2.5

CC430 Wireless Network GUI

The included CC430 Wireless Network GUI is designed to provide more detailed information as well as
visual presentation of the network and device information. The GUI requires a PC USB connection from
the MSP-EXPF6137Rx Base Board. The Base Board captures all status and sensor information from the
devices (including the AP itself) and relays the prepared packets to the PC GUI. The GUI displays the
wireless network in the star topology, showing the connected and disconnected devices along with their
status information such as RSSI (relative distance from the AP), temperature, and remaining battery life.
