1.
INSTRUCTIONS FOR USE ........................................................................... 4
2.
SAFETY PRECAUTIONS .............................................................................. 6
3.
ENVIRONMENTAL RESPONSIBILITY .......................................................... 8
4.
DESCRIPTIONS OF THE CONTROLS ......................................................... 9
5.
USING THE HOB......................................................................................... 10
6.
CLEANING AND MAINTENANCE ............................................................... 11
7.
POSITIONING OF THE HOB....................................................................... 14
8.
ADAPTATION TO DIFFERENT TYPES OF GAS........................................ 20
9.
FINAL OPERATIONS .................................................................................. 23
THESE INSTRUCTIONS ARE VALID ONLY FOR THE DESTINATION COUNTRIES
WHOSE IDENTIFYING SYMBOLS ARE INCLUDED ON THE COVER OF THIS MAN-
UAL.
INSTRUCTIONS FOR THE USER: these instructions contain user
recommendations, a description of the controls and the correct
procedures for cleaning and maintenance of the appliance.
INSTRUCTIONS FOR THE INSTALLER: these are intended for the
authorized person who must install the appliance, set it functioning and
carry out an inspection test.
Contents
3
Advertisement
Table of Contents
Related Manuals for Smeg Gas Cooktop PA106SX
Summary of Contents for Smeg Gas Cooktop PA106SX
-
Page 1: Table Of Contents
INSTRUCTIONS FOR USE ... 4 SAFETY PRECAUTIONS ... 6 ENVIRONMENTAL RESPONSIBILITY ... 8 DESCRIPTIONS OF THE CONTROLS ... 9 USING THE HOB... 10 CLEANING AND MAINTENANCE ... 11 POSITIONING OF THE HOB... 14 ADAPTATION TO DIFFERENT TYPES OF GAS... 20 FINAL OPERATIONS ... -
Page 2: Instructions For Use
General instructions 1. INSTRUCTIONS FOR USE THIS MANUAL CONSTITUTES AN INTEGRAL PART OF THE APPLIANCE. THIS MANUAL CONSTITUTES AN INTEGRAL PART OF THE APPLIANCE. IT SHOULD BE KEPT INTACT AND AT HAND FOR THE APPLIANCE’S ENTIRE LIFE CYCLE. IT IS IMPORTANT TO CAREFULLY READ THIS MANUAL AND ALL THE INSTRUCTIONS CONTAINED HEREIN... -
Page 3: General Instructions
General instructions NEVER USE PANS OR GRIDDLE PLATES WHICH PROJECT BEYOND THE OUTSIDE EDGE OF THE HOB. SUITABLE HEAT-PROOF GLOVES SHOULD BE WORN FOR ALL OPERATIONS. DO NOT USE OR STORE FLAMMABLE MATERIALS IN THE APPLIANCE STORAGE DRAWER OR NEAR THIS APPLIANCE. THIS APPLIANCE IS DESIGNED FOR COOKING FOOD AND IT SHALL NOT BE USED AS A SPACE HEATER. -
Page 4: Safety Precautions
General instructions 2. SAFETY PRECAUTIONS REFER TO THE INSTALLATION INSTRUCTIONS FOR THE SAFETY REGULATIONS FOR ELECTRIC OR GAS APPLIANCES AND VENTILATION FUNCTIONS. IN YOUR INTERESTS AND FOR YOUR SAFETY THE LAW REQUIRES THAT THE INSTALLATION AND SERVICING OF ALL ELECTRICAL APPLIANCES IS CARRIED OUT BY QUALIFIED PERSONNEL IN ACCORDANCE WITH THE REGULATIONS IN FORCE. - Page 5 General instructions DO NOT LET CHILDREN GO NEAR THE APPLIANCE WHEN IT IS IN OPERATION OR PLAY WITH IT AT ANY TIME. DO NOT INSERT POINTED METAL OBJECTS (CUTLERY OR UTENSILS) INTO THE SLITS IN THE APPLIANCE. DO NOT USE STEAM JETS FOR CLEANING THE APPLIANCE. THE STEAM COULD REACH THE ELECTRONICS, DAMAGING THEM AND CAUSING SHORT-CIRCUITS.
