Idis DA-WM2100 Installation Manual

DA-WM2100 INSTALLATION MANUAL

Mounting

Mount the bracket to the wall as follows:
1
Mount bracket to the wall by using the anchors
and screws.
Connect your camera to the bracket as follows:
2
Screw the camera body
or bottom cover onto
bracket.
This manual is intended for users of the DA-WM2100 wall mounting
bracket. It includes instructions for mounting the DA-WM2100 wall
mounting bracket to a wall.
• This bracket is intended to be used with DC-D2233 series
or DC-D1212R model of camera. Do not use it with other
models of cameras.
• This installation should be performed by a qualified
service personnel in conformance to all local codes.
• You may need to reinforce the wall. If the wall is not strong
enough to support the camera, the camera may fall.
• Do not use this product for other purposes.
Bracket
<DC-D2233 Series > <DC-D1212R >
Bracket
Camera
Body
wall
Bracket
Bottom
Cover
