- Page 1 DH8500EW DH9500EW Dehumidifier Luftentfeuchter Déshumidificateur Ontvochtiger Deshumidificador www.ecor-pro.com...
- Page 2 This instruction manual describes the many benefits and advanced features that this unique product has to offer. The Ecor-Pro dehumidifier is a large capacity unit designed to run highly ef- ficiently in places such as: restaurants, bars, printing presses, indoor swim- ming pools, jacuzzis, garages, animal enclosures, cellars, stores, boat sheds, weekend cottages, archives, etc.
- Page 3 Any service other than regular cleaning or filter replacement should be performed by an authorized service representative. Failure to do so could result in a loss of warranty. Your Ecor-Pro dehumidifier is supplied with an electrical cable and an earthed plug. Should it be necessary to replace this plug at any time, you must use an earthed electrical plug.
-
Page 4: How It Works
HOW IT WORKS Your Ecor-Pro dehumidifier controls the Relative Humidity by passing the air through the unit forcing the excess moisture to condensate over a cooled heat exchanger. This condensate water then flows safely into a fixed drain. The dried air then passes through a final heat exchanger where it is warmed before it re-enters the room area at a slightly elevated temperature. - Page 5 There must be free space of at least 30 cm between any other object and the front and the top of the unit. Your Ecor-Pro dehumidifier can be installed in any area with a too high relative humidity, such as cellar, playing area, shed, archive or swimming pool.
-
Page 6: Wall Mounting
WALL MOUNTING The unit can stand on the floor or hang on a wall. A wall-mounting bracket is provided with your Ecor-Pro dehumidifier. Fix the supporting bracket with at least 5 screws horizontally to the wall, use the appropriate fixings for the type of wall - Note the unit is heavy approxi- mately 25kg. - Page 7 CLEANING Disconnect from the mains before cleaning the unit or any of its components. Cleaning the air filter Air circulation is impeded and the efficiency of the dehumidifying and air pu- rifying functions decreases when the filter is dirty. It is therefore good practice to clean the filter at regular intervals.
- Page 8 CONTROLS Your Ecor-Pro dehumidifier features a microprocessor based digital control system for optimal performance control. All functions are accessible via the membrane keypad shown below: Humidity & Temperature Humidity Setting Humidity Temperature Display On/Off Timer Display Select Display Adjust Select...
-
Page 9: Troubleshooting
Timer Press the ‘TIMER’ button to run the unit for a limited time period only. The selected time period (in hours) is displayed temporarily on the display panel, repeatedly pressing the button cycles through the available settings. When this mode is selected, the unit will switch itself off after the selected time pe- riod has elapsed. -
Page 10: Technical Data
TECHNICAL DATA Specifications DH8500EW DH9500EW Typical Extraction @ 30 C 85%rh 47 l /day 57 l /day Typical Extraction @ 30 C 80%rh 43 l /day 55 l /day Typical Extraction @ 27 C 60%rh 24 l /day 35 l /day...
