  • Page 1 Contents Index USER’S MANUAL Interactive pen display Model: DTU-2235B Interactive pen display Installation Using the pen Customizing the pen Using the pen display Customizing the pen display Using the Radial Menu Application-specific settings Troubleshooting Contents Index...
  • Page 2 Wacom reserves the right to revise this publication without obligation to provide notification of such changes. Wacom does its best to provide current and accurate information in this manual. However, Wacom reserves the right to change any specifications and product configurations at its discretion, without prior notice and without obligation to include such changes in this manual.
  • Page 3 Interactive pen display Contents Index TABLE OF CONTENTS About the manual Adjusting pitch and phase (VGA only) Customizing the pen Navigating the manual Adjusting tip feel and double-click YOUR INTERACTIVE PEN DISPLAY Adjusting eraser feel Pen display features Advanced tip and eraser pressure settings Front view Customizing pen buttons Rear view...
  • Page 4 Interactive pen display Contents Index Product specifications Warranty (Worldwide, Except for Europe, Model DTU-2235B interactive pen display Africa and Middle East) General specifications Limited Warranty Display Warranty Service in the U.S.A. and Canada Tablet Warranty Service Outside of Power adapter the U.S.A.
  • Page 5 For information on how best to use pen display features within a specific application, see the instructions in that application’s manuals. Wacom’s philosophy is to continually improve all of its products. As a result, engineering changes and improvements are made from time to time. Therefore, some changes, modifications, and improvements may not be covered in this document.
  • Page 6 Interactive pen display Contents Index NAVIGATING THE MANUAL Use the navigation controls to move through the manual: Go to front page. Go to table of contents. Contents Go to index. Index Go back to previous view. Page back, or page forward. topic Go to topic.
  • Page 7 YOUR INTERACTIVE PEN DISPLAY This manual describes the installation of your interactive pen display. The Wacom Tablet control panel enables you to customize your pen and pen display settings. To learn more, see customizing. Pen display features Adjusting display incline...
  • Page 8 Interactive pen display Contents Index PEN DISPLAY FEATURES Familiarize yourself with the features and components of your product. FRONT VIEW On Screen Display (OSD) controls Use to adjust the display settings. adjusting the display. Status LED Lights blue when pen is in active area of the pen display and the pen tip is pressed.
  • Page 9 Interactive pen display Contents Index REAR VIEW Security slot Pen storage compartment Allows easy attachment Store by inserting one end of the pen into either side of the of a security cable. compartment. Then gently press other end of pen into the compartment.
  • Page 10 Interactive pen display Contents Index ADJUSTING DISPLAY INCLINE • To open the display stand, pull up on the adjustment lever and swing stand out to desired incline. Release lever to lock the stand in place. • To close the stand, pull up on the adjustment lever and gently move stand back into closed position until the latch catches.
  • Page 11 When pressure is applied to the pen tip, the pen simulates a primary mouse button click. Tip click pressure can be adjusted in the Wacom Tablet control panel. Notes: When not in use, place the pen in the pen storage compartment or lay it flat on your desk.
  • Page 12 Then install as a pen tablet. Both stages require hardware and software installations and adjustments. Carefully follow ALL instructions. Important: You MUST install the Wacom driver software for correct pen-on-screen functionality. System requirements Step 1: Display installation Step 2: Pen tablet installation...
  • Page 13 Interactive pen display Contents Index STEP 1: DISPLAY INSTALLATION In this step, the interactive pen display is installed as a monitor on your system. Important: Do not connect the USB data cable until instructed to do so. Never connect or disconnect the video or power cables while your computer or pen display are powered on.
  • Page 14 Interactive pen display Contents Index LCD monitor cabling diagram Use the DVI-I port to connect a second device, such as a projector or monitor, that mirrors the pen display. DVI or VGA – A – Analog (VGA) Fully install the hardware and software video card DVI/VGA switch Digital (DVI)
  • Page 15 U ..An update driver dialog or Wizard will appear. RIVER PDATE RIVER E) Insert the Installation CD. If the Wacom Tablet installation menu displays, close it. Windows 7 and Vista: • Select B ROWSE MY COMPUTER FOR DRIVER SOFTWARE •...
  • Page 16 Interactive pen display Contents Index 8. As necessary, configure the display control panel settings for the proper size and color resolution. See the product specifications for details about the maximum (native) resolution and other resolution sizes that can be used with your pen display. The display size and color resolution may be constrained by the capabilities of your video card.
