USER INSTRUCTIONS
Programmable
2-wire Transmitter
for Pt100 and Pt1000 Input
The user instruction must be read prior to adjustment and/or installation.
All information subject to change without notice.
ME ASUR E O F SUCCESS
INOR Process AB, PO Box 9125, SE-200 39 Malmö, Sweden,
Phone: +46 40 312 560, Fax: +46 40 312 570, E-mail: support@inor.se
INOR Transmitter OY, Unikkotie 13, FI-01300 Vantaa, Finland,
Phone:+358 10 421 7900, Fax: +358 10 421 7901, E-mail: myynti@inor.fi
INOR Transmitter GmbH, Am See 24, D-47279 Duisburg, Germany,
Phone: +49-203 7382 762 0, Fax: +49-203 7382 762 2, E-mail: info@inor-gmbh.de
KROHNE Temperature Division INOR, 55 Cherry Hill Drive,
Beverly, MA 01915, United States
Phone: +1 978 826 6900, Fax: +1 978 535 1720, E-mail: inor-info@krohne.com
www.inor.com, www.inor.se
This product should not be mixed with other kind of scrap, after usage.
It should be handled as an electronic/electric device.
ME ASUR E O F SUCCESS
APAQ R130 is a low cost, non-isolated, easy-to-use 2-wire
temperature transmitter for Pt100 and Pt1000 input intended to be
used in industrial environment.
The transmitter is configured from a mobile device via NFC
communication, by using the app INOR Connect. Inor Connect is
available for free download on App Store, Google Play Store and
Huawei AppGallery.
R130
Input
Pt100 (IEC 60751,
Pt1000 (IEC 60751,
Adjustments - Zero
Adjustments - Minimum span 20 °C / 36 °F
Output
Sensor failure indication
NAMUR Compliance
Response time
Ambient temperature
Storage and operation
Galvanic isolation
Power supply
Accuracy
Vibration
EMC

Configuration

Factory settings
Input
Output
Sensor error indication
Before making a configuration of APAQ R130 you need to do
following:
1. Make sure that you have a mobile device with NFC
communication activated
2. Download the app INOR Connect to your mobile device
Required versions:
iOS
iOS 13 or later and
Iphone 7 or later for NFC
Configuration procedure:
1. Launch the app by clicking on the App
icon or holding your mobile device
against the transmitter on the part of the
device where NFC is located
(only possible with Android).
2. Click on "Read Configuration" and hold
your mobile device against the trans-
mitter as explained in the first section.
3. In the app you can edit the following:
a. Sensor type and number of wires
b. Measuring range
c. Upscale or downscale
d. Filter level
e. TAG-number
f. Password
4. Once you have set the desired values in the
app, you transfer it to the transmitter by
clicking the transfer button and holding the
mobile device against the transmitter
until a green check box appears confirming
that the transfer has been completed.
G E NE R A L I NF O R M A T I O N
D A T A ( s h o rt fo r m )
2-, 3-, 4-wire connection
α
=0.00385)
-200 to +850 °C / -328 to +1562 °F
α
=0.00385)
-200 to +850 °C / -328 to +1562 °F
Any value within range limits
4-20 mA, temperature linear
Upscale (≥21.0 mA) or downscale (≤3.6 mA)
Current limitations and failure currents acc.
to NAMUR NE 43
0.4 to 26 s, adjustable filtering level
-40 to +85 °C / -40 to +185 °F
None
6 to 32 VDC
Max. ±0,15 K or ±0,15 % of span
Rail acc. to DIN EN50022, 35 mm
IEC 60068-2-6, 5 g
EN 61326-1 and EN 61326-2-3
App INOR Connect via NFC
Pt100 3W, 0 to 100 °C
4 to 20 mA
Upscale
C O NF I G UR AT I O N
Sensor error indication
Android
Android 4.4 or later
