PARTS LIST
bottom panel
has pre-drilled
holes on both
sides
Bottom Panel
WWW.BLUDOT.COM
WWW.BLUDOT.COM
MODULICIOUS
BEDSIDE TABLE
ASSEMBLY INSTRUCTIONS
CARE
Clean with a slightly damp,
soft cloth. To remove dirt
and fingerprints, use a
quality cleaner formulated
for wood furniture. Wipe
completely dry with a soft
cloth in the direction of the
x1
wood grain.
Shelf Panel
x1
x1
Top Panel
x1
x2
Back Panel
Foot
x2
x4
Side Panel
Drawer Slide
HARDWARE
x24
5002
x1
8018
x1
Stretcher
x4
1023
x2
Drawer
MODULICIOUS Bedside Table rev02 - PAGE 1 OF 6
x24
5001
x16
5005
x4
4005
