- Page 1 D850E D950E /R410A /R410A GB DEHUMIDIFIER D LUFTENTFEUCHTER F DÉSHUMIDIFICATEUR NL ONTVOCHTIGER...
- Page 2 THANK YOU! Thank you for choosing this innovative dehumidifier. The instruction manual describes the many benefits and advanced features that this unique product has to offer. This dehumidifier is a large capacity unit designed to run highly efficiently in places such as: restaurants, bars, printing presses, indoor swimming pools, jacuzzis, garages, animal enclosures, cellars, stores, boat sheds, weekend cottages, archives, etc.
-
Page 3: How It Works
available, one should be installed by a licenced electrician. • Any service other than regular cleaning or filter replacement should be performed by an authorized service representative. Failure to do so could result in a loss of warranty.Your dehumidifier is supplied with an electrical cable and an earthed plug. - Page 4 PARTS Filter Fig. 2 Fig. 1 Fig. 4 Dry air Back cover Moist air Wall Cooling elements Compressor Drainage Fig. 3 Fig. 5 outlet...
-
Page 5: Positioning The Dehumidifier
POSITIONING THE DEHUMIDIFIER There must be free space of at least 30 cm between any other object and the front and the top of the unit. Your dehumidifier can be installed in any area with a too high relative humidity, such as cellar, playing area, shed, archive or swimming pool. - Page 6 CONTROLS See page 4, fig. 4 ON/OFF (1) The unit is switched on and off by pressing the ON/OFF button (1). When the unit is on, the fan runs in the set speed. Humidity (2) Press the HUMIDITY button (2) repeatedly to choose the desired level of relative humidity in the area.
- Page 7 DRAINAGE There are four optional outlets for the drainage tube. To change the outlet of the drainage tube the rear panel should be dismounted (only by authorised / competent persons). When remounting the rear panel care should be taken to return all the screws and washers to their original location.
-
Page 8: Troubleshooting
TROUBLE SHOOTING If the dehumidifier does not operate: • Make sure the unit is plugged in. • Ensure the humidistat control is turned on. If the unit is noisy: • Make sure the dehumidifier is standing solidly and level. If the unit is leaking: •... -
Page 9: Wiring Diagram
MOISTURE REMOVAL • ENTFEUCHTUNG • DÉSHUMIDIFICATION • ONTVOCHTIGING For reference purposes only WIRING DIAGRAM CONTROL PANEL... - Page 10 KYOTO PROTOCOL - FLUORINATED GASES This product contains fluorinated gases covered by the Kyoto Protocol Chemical Name of the Gas R410A Global Warning Potential (GWP) of the Gas 1975 (Caution) (a) Hermetically sealed system (b) Emission of the contained fluorinated gas shall be prevented. The fluorinated gas may never be vented to the atmosphere during installation, service and disposal.
- Page 11 ECOR PRO B.V. Anton Phillipsweg 9-11 1422 AL UITHOORN The Netherlands Tel.: +31 (0)297 52 75 83 Fax: +31 (0)297 56 01 87 e-mail: info@ecor-group.com Chamber of Commerce: 34334850 Subject to modifications. / Änderungen vorbehalten. Sous réserve de modifications. / Wijzigingen voorbehouden.
