RECOMMENDED
FOR R&D,
PROTOTYPING,
MAINTENANCE &
REPAIR
PRECISION
CONSTRUCTION
OF DURABLE
HIGH CARBON
STEEL
ANGLED
HEAD
FOR COMFORT-
ABLE HAND &
WRIST POSITION
EXTRA
STRENGTH
PIVOT PINS FOR
GREATER
DURABILITY
RATCHET CON-
TROL ASSURES A
COMPLETE
CRIMPING
CYCLE
EMERGENCY
RATCHET
RELEASE
INTERCHANGE-
ABLE DIES ARE
AVAILABLE
DANIELS MANUFACTURING CORP., 526 THORPE ROAD, ORLANDO, FL 32824, USA
PHONE (407) 855-6161 • FAX (407) 855-6884 • WWW.DMCTOOLS.COM • E-MAIL: DMC@DMCTOOLS.COM
COPYRIGHT © ALL RIGHTS RESERVED
INSULATEDTERMINALS&SPLICES
# 24-20 AWG, # 22-18 AWG AND # 16-14 AWG
FOR DETAILS ON EMERGENCY
RATCHET RELEASE SEE
FIGURE 1.
REV. B
1
PART No. DCT4-119
3/99
FILE # DS0076
DOC. # DCT4-119-DS
