ITEM NO: ICB-495-BCH/BLK/EGG/GRY-KD-1
ICB-406L-BCH/BLK/EGG/GRY-1
ICB-410L-BCH/BLK/EGG/GRY-1
ICB-407D-BCH/BLK/EGG/GRY-1
Thank you for purchasing this quality product. Be sure to check all packing material carefully for
small parts that may come loose inside the carton during shipment.
ICB-495
HARDWARE LIST: ICB-495
Description
No.
A Bolt Ø5/16"*1-3/4"
B Lock Washer Ø5/16"
C Flat Washer Ø5/16"
D Allen Wrench 5mm
HARDWARE LIST: ICB-406L/410L
Description
No.
E Wood Screw
F Allen Wrench 4mm
HARDWARE LIST: ICB-407D
Description
No.
G Bolt Ø1/4"*1-3/4"
H Bolt Ø1/4"*1-1/4"
I Lock Washer Ø1/4"
J Flat washer Ø1/4"
K Wood Screw #8*1"
L Wood Screw #8*1-1/2"
M Allen Wrench 4mm
BEFORE USING THIS PRODUCT PLEASE READ, UNDERSTAND, AND FOLLOW THESE INSTRUCTIONS.
Save these instructions for future reference.
Page 1/5
UNIT SHOULD BE INSTALLED BY 2 OR MORE PERSONS.
ICB-407D
Sketch Quantity
8 PCS
8 PCS
8 PCS
1 PC
Sketch Quantity
10 PCS
1 PC
Sketch Quantity
9 PCS
4 PCS
13 PCS
13 PCS
6 PCS
5 PCS
1 PC
FOR INDOOR USE ONLY
MADE IN VIETNAM
ASSEMBLY INSTRUCTIONS
R
King Framed Panel HB
King Side Rails
Cal King Side Rails
King/Cal King LP FB w/Drawers
All Beds need to be set up in the exact final
location so that after full assembly it will not
need to be moved. Moving the bed will cause
the support legs to move out of perpendicular
(90 degree), weaken the support system, and
may allow the bed to collapse.

TOOLS REQUIRED (NOT PROVIDED)

PHILLIPS SCREWDRIVER
UTILITY KNIFE (FOR CAL KING)
COMPONENTS LIST: ICB-495
Description
No.
1 Headboard
2 Left Leg
3 Right Leg
4 Wood Stretcher
COMPONENTS LIST: ICB-406L/410L
Description
No.
1 Bed rails
2 Slats
3 Magnetic Plate(Only for -410L)
COMPONENTS LIST: ICB-407D
Description
No.
1 Footboard
2 Support Leg (for center rail)
3 Support Leg (for pedestal)
4 Decking
5 Center Rail
6 Filler
7 Bun Foot
8 Support Panel
9 Rail connector
Sketch Quantity
1 PC
1 PC
1 PC
1 PC
Sketch Quantity
2 PCS
5 PCS
4 PCS
Sketch Quantity
1 PC
1 PC
2 PCS
3 PCS
1 PC
1 PC
2 PCS
2 PCS
1 PC
10-26-2017
