Muse M-32CM User Manual

M-32CM
MICRO SYSTEM CD/MP3/USB
User Manual
Please read the instruction carefully
before operating the unit.
A U D I O C O N T R O L
1. The player is on/off by pressing STANDBY (2/H9) button.
2. The function is selected cyclically by pressing
STOP / CLEAR / FUNCTION button:
CD USB TUNER AUX
NOTE: When standby light is lit, unit is in OFF (standby) mode.
ADJUSTING THE SOUND
Press STANDBY button (2/H9) to turn on the unit,
then press VOLUME +/- control (10/H16, 19/H8)
to adjust the sound to comfortable level. The vol-
ume level will show on display for a few seconds.
MUTE
To cut off the sound from the speakers temporarily, press the MUTE button (H15).
The Volume level icon flash on the LCD display (5). Press the MUTE button again to
cancel Mute mode and restore the sound from the speakers.
Press MUTE button (H15) to on/off mute function.
Note: The mute on is cancelled when:
a. The power is off/on
b. The Volume is adjusted by the VOL +/- button.
USING HEADPHONES (Headphones Not Included)
Connect a set of stereo headphones with 3.5mm mini plug to the phone jack on the
bottom panel. The speakers are automatically cut off when headphones are in use.
Note: To establish a safe headphones sound level:
Start your volume control at a low setting.
Slowly increase the sound until you can hear it comfortably and clearly, and without
distortion.
In full power, the continuous listening of the player may damage the user's
hearing.
GB - 3
Ｈ Ｘ － ２ ７ ０ ６ Ｉ Ｂ Ｍ Ｕ Ｓ Ｅ ０ ０ １ Ｒ Ｅ Ｖ ０ Ｇ Ｂ ． Ｐ ６ ５
1
LOCATION OF CONTROLS
1. SPEAKER
2. POWER / STANDBY BUTTON
3. CD DOOR
4. REMOTE SENSOR
5. LCD DISPLAY
6. USB PORT
7. CD OPEN / CLOSE BUTTON
8. FM STEREO LED INDICATOR
9. PLAY / PAUSE BUTTON
10. VOL + BUTTON
11. F - SKIP / UP BUTTON
12. PLAY MODE BUTTON
13. FOLDER UP BUTTON
14. PROGRAM / CLOCK - ADJ.
BUTTON
15. AUX. IN JACK
16. PHONES JACK
17. BAND BUTTON
B - SKIP / DN BUTTON
18.
19. VOL - BUTTON
20. STOP / CLEAR / FUNCTION
BUTTON
21. TUNING CONTROL
22. SPEAKER CORD
LEFT SPEAKER JACK
23.
24. AC POWER CORD
25. RIGHT SPEAKER JACK
FM WIRE ANTENNA
26.
REMOTE CONTROL
H1. FUNCTION BUTTON
STOP BUTTON
H2.
H3. B - SKIP BUTTON
H4. - 10 TRACK BUTTON
FOLDER DOWN BUTTON
H5.
H6. PROGRAM/CLOCK-ADJ
BUTTON
BAND BUTTON
H7.
H8. VOLUME BUTTON
English
CLOCK SETTING
The clock is displayed on LCD display at standby mode.
1. Press the PROGRAM / CLOCK-ADJ.
button (14/H6).
2. Press the F-SKIP/UP (11/H11) or
B-SKIP /DOWN (18/H3) to select 12 hours
or 24 hours display.
3. Press the PROGRAM / CLOCK-ADJ. button
(14/H6), the hour digit flash.
4. Press the F-SKIP/UP (11/H11) or
(18/H3) to adjust hour digit.
TO ADJUST THE VOLUME
VOLUME 5. Press the PROGRAM / CLOCK-ADJ. button (14/H6), the minute digit flash.
VOL - VOL + 6. Press the F-SKIP/UP (11/H11) or
minute digit.
7. Press the PROGRAM / CLOCK-ADJ. button (14/H6) again, the correct time is
shown on display.
LISTENING TO THE RADIO
1. Turn on the unit by pressing STANDBY
button (2/H9).
