and collect under the mowing deck. • Mowing should be started with tow vehicle in low gear and increased only as safe mowing conditions permit. -
Page 10: Mower Maintenance
MOWER MAINTENANCE GENERAL RECOMMENDATIONS The warranty on this Trail Mower does not cover items that have been subjected to operator abuse or negligence. To receive full value from the warranty, operator must maintain unit as instructed in this manual. Some adjustments will need to be made periodically to maintain your unit properly. All adjustments in this manual should be checked at least once each season. -
Page 11: Repair Parts
BLADE CARE AND SERVICE For best results mower blades must be kept sharp. The blades can be sharpened with a few strokes of a file or grinding wheel. Do not attempt to sharpen blades while they are on the mower. Disconnect spark plug wire before servicing unit. Important: Replace blades that have been damaged or deeply nicked. -
Page 12: Parts Not Shown
Fig. 1 Cont. WIRING CONFIGURATIONS FC44 12 VOLT START 䩆 Ϋ PARTS NOT SHOWN DESCRIPTION PART # 12 VOLT START MODELS Harness - Wiring, 12V 19206 Solenoid - 3 Pole 1002004 Cable - Battery, 10" Red; Positive BCSR Cable - Battery, 10" Black; Negative Box - Battery 10231* Pad - Battery... - Page 13 Fig. 2 PARTS BREAKDOWN ITEM # DESCRIPTION PART # Cover - Belt 10599* ITEM # DESCRIPTION PART # Bolt - 1/4-20 X 1/2 NB114 Bracket - Roller, Left 4015* Base - Motor 4517* Roller - Anti-Scalp 1/2 ID AS003 Hitch - Weldment 4525* Nut - Jam Lock, 1/2-13 2-Way NB121...
- Page 14 Slide plastic tube on tether 6736 snug against the toggle switch. Blade Driver Assembly (Includes shaft, housing and bearings) Fig. 3 Fig. 4 Part # 9018 ENGINE SET UP BLADE SET UP ITEM # DESCRIPTION PART # ITEM # DESCRIPTION PART # Nut - Jam 3/4-16 NB175...
- Page 15 Fig. 5 Fig. 6 STANDARD ENGAGE HEIGHT ADJUSTMENT ITEM # DESCRIPTION PART # ITEM # DESCRIPTION PART # QTY Bolt - 1/2-13 X 5 NB155 Rod - Crank ES214 Bolt - Spade, 5/16-18 X 10.5 NB260 Nut - Push, 5/16 NB117 Nut - Nyloc 5/16-18 NB181...
- Page 16 Fig. 7 Tension Assembly ITEM # DESCRIPTION PART # Nut - 2 Way Lock 3/8-16 NB280 Washer - 3/8 NB272 Pulley - Idler B527 Bolt - 1/4-20 X 2 NB218 Bolt - 3/8-16 X 1 1/4 NB618 Washer - Idler 6040Z Nut - Nyloc 1/4-20 NB180...
- Page 17 RIGHT ASSEMBLY PART # 10590 Fig. 9 Item # Description Part # Arm - Brake 10589* BRAKE ARM CONFIGURATIONS Eyebolt - 1/4-20 X 3/4 V139EB Nut - Nylock 1/4-20 NB180 Nut - Serr Flange 1/4-20 NB524 Bolt - HTC 1/4-20 X 1 1/2 NB162 Nut - Kep 10-24 NB172...
-
Page 18: Hitch Assembly
Fig. 10 HITCH ASSEMBLY Hitch Replacement Kit (Includes Items 1-13) Part # 18887 慆 Ϋ ITEM # DESCRIPTION PART # QTY. Weldment - "L" Hitch 18829* Tube - Hitch 18832* Tube - Hitch Elbow 18833* Washer - SAE Flat 3/8 NB272 Bolt - 3/8-16x2 1/2 HCC GR5 NB221... - Page 19 艆 δ p ֊ RECOMMENDED HITCH CONFIGURATIONS AND POSITIONS...
- Page 20 湆 Ϋ...
- Page 21 NOTES: ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ 囐 Ң ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________...
- Page 22 NOTES: ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ꀀ ұ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________...
- Page 23 NOTES: ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ꀀ ұ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________ ______________________________________________________________________...
-
Page 24: How To Order Repair Parts
The serial number for the engine will be found on the top of the blower fan housing. FC10544BS All Trail Mower parts listed herein may be ordered directly from Swisher, your nearest Swisher dealer, or from our FC10544CL website. www.swisherinc.com FCE11544BS...