-
Page 6: Environmental Responsibility
Instructions for disposal 3. ENVIRONMENTAL RESPONSIBILITY Our products packing is made of non-polluting materials, which are therefore compatible with the environment and recyclable. Please help by disposing of the packaging correctly. You can obtain the addresses of collection, recycling and disposal centres from your retailer or from the competent local organisations. -
Page 7: Descriptions Of The Controls
Instructions for the user 4. DESCRIPTIONS OF THE CONTROLS Front control panel All of the commands and controls for the hob are found on the front panel. MODEL 60 CONTROL PANEL MODEL 70 CONTROL PANEL MODEL 100 CONTROL PANEL DESCRIPTION OF THE KNOB The flame is lit by pressing the knob and simultaneously turning it anticlockwise to the minimum flame symbol To adjust the flame, turn the knob to the zone between... -
Page 8: Using The Hob
Instructions for the user 5. USING THE HOB Check that the flame crowns, the burner caps and grids are correctly assembled. Pins A of the flame crowns must be inserted in housings B of the burner rings, and pins C on the grids must be blocked in their respective housings on the hob. -
Page 9: Cleaning And Maintenance
Instructions for the user 6. CLEANING AND MAINTENANCE Before performing any operations requiring access to powered parts, switch off the power supply to the appliance. NEVER USE A STEAM JET FOR CLEANING THE APPLIANCE. Cleaning stainless steel To keep stainless steel in good condition it should be cleaned regularly after use. - Page 10 Instructions for the user 6.2.3 Grids and burners cap In normal use of the hob, the grids and burner caps normally get browned as a result of the high temperature. For optimum cleaning remove the burner cap and lift up one of the horizontal spokes of the grid to remove it from its housing.
- Page 11 Instructions for the user Problems and causes Each of the following cases is caused by an abhnormal operation of the appliance and should be dealt with by an authorised person: please contact your local dealer or Service Center in case you detect any of these malfunctioning.
-
Page 12: Positioning Of The Hob
Instructions for the installer 7. POSITIONING OF THE HOB The following operation requires building and/or carpentry work so must be carried out by a competent tradesman. Installation can be carried out on various materials such as masonry, metal, solid wood or plastic laminated wood as long as they are heat resistant (T 90°C). - Page 13 Instructions for the installer Carefully position the insulation gasket (supplied) on the external perimeter of the hole made in the top surface (see figures below) and try to make it stick to the entire surface by applying light pressure with your hands. Refer to the distances shown in the figure for the model to be installed, keeping in mind that for both models the long front side has to skim the hole.
-
Page 14: Clearances Above And Around Domestic Appliances
Instructions for the installer Clearances above and around domestic appliances Extract from AS5601 REQUIREMENTS Overhead clearances – (Measurement A) Range hoods and exhaust fans shall be installed in accordance with the manufacturer’s instructions. However, in no case shall the clearance between the highest part of the hob of the cooking appliance and a range hood be less than 600 mm or, for an overhead exhaust fan, 750 mm. - Page 15 Instructions for the installer NOTES Requirement 3 does not apply to a freestanding or elevated cooking appliance which is designed to prevent flames or the cooking vessels from extending beyond the periphery of the appliance. The ‘cooking surface area’ is defined as that part of the appliance where cooking normally takes place and does not include those parts of the appliance containing control knobs.
- Page 16 Instructions for the installer Gas connection This appliance is suitable for installation with Natural Gas or ULPG (propane/butane). Refer to page 25 for the relevant burner pressure and appropriate injector sizes. When the appliance is to be connected to Natural Gas then the pressure regulator supplied must be fitted to the gas inlet.
- Page 17 Instructions for the installer Installation with the flexible hose must be carried out so that the length of the piping does not exceed 2 metres fully extended; make sure that the hoses do not come into contact with moving parts and that they are not crushed in any way.
-
Page 18: Adaptation To Different Types Of Gas
Instructions for the installer 8. ADAPTATION TO DIFFERENT TYPES OF GAS Before carrying out the following operations, disconnect the appliance from the power supply. The appliance is preset for natural gas NG at a pressure of 1.0 kPa. In the case of operation with other types of gas, the burner nozzles must be changed and the minimum flame adjusted on the gas taps. - Page 19 Instructions for the installer Adjustment for ULPG Check that the connection has been made as described in the “Gas connection” section. Undo the screw “C” and push the air regulator “D” fully down. Use a spanner to remove the nozzles “E”...
- Page 20 Instructions for the installer Burner Auxiliary (1) Semi rapid (2) Medium rapid (3) Large rapid (4) Ultra rapid (5) Primary air adjustment efers to distance “X” in mm. BURNER Auxiliary Semi rapid Medium rapid Large rapid Ultra rapid To identify the burners on your hob, please refer to the illustrations in paragraph “9.4 Arrangement of the burners on the hob”.
-
Page 21: Final Operations
Instructions for the installer 9. FINAL OPERATIONS Follow the instructions given in paragraph “5.1 Removing the hob”, but in the reverse order. When replacing the burner rings, remember that they have to be tightened completely by means of the wrench supplied, otherwise the flame interruption zones on the flame crowns will not be aligned with the grid spokes. - Page 22 Instructions for the installer Arrangement of the burners on the hob BURNERS 1 Auxiliary 2 Semi rapid 3 Medium rapid 4 Large rapid 5 Ultra rapid When replacing the burner rings, remember that they have to be tightened completely by means of the wrench supplied, otherwise the flame interruption zones on the flame crowns will not be aligned with the grid spokes.