2. Press the STOP (20/H2) /FUNCTION
(20/H1) button to select the tuner.
3. Press the BAND button (17/H7) to select desired band.
4. Tune to the desired radio station by using TUNING knob (21) and frequency is displayed.
5. Adjust the sound.
ANTENNA
For FM reception fully unwind the external FM wire antenna and adjust direction, for
optimum reception.
AFTER LISTENING
Turn off the unit by pressing STANDBY button (2/H9).
COMPACT DISC OPERATION
1. Press STANDBY button (2/H9).
2. Press the STOP / FUNCTION button to select CD.
3. Open the CD door(3) by pushing the CD door Open button (7).
4. Place the CD with label side up inside the CD compartment
and close the CD door (3).
5. After a few seconds, the total number of tracks and total
playing time will appear on the Multifunction display (5).
Press button (9/H10) to start playing the CD.
6. Press the PLAY/PAUSE
Installing Battery
Insert 2 "AAA/ UM4" batteries to the remote control prior to use. Make sure to match
their polarities (+/-) to the markings inside the compartment.
NOTES:
- In order to avoid leakage, always remove the batteries when unit will not be used for
- If the remote control is not going to be used for a long time, remove the battery to
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type.
1. This micro system operates on AC230V~50Hz line power supply.
2. The remote control unit operates on 2pcs
Important note
If an abnormal display indication or an operating problem occurs, disconnect the AC
power cord. Wait at least 5 seconds, then reconnect the AC power cord.
An external (auxiliary) audio source (i.e., personal CD player or MP3 player) can be
connected to this unit and heard through the speakers.
H9. STANDBY BUTTON
1. Plug one end of cable (not included)
H10. PLAY/PAUSE BUTTON
H11. F - SKIP BUTTON
2. Plug the other end of the cable into the
H12. + 10 TRACK BUTTON
H13. FOLDER UP BUTTON
H14. PLAY MODE BUTTTON
3. Press the STOP
H15. MUTE BUTTON
H16. VOLUME BUTTON
GB - 1
Track number "01" ,"CD"& the symbol "
normal compact disc playback.
Track number "001","CD", the symbol " " & "MP3"will be shown during MP3 playback.
Track number "001","MP3", the symbol "
playback.
To:
Stop play
Pause play
Resume play after pause
Scan forward and backward
B-SKIP/DOWN
Skip tracks
Repeat current track
Repeat all tracks
B-SKIP/DOWN (18/H3) to adjust
Random play
DISC ERROR
Note: If the disc is dirty, damaged or unreadable, or if the disc is placed upside down,
the "
disc correctly, or try another disc.
Press PLAY MODE button (12) during unit ON mode.
CD plays with a single track repeat, all tracks repeat or
randomly.
FOR MP3/USB PLAYBACK
During Repeat 1
mode, display shows
During Repeat folder
mode,display shows
During Repeat all
mode, display shows
During Random mode,
display shows
button.
GB - 4
2009-6-15, 10:27
a long period of time.
avoid damage caused by battery leakage corrosion.
Before throwing any batteries away, consult your distributor who may be able
to take them back for specific recycling.
POWER SUPPLY
"AAA/UM4" battery (excluded). To
power up the remote control, open the
battery door, install the battery
according to the polarity diagram on the
battery compartment, then close the
battery door.
AUX IN
into the AUX IN socket (15) on the unit.
Headphone or Line Out socket of the
external source.
/ FUNCTION button (20) on the unit or the FUNCTION button
(H1) on the remote control to select Auxiliary function. "AUX" indicator shows on
the display.
GB - 2
" will be shown during
" & "USB" will be shown during USB
PRESS:
once
again
and hold /
/
PLAY MODE once
PLAY MODE twice
PLAY MODE three times
" indicator will appear on the display. If this occurs, clean the disc, insert the
REPEAT, REPEAT FOLDER AND RANDOM PLAYBACK
FOR NORMAL COMPACT
DISC PLAYBACK
During Repeat 1
mode, display shows
During Repeat all
mode, display shows
During Random mode,
display shows
RANDOM
GB -5
-