  • Page 17 Interactive pen display Contents Index STEP 2: PEN TABLET INSTALLATION In this step, the interactive pen display is installed as a pen tablet. USB cable installation Software installation USB CABLE INSTALLATION Plug the square end of the USB cable into the USB port of the interactive pen display. Plug the other end into an available USB port on your computer or USB hub attached to your computer.
  • Page 18 Wacom pen in Windows. User-specific preferences are supported. After logging in, each user can customize their personal settings in the Wacom Tablet control panel. Switching to another user will automatically load the settings for that user.
  • Page 19 Change your position if you feel any discomfort due to your work position. Note regarding RSI: Wacom makes no representation, promise or guarantee that Wacom products will cure or prevent, in whole or in part, mouse-induced repetitive stress symptoms, injuries or conditions.
  • Page 20 Interactive pen display Contents Index USING THE PEN The pen is cordless, battery-free, and senses the amount of pressure you apply to the tip. Holding the pen Positioning Clicking Dragging Using the side switch Working with pressure sensitivity Erasing HOLDING THE PEN Hold the pen like you would a normal pen or pencil.
  • Page 21 Interactive pen display Contents Index CLICKING Tap the display screen once with the pen tip, or touch the pen to the display screen with enough pressure to register a click. Windows tip: To make navigating with the pen easier, configure Windows to select when the pen is over an icon and to launch the icon with a single click.
  • Page 22 For example, your product can be used as a pen display (the screen cursor is positioned at the pen tip location) or toggled for use as a standard Wacom tablet (the screen cursor can be moved across the entire desktop or additional displays). See working with Display Toggle for more information.
  • Page 23 Interactive pen display Contents Index ADJUSTING THE DISPLAY FACTORY PRESETS, AUTO-SYNC, AND USER SETTINGS Factory presets: For optimal display quality, set your video card to the maximum (native) resolution that can be used with your pen display. See the product specifications for details.
  • Page 24 Interactive pen display Contents Index Menu options are available when you open the On Screen Display. options allow you to choose the language in which to display ANGUAGE the OSD menu. OSD P options include: OSITION • . Adjusts the vertical position of the OSD menu window. ERTICAL •...
  • Page 25 Interactive pen display Contents Index options include: CALING • . Resizes the image to fill the whole screen. • . Resizes the image to fill as much of the screen as possible SPECT while maintaining the correct aspect ratio. • 1:1.
  • Page 26 When used with a Display Power Management Signaling (DPMS) compliant computer or video card, the display will automatically comply with the below power saving parameters. When these power-saving functions are in effect, the screen display is darker than usual. MODEL DTU-2235B Computer mode H-sync...
  • Page 27 After mastering the basics of using your pen on the interactive pen display, you may want to customize the way your product works. This chapter describes how to use the Wacom Tablet control panel to adjust your pen display and pen settings.
  • Page 28 Contents Index CONTROL PANEL OVERVIEW Use the Wacom Tablet control panel to customize the pen display. When you open the control panel, an list and the appropriate tabs are displayed. icon for the pen is displayed in the T To customize the pen and pen display, make your changes to the tab controls. Experiment with different settings to find what works best for you.
  • Page 29 Interactive pen display Contents Index Control panel lists and tabs: The control panel T , and A lists allow you to select the ABLET PPLICATION pen display or tablet, tool, or application for which you want to change settings. The T list displays an icon for any ABLET supported pen display or tablet that has been...
  • Page 30 (VGA only). 1. Open the Wacom Tablet control panel. If more than one pen display is installed on your system, select the unit you are working with from the T list.
  • Page 31 (native) resolution that can be used with your pen display. See the product specifications for details. 1. In the Wacom Tablet control panel, select the C tab. ALIBRATE 2. If you are working with multiple displays,...
  • Page 32 Index CUSTOMIZING THE PEN Customizing your pen is easy. First open the Wacom Tablet control panel using the pen. The pen will be list and the appropriate tabs will be displayed. Select a tab and choose from the selected in the T available options.
  • Page 33 Interactive pen display Contents Index ADJUSTING ERASER FEEL To adjust the eraser sensitivity of your pen, select the E tab. RASER Note: Some product configurations may include a pen without an eraser. Select the button function perform when using the eraser. Customizes the amount of pressure needed to erase.
  • Page 34 Interactive pen display Contents Index ADVANCED TIP AND ERASER PRESSURE SETTINGS To further customize tip or eraser pressure settings, select the P or E tab and click on the D RASER ETAILS dialog box enable you to change the tip or eraser pressure button.
  • Page 35 Interactive pen display Contents Index CUSTOMIZING PEN BUTTONS Select the P tab to change the functions assigned to the side switches and tip of your pen. Note: Some product configurations may include a pen without side switches. Select the button function perform when pressing the upper or lower side switch.
