CM-AC114
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
Allen Wrench
shows the degree of effort needed in
(Included)
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
DIFFICULT
EASY
Page 1 of 5
Rev.14-04-01
Advertisement
Table of Contents
Related Manuals for Furniture of America CM-AC114
Summary of Contents for Furniture of America CM-AC114
- Page 1 Assembly Instructions CM-AC114 ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some products, two persons are recommended.
- Page 2 Page 2 of 5...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1 pc #A x 8 pcs Table Top Bolt 1/4”x2” #B x 8 pcs #2 x 1 pc Drawer Assembly...
- Page 4 Align the brackets (#E) with the pre-drilled holes on the legs (#3). Prepare 4 bolt assemblies by inserting FIRST the lock washer (#C) onto the bolt (#B) and then the flat washer (#D) onto the SAME bolt (#B), in that order.
- Page 5 Remove the drawers out of the drawer assembly (#2). Align the drawer assembly (#2) with the pre-drilled holes of the legs (#3). III. Prepare 8 bolt assemblies by inserting FIRST the lock washer (#C) onto the bolt (#A) and then the flat washer (#D) onto the SAME bolt (#A), in that order.
