User Manual
Deco Series Pen Tablet

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Deco Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for XP-PEN Deco Series

Summary of Contents for XP-PEN Deco Series

  • Page 1 User Manual Deco Series Pen Tablet...

  • Page 2: Table Of Contents

    Contents I. Overview II. Accessories III. Connection IV. Support system V. Download VI. Driver installation VII. Introduction to driver i. Work area a. Screen b. Pen Tablet/Pen Display ii. Application iii. Pen settings iv. Shortcut keys v. Settings VIII. Driver uninstall...
  • Page 3 I Overview 1. Lanyard hole 2. Power key: Press and hold it for 3 seconds to turn on or off the pen tablet 3. USB-C port 4. Shortcut keys 5. Indicator 1 a. Flashing: Stylus is in range, but not touching the work area b.

  • Page 4: Accessories

    a. Flashing: Low battery (20% battery remaining) b. Solid: Charging c. No Light: Fully charged In purple status: The red and the blue indicator are both on simultaneously 7. Work area * All descriptions and pictures shown are for reference only and may differ from the actual products.
  • Page 5 Wireless Connection (Wireless Connection (on models that support such function) A. Connect via the Bluetooth receiver Plug the Bluetooth receiver into the computer. Press and hold the power key for 3 seconds to turn on the pen tablet. B. Direct Bluetooth connection (Windows 10 or later/Mac OS X 10.10 or later) 1.

  • Page 6: Support System

    Chrome OS 88 or later; Linux. V Download Please download the corresponding driver according to your product model from the XP-PEN official website (https://www. xp-pen.com). VI Driver installation You must install the driver for your device to work properly; If you uninstall the driver, reinstall the latest driver from the XP-PEN official website (https://www.
  • Page 7 (For the standard models: System Preferences -> Security & Privacy -> Accessibility; For the Bluetooth models: System Preferences -> Security & privacy -> Accessibility, Bluetooth). Please ensure that all XP-PEN options have been selected. Otherwise, the device and driver will not work properly.

  • Page 8: Introduction To Driver

    VII Introduction to driver If the device is successfully connected to the computer, the device’s picture will be displayed on the driver interface. If the connection fails, restart your computer or driver. Multiple devices can be connected at the same time, and up to three devices are supported. After switching one of the devices, user-defined settings can be made for the current device, and the settings only work for the currently selected device.

  • Page 9: Pen Tablet/Pen Display

    The screen’s display area can be set in the following three ways: 1. Set full screen: Set the display area of the selected monitor to the maximum. 2. Set screen area: Manually set the screen’s display area with the mouse. 3.

  • Page 10: Application

    4. Customize: Manually enter coordinates in the corresponding input boxes below X, Y, W and H to customize the size of the device’s work area, or use the stylus to drag on the device icon on the driver interface to set the size of the device’s work area. Rotation setting: You may set the device to 0°, 90°, 180°...

  • Page 11: Pen Settings

    iii Pen settings When the stylus is within the sensing area, it will automatically identify different types of styluses and add them to the driver. Each different type of stylus can be configured differently. Click the drop-down menu to "Customize" the stylus’s button functions. Select "Mouse control" or "Keyboard"...
  • Page 12 Other: Precision mode is to limit the device’s work area to a certain area. This function may allow you to create more detailed drawings. Pressure settings: The pressure can be adjusted by adjusting the "output" and "pressure" curve or moving the slider on the progress bar.

  • Page 13: Shortcut Keys

    Windows Ink: Windows system supports handwriting input. If you need to use handwriting function in Microsoft Office, Microsoft Whiteboard and other applications, please do not turn off this function. iv Shortcut keys Select "Customize" in the drop-down menu to customize the functions of shortcut keys. The setting steps are the same as the stylus key settings (see iii Pen settings).

  • Page 14: Driver Uninstall

    Disable pressure: You will not feel the pressure when using the stylus. Disable tilt: Disable the tilt function of the stylus. Diagnostic tool: If there is any problem while using the driver, you can use a diagnostic tool. Import & export configuration: Read or store the set value of the set functions by way of Import &...
  • Page 15 Linux: DEB: Open the terminal window, enter "sudo dpkg -r xp-pen-pentablet" to execute the command; RPM: Open the terminal window, enter "sudo rpm -e xp-pen-pentablet" to execute the command; Tar.gz: Please unzip it first, then enter "sudo" in the terminal window, drag "uninstall.sh" into it and execute command;...