  • Page 36 Interactive pen display Contents Index BUTTON FUNCTIONS The following options are available for pen or Radial Menu settings. Not all options are available for all controls or pen display models. FUNCTION NAME DESCRIPTION LICKS • Simulates a primary mouse button click. Be sure at least one button performs this LICK function so you can always navigate and click.
  • Page 37 Interactive pen display Contents Index FUNCTION NAME DESCRIPTION Enables you to simulate modifier key(s) (such as S , or C for Windows, ODIFIER HIFT , and for Macintosh). Many applications use SHIFT OPTION COMMAND CONTROL modifier keys to constrain the size or placement of objects. Choose one or more modifier key options.
  • Page 38 When selected, your product can be used either as a pen display (the screen cursor is positioned at the pen tip location) or as a standard Wacom tablet (the screen cursor can be moved across the entire desktop or additional displays). See working with Display Toggle.
  • Page 39 PEED The mouse mode acceleration and speed settings are independent of system settings. Changes you make to these settings in the Wacom Tablet control panel do not affect similar system settings. However, changes made to similar system settings may affect your pen display settings.
  • Page 40 Interactive pen display Contents Index USING AND CUSTOMIZING THE RADIAL MENU To display the Radial Menu, set a pen button to the R function. Whenever you press that ADIAL button, the Radial Menu is displayed. The menu will extend over the entire desktop. •...
  • Page 41 For example, your product can be used as a pen display where the screen cursor is positioned at the pen tip location, or toggled for use as a standard Wacom tablet where the screen cursor can be moved across the entire desktop or additional displays.
  • Page 42 Interactive pen display Contents Index APPLICATION-SPECIFIC SETTINGS You can customize your pen for use with a particular application. For example, you may prefer a firm pen list enables tip pressure setting in one application and a soft pressure setting in another. The A PPLICATION you to add an individual application to the list and then customize your settings for that application.
  • Page 43 Interactive pen display Contents Index CREATING AN APPLICATION-SPECIFIC SETTING To create an application-specific setting, first choose the pen display and pen for which you want to create list’s [ + ] button to display the A an application-specific setting. Then click on the A PPLICATION dialog box.
  • Page 44 Interactive pen display Contents Index CHANGING APPLICATION-SPECIFIC SETTINGS To change pen settings for a specific application, select P and the application and then customize the tab settings. REMOVING APPLICATION-SPECIFIC SETTINGS To remove an application-specific setting: 1. In the T list, select the P .
  • Page 45 See obtaining driver downloads. 5. If you have tried the suggestions in this guide and still cannot resolve the problem, then contact Wacom for Technical Support. See the technical support options and the Read Me file for information on where to obtain support for your region.
  • Page 46 Interactive pen display Contents Index TESTING THE INTERACTIVE PEN DISPLAY 1. If the pen display power LED does not light, check the following: • First verify that the light on the power adapter is on. If the light is not on, check that the power cable is properly connected to the power adapter and to an active AC outlet.
  • Page 47 [ – ] button. After the pen has been removed, place it back onto the display screen surface and the pen will be re-added to the T list with its default settings. Open the Wacom Tablet control panel and click on the A button. In the dialog box that appears, click BOUT on the D ...
  • Page 48 Interactive pen display Contents Index DISPLAY TROUBLESHOOTING If you encounter problems with the display portion of the interactive pen display, refer to the following tables; your problem may be described here and you can try the solution offered. For additional information about color issues, see the documentation that came with your operating system or applications.
  • Page 49 Interactive pen display Contents Index An ‘out of range’ message • The input signal frequency is incorrectly set or not compatible with appears briefly on your display the interactive pen display. Set the refresh rate to a vertical screen. frequency that is compatible with your pen display. If your video card driver supports adjustment of the horizontal frequency, make sure it is also set to a compatible value.
  • Page 50 Interactive pen display Contents Index VGA PROBLEMS The display ripples or flickers. • Open the OSD menu and select the A option. DJUST Then, if necessary, manually adjust pitch and phase. • Verify that the display adapter or video card matches the specifications for the interactive pen display.
  • Page 51 Verify also that your application supports pressure sensitivity. Clicking is difficult. Open the Wacom Tablet control panel and go to the P tab. Try using a lighter T The pen selects everything or Open the Wacom Tablet control panel and go to the P tab.
  • Page 52 Double-clicking is difficult. Be sure you are quickly tapping the display screen twice in the same place on the pen display active area. Wacom recommends using the side switch to double-click. Open the Wacom Tablet control panel and go to the P tab.
