Important Safety Instruction
IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS – Your Safety And the Safety of Others Are Very Important.
We have provided many important safety messages throughout this manual and on your appliance.
Read all instructions before using your appliance and always obey all safety messages.
RECOGNIZE SAFETY INFORMATION
This is a safety alert symbol. This symbol alerts you to potential hazards that can kill or hurt you and
others.
UNDERSTAND SIGNAL WORDS
A signal word – DANGER, WARNING, or CAUTION – is used with the safety-alert symbol. DANGER
identifies the most serious hazards. It means you can be killed or seriously injured if you do not
immediately follow instructions. WARNING means you can be killed or seriously injured if you do not
follow instructions. CAUTION indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury.
All safety messages will inform you as to potential hazards, inform you on how to reduce the risk of
injury and as to what can occur if the instructions are not followed.
IMPORTANT: Observe all government codes and ordinances.
WARNING: For your safety, the information in this manual must be followed to minimize the risk
of fire or explosion, or to prevent property damage, personal injury or death.
-
This conversion kit must be installed by a qualified service agency in accordance with the
manufacturer's instructions and all applicable codes and requirements of the authority
having jurisdiction.
-
The qualified service agency is responsible for the proper installation of this kit.
-
The installation shall not be considered to be correct and completed until the operation of the
converted appliance is checked as specified in the manufacturer's instructions supplied with
this kit.
WARNING
Securely tighten all gas connections. If connected to LP, have a qualified
person ensure that the gas pressure does not exceed 14" water column.
Examples of a qualified person include licensed heating personnel,
authorized gas company personnel, and authorized service personnel.
FAILURE TO DO SO CAN RESULT IN DEATH, EXPLOSION, OR FIRE.
3
Advertisement
Table of Contents
Related Manuals for Smeg PU 64-LP
Summary of Contents for Smeg PU 64-LP
- Page 1 Important Safety Instruction IMPORTANT SAFETY INSTRUCTIONS READ AND SAVE THESE INSTRUCTIONS – Your Safety And the Safety of Others Are Very Important. We have provided many important safety messages throughout this manual and on your appliance. Read all instructions before using your appliance and always obey all safety messages. RECOGNIZE SAFETY INFORMATION This is a safety alert symbol.
- Page 2 Conversion Kit Check that the main gas supply line to the range is shut off and that the power supply cord is disconnected. Remove access cap “A” by using a screwdriver or a quarter, turning the access cap anti-clockwise. The gas pressure regulator has two settings which are indicated on two sides of the cap. Turn the cap and reinstall it in the regulator with "LP"...
- Page 3 Conversion Kit Remove all the burner components following the numerical sequence shown in the figure: remove all the knobs (1) by pulling them upward remove the grids (2), lifting up one of the two horizontal spokes remove the burner caps (3) and flame caps (4) with wrench A (available from authorized service centers), open the bayonet clamps on the burner rings by levering on guides B After having removed all of the above-described components, lift the surface to gain access to the...
- Page 4 Conversion Kit To adjust the cooktop for LP gas or to return to Natural Gas use, refer to the tables here below. PU 64 - Natural gas PU 64 - LP Injector Injector Ø mm Ø mm Front Right 3800 0.82 1500 Front Right...
- Page 5 Conversion Kit Loosen screw C and push air regulator D to the bottom. With a 7-mm wrench, remove nozzle E and replace it with the proper one (follow the instructions on the reference tables for the type of gas to be used). The torque wrench setting for the nozzle must not exceed 3 Nm.
- Page 6 Ensure that the power supply cord is plugged in and that the circuit breaker or house fuse has not blown. Ensure that the shut-off valve is on the "ON" position. Check operation again. If a burner does not light at this point, contact your SMEG dealer for assistance.
- Page 7 Conversion Kit Replace the components on the burner and turn the knobs on the gas tap pins. Light the burner and set it at minimum Remove the knob and turn the regulation screw inside or next to the gas tap pin (depending on the model) until you obtain a suitable minimum flame.
