5.2 Communication Interfaces

5.2.1 USB interface

USB interface pin assignment
•
PIN No. Description
1
VBUS
2
D-
3
D+
4
GND
USB interface connector diagram
•

5.2.2 Wi-Fi interface

Wi-Fi interface supports 2.4 GHz, IEEE Std. 802.11b standard.

5.2.3 Bluetooth Interface

Bluetooth version: Standard BT2.1+EDR
Communication protocol: SPP
Radio frequency: 2.4GHz
Transmission distance: 10m

5.2.4 Ethernet interface

Ethernet interface pin assignment
•
Pin. No. Name
1 TX+
2 TX-
3 RX+
Driver (Windows 32bit/64bit, Linux), Barcode Easy, SDK system
230(W)×290(D)×176(H)mm
Black, white
Approx 3kg
5～40℃/20～95%RH (non-condensing)
-20～60℃/≤95%RH (non-condensing)
GB 4943.2011
Class B
CCC, CE, FCC, UL, Energy star
Cutter, Peeler
150km
(Condition: use specific thermal roll paper and the print rate is 12%)
Classic wire color
Red
White
Green
Black
Description
Tranceive Data+
Tranceive Data-
Receive Data+