  • Page 53 (0.2 inch) of the pen display active area. Do this without pressing down on the pen tip. In the Wacom Tablet control panel, verify that the side switch is set to the proper function you are expecting to occur for the application and tool you are using.
  • Page 54 WINDOWS-SPECIFIC PROBLEMS You suspect the pen display Use the Wacom Tablet Preference File Utility to work with your preferences may be preferences. Close any open applications. Click the icon and...
  • Page 55 ROFILER ARDWARE ONTENTS A Wacom USB pen display model should be listed. If a pen display model is not listed, check the pen display USB cable connection or try plugging the pen display into a different USB port. If this does not help, contact Wacom for Technical Support.
  • Page 56 YSTEM REFERENCES handwriting recognition. 4. Test the Ink function using your Wacom pen display and pen. If this procedure does not resolve your problem with Ink, contact Apple Support for further assistance. Wacom is not the software manufacturer for Ink and we are limited in our abilities to support a third party software application.
  • Page 57 Read Me file for your platform (located on the Installation CD). You can also check the product FAQs (Frequently Asked Questions) on the Wacom web site for your region. If you have an Internet connection, you can download the latest software drivers from the Wacom web site for your region. See obtaining driver downloads.
  • Page 58 Index OBTAINING DRIVER DOWNLOADS Wacom periodically updates the software driver for the tablet portion of the interactive pen display to maintain compatibility with new products. If you are having a compatibility problem between your interactive pen display and a new hardware or software product, it may be helpful to download a new Wacom software driver (when available) from the Internet.
  • Page 59 Interactive pen display Contents Index APPENDIX This section contains tips on caring for your interactive pen display, instructions on how to uninstall the software, your license and warranty, and more. Caring for the interactive pen display Replacing the pen tip Using an alternate mount or stand Uninstalling the interactive pen display Managing preferences...
  • Page 60 When the nib gets too short or develops a sharp edge, replace it with one of the extra nibs that came with the pen. Clasp the old nib with a Wacom nib Slide the end of the new nib straight extraction tool, pair of tweezers, into the barrel of the pen.
  • Page 61 VESA standard. For model DTU-2235B, the mount arm or stand must conform to the VESA 100 mm standard. Mounting screws that are 4 mm wide with a 0.7 mm pitch (M4 Regular), with a screw clearance depth of 15 mm are required.
  • Page 62 Contents Index UNINSTALLING THE INTERACTIVE PEN DISPLAY Follow the appropriate procedure below to remove the Wacom driver software and the pen display from your system. Important: When you remove the Wacom driver software from your system, your Wacom interactive pen display will no longer operate with full tablet functionality but will continue to function as a mouse device.
  • Page 63 Interactive pen display Contents Index MANAGING PREFERENCES Use the Wacom tablet preferences utility to manage your pen display preferences for a single or multiple users. For Windows, first close any open applications. Then open the utility by clicking the icon and...
  • Page 64 The eraser function will continue to work correctly using the first unit that was added to the control panel. To remove one of multiple tablets from the driver, in the Wacom Tablet control panel select the pen display or tablet icon to be deleted and click on the [ – ] button next to the T list.
  • Page 65 EVICES • Digital Ink in Microsoft Office 2007. Use your Wacom pen to full advantage with the enhanced digital mark-up and inking tools available in Microsoft Office 2007 or later applications running on Windows 7 or Vista. Found on the R...
  • Page 66 3. Customize the Input Panel settings for the way you like to work. To learn more about using your Wacom pen in Microsoft Windows and Office 2007 or later, study the documentation that came with your system and Microsoft Office applications. Be sure to take advantage of the Windows training tools, including the Tablet PC tutorial, available from Microsoft.
  • Page 67 Interactive pen display Contents Index PRODUCT SPECIFICATIONS Model DTU-2235B interactive pen display Pen (model UP-817E) Pen (model UP-818E) MODEL DTU-2235B INTERACTIVE PEN DISPLAY General specifications Display Tablet Power adapter GENERAL SPECIFICATIONS Dimensions (W x D x H) 564.0 x 374.0 x 55.5 mm (22.2 x 14.7 x 2.2 in), excluding stand Weight 7.4 kg (16.3 lb), including stand...
  • Page 68 Each interactive pen display LCD panel is produced under very stringent quality standards. Production techniques cannot guarantee an absolutely perfect TFT display. Wacom does not allow any pixel to be always white or always black. A small number of pixels (4 or less) are allowed to show a wrong color for some parts of the color spectrum.
