INOR Mini IPAQ-HLP User Instructions

USER INSTRUCTIONS
Intelligent, Economy
2-wire Transmitter
The user instruction must be read prior to adjustment and/or installation.
All information subject to change without notice.
M E ASURE OF SUCCESS
INOR Process AB, PO Box 9125, SE-200 39 Malmö, Sweden,
Phone: +46(040)31 25 60, Fax: +46(040)31 25 70, E-mail: info@inor.se
INOR Transmitter OY, Unikkotie 13, FI-01300 Vantaa, Finland,
Phone:+358-10-4217900, Fax: +358-10-4217901, E-mail: jari.stadig@inor.fi
INOR Transmitter GmbH, Rodenbacher Chaussee 6,
DE-63457 Hanau-Wolfgang, Germany,
Phone: +49(0)6181-582940, Fax: +49(0)6181-582944, E-mail: inor.gmbh@t-online.de
INOR Transmitter Inc, 7 Dearborn Road, Peabody, MA 01960, USA,
Phone: +1(978) 826-6900/(262) 670-9050,
Fax: +1(978) 535-3882/(262) 670-9001, E-mail: service@inor.com
www.inor.com, www.inor.se
This product should not be mixed with other kind of scrap, after usage.
It should be handled as an electronic/electric device.
M E ASURE OF SUCCESS
GE N ER AL INF OR MA TI ON
MinIPAQ-HLP is a basic, programmable, non-isolated, easy-to-use
2-wire temperature transmitter intended to be used in industrial
environment.
The transmitter is configured from a PC via a USB port, connected
via the INOR USB Interface, by using the ConSoft program together
with the MinIPAQ Soft program.
When the transmitter is set from a PC no calibration is needed.
ConSoft is compatible with Windows 2000 (SP3), Windows XP and
Windows Vista (32-bit).
All necessary hardware and software for configuration are included
in the ICON Configuration Kit, 70CFGUS001.

DATA (shortform)

Input
Sensor failure
Adjustments - Zero
Adjustments - Minimum spans
Pt100, Pt1000, Ni100, Ni120, Ni1000
Cu10
T/C
Output
Operating temperature
Galvanic isolation
Power supply
Typical accuracy
Connection head
CO NFI GU RA T IO N
Guidelines for ConSoft version 1.1.0.2 or higher.
Before making a configuration of MinIPAQ-HLP you need to do
following:
1. Install the drivers for the INOR USB Interface.
2. Install the PC configuration software ConSoft in your PC.
3. Install the PC configuration software MinIPAQ Soft, version 1.24.00 or
higher, in your PC.
Please refer to "Installation Guide for ICON", 86BCONF004, for
detailed installation instructions. All software and guides are included in the
ICON Configuration Kit, 70CFGUS001, and can also be downloaded from the
web site www.inor.com.
Configuration procedure:
The help files in ConSoft and MinIPAQ Soft contains complete information
about the configuration procedure. Here is a short-form guide:
1. Connect the MinIPAQ-HLP to the PC via the USB Interface.
Configuration can be performed with or without connected power
supply.
2. In ConSoft, click on the upper left "Read from transmitter" button.
The software will automatically recognize the connected transmitter
and open the MinIPAQ Soft program. The MinIPAQ Soft program
will automatically find the correct communication port (first time
MinIPAQ Soft is used it will open the Com port selection window).
3. In the configuration window you can set the following parameters:
a. Input (RTD or Thermocouple type)
b. 3- or 4-wire connection (for RTD input)
c. Activation of Cold Junction Compensation (for T/C input)
d. Measuring range in three different engineering units
e. Upscale or downscale action at sensor break or short-circuit
f. Compensation for known sensor errors
g. Activation of a Low pass filter
4. The selected configuration is downloaded to the transmitter by clicking
the button "Transfer to transmitter". If the transmitter is in operation
during transmission from the PC, the transmitter output is frozen.
When the transfer is complete, the transmitter begins using the new
parameters directly.
See "Input Connections"
Upscale, downscale or off
Any value within range limits
10°C / 18°F
100°C / 180°F
2 mV
4-20 mA, temperature linear
-40 to +85°C / -40 to +185°F
No
8 to 32 VDC
±0.15 % of temperature span
DIN B or larger
