Product Overview
No.
Item
1
Alignment port (x2)
2
Docking connector
3
LAN indicator
4
Power indicator
5
Power button
*The power button's function is the same as
the power button on the tablet PC.
No.
Item
1
DC-in jack *
2
LAN (RJ-45) port
3
USB3.0 port (x2)
4
USB2.0 port (x2)
5
HDMI port
6
VGA port
7
Serial port (RS-232)
8
Audio out jack
9
Microphone in jack
* Please contact dealer for appropriate adapter.
Docking the Tablet PC
1. With screen side facing out and docking connector down, install the tablet PC into the alignment
ports on docking cradle.
U11I Office Dock
Front
Rear
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Durabook U11I Office Dock
Summary of Contents for Durabook U11I Office Dock
- Page 1 U11I Office Dock Product Overview Front Item Alignment port (x2) Docking connector LAN indicator Power indicator Power button *The power button’s function is the same as the power button on the tablet PC. Rear Item DC-in jack * LAN (RJ-45) port USB3.0 port (x2)
- Page 2 U11I Office Dock 2. Ensure the tablet PC is tightly secured to the docking cradle. Undocking the Tablet PC Use both hands to remove the tablet PC from the docking cradle. FCC Regulations This device complies with Part 15B Class B of the FCC Rules. Operation is subject to the following two...