  • Page 69 Interactive pen display Contents Index TABLET Reading technology Electromagnetic resonance method Active area 476.6 x 268.1 mm (18.78 x 10.56 in) Resolution 0.01 mm/point (2540 lpi) Accuracy ±0.5 mm (±0.02 in), center Edge area 1 (20 mm (0.79 in) wide from edge of display area) to be ±2.0 mm (±0.079 in) Edge area 2 (3 mm (0.12 in) wide from edge of display area) to be ±4.0 mm (±0.158 in) Reading height...
  • Page 70 Thailand http://www.wacom-thai.com ORDERING PARTS AND ACCESSORIES To purchase parts and accessories, refer to the Wacom pen display Read Me file and see who to call for your region. You can also do the following: To purchase parts and accessories in the USA or Canada, call 1.888.884.1870 (toll-free) or visit Wacom’s web site at http://www.WacomDirect.com (USA only).
  • Page 71 Plug the equipment and computer into an outlet that is on a different circuit from the television or radio. If necessary, consult your Wacom dealer or an experienced radio/television technician for help. Changes or modifications to this product not authorized by Wacom could void the FCC Certification and negate your authority to operate the product.
  • Page 72 - IEC61000-4-8: 2001 - IEC61000-4-11: 2004 Based on the results of these tests, Wacom declares that the above mentioned device conforms to the EMS Directive 2004/108/EC. The device must be installed and operated always in strict accordance to the instructions given in this manual.
  • Page 73 Failure to do so could cause the loss of data or damage to your computer. Failure to do so could also void your warranty, in which case Wacom shall have no responsibility to repair or replace the product.
  • Page 74 Do not connect or disconnect the video or power cables while the pen display or your computer Caution are turned on; this may damage the display or computer video card. In this case, Wacom shall have no responsibility to repair or replace the product.
  • Page 75 Wacom products are subject to the Directive 2002/96/EC and therefore you should always collect them separately and bring them to the appropriate collection point in your community or region.
  • Page 76 LIMITATION OR EXCLUSION MAY NOT APPLY TO YOU. In the event that any of the above limitations are held unenforceable, Wacom’s liability for any damages to you or any party shall not exceed the purchase price you paid, regardless of the form of any claim.
  • Page 77 Wacom repair center. In all other respects, the terms of the warranty as set forth above apply to such sales. Wacom Technical Support in Asia Pacific (except Japan and China) Detailed Asia Pacific Limited Warranty policy and product registration may be found online at http://www.wacom-asia.com...
  • Page 78 WACOM Europe GmbH ("WACOM"). This software is an integral component of the product and is also held on the associated data carrier. The software of WACOM and the associated rights of use are not included with the purchase of this product from your retailer. WACOM grants you-the user-the right to use the software exclusively in accordance with the conditions stipulated in this licence agreement.
  • Page 79 WACOM, nor for damages arising from wilful or grossly negligent behaviour on the part of WACOM, from damages leading to loss of life, personal injury or sickness or in the case of binding legal provisions.
  • Page 80 Should a provision be invalid, the legally permissible regulation most closely resembling the invalid regulation shall apply in its place. If you have any questions about this agreement, or would like to contact WACOM for another reason, please contact us by post at this address:...
  • Page 81 Journal includes a variety of pen, marker, and highlighter tools, plus an eraser that is easily activated by the eraser end of your Wacom pen. Additionally, your handwritten content is searchable within Journal.
  • Page 82 Pixel. The smallest unit of measure on your display screen. Pressure sensitive. A quality of the Wacom pen tip and eraser that senses the amount of pressure being applied. This is used to create natural-looking pen, brush, and eraser strokes in applications that are pressure sensitive.
  • Page 83 Interactive pen display Contents Index INDEX Accessories FCC notice Features available ordering Adjusting, pen display pen display Application-specific settings Front view, pen display changing Functions, button creating General problems, troubleshooting removing Holding the pen Auto-sync Incline, adjusting Button functions Industry Canada statement Information, product Calibrating, pen display Installation...
  • Page 84 On Screen Display (OSD) testing user Side switch, using using using side switch Software installation working with pressure sensitivity Specifications Pen display general about model DTU-2235B adjusting display incline tablet pitch and phase calibrating model UP-817E model UP-818E caring for cleaning power adapter...
  • Page 85 CPF Bishan Building #06-08 NSW 2116 Australia Singapore 579838 Telephone: +61.2.9422.6700 Telephone: +65.6258.8640 Fax: +61.2.9420.2272 Fax: +65.6258.8697 WACOM TAIWAN INFORMATION CO., LTD. Suite 605, 6th floor, No. 205 Tun-Hwa North Road Taipiei, 105 Taiwan Telephone: +886.2.2712.2675 Fax: +886.2.2712.9789 Contents Index...
