aspenhome
ah
ITEM NO: ICF-350
Thank you for purchasing this quality product. Be sure to check all packing material carefully for
small parts that may come loose inside the carton during shipment.
ICF-350
FUNCTIONALITY INSTRUCTION
Metal plate
Hook latch
Press here to release
Adjust the leveler
when necessary
BEFORE USING THIS PRODUCT PLEASE READ, UNDERSTAND, AND FOLLOW THESE INSTRUCTIONS.
Save these instructions for future reference.
Page 1/2
50" Single Ped Desk
UNIT SHOULD BE INSTALLED BY 2 OR MORE PERSONS.
Remove the wood screws on the
side of drawer box to remove the
rod loops and file rods if necessary.
FOR INDOOR USE ONLY
MADE IN VIETNAM
R
TOOLS REQUIRED (NOT PROVIDED)
PHILLIPS SCREWDRIVER
COMPONENTS LIST:
Description
No.
Desk Top
1
2
End Panel
Right Pedestal
3
4
Wood Stretcher
HARDWARE LIST:
Description
No.
A Bolt Ø1/4"*1-1/4"
Lock Washer Ø1/4"
B
Flat Washer Ø1/4" *5/8"
C
D Allen Wrench 4MM
E
Wood Screw M4*1-1/2"
Quantity
Sketch
1 PC
1 PC
1 PC
1 PC
Quantity
Sketch
12 PCS
12 PCS
12 PCS
1 PC
2 PCS
Flip down keyboard tray
File drawers hold letter or
legal size files
Leveler on feet
05-09-2017
Advertisement
Table of Contents
Related Manuals for aspenhome ICF-350
Summary of Contents for aspenhome ICF-350
- Page 1 ASSEMBLY INSTRUCTIONS ITEM NO: ICF-350 50" Single Ped Desk Thank you for purchasing this quality product. Be sure to check all packing material carefully for small parts that may come loose inside the carton during shipment. UNIT SHOULD BE INSTALLED BY 2 OR MORE PERSONS.
- Page 2 ASSEMBLY INSTRUCTIONS ITEM NO: ICF-350 50" Single Ped Desk STEP 1: Remove the drawers from the desk top and right pedestal: Fully extend the drawer, then press the plastic tab down on the right and up on the left at the same time as shown below. While holding the tabs pressed down/up, pull the drawer out.
- Page 3 STEP 1: Put the hutch on the single ped desk top. Take off one screw from each metal plate on the back of hutch and swing it in an ideal ICF-350 place. Then re-secure the metal plate with screw to single ped desk top.
