Fujitsu LifeBook

N Series
BIOS Guide
LifeBook N Series Models:
N6110
Document Date: 10/21/2005
Document Part Number: FPC58-1431-01
F U J I T S U
C O M P U T E R
S Y S T E M S
1

Advertisement

Table of Contents
loading

Related Manuals for Fujitsu Lifebook N6110

Summary of Contents for Fujitsu Lifebook N6110

  • Page 1: Fujitsu Lifebook

    Fujitsu LifeBook N Series BIOS Guide LifeBook N Series Models: N6110 Document Date: 10/21/2005 Document Part Number: FPC58-1431-01 F U J I T S U C O M P U T E R S Y S T E M S...

  • Page 2: N Series Bios

    To enter the BIOS Setup Utility do the following: 1. Turn on or restart your notebook. 2. Press the [F2] key once the Fujitsu logo appears on the screen. This will open the main menu of the BIOS Setup Utility with the current settings displayed.
  • Page 3 3. If an error message is displayed on the screen, and you want to enter the setup utility, press the [F2] key. 4. When the setup utility starts with a fault present, the system displays the following message: Warning! Error message [Continue] 5.

  • Page 4: Main Menu - Setting Standard System Parameters

    PhoenixBIOS Setup Utility Security Boot Info Exit [14:57:01] [10/21/2005] [FUJITSU MHV2100AT-(PM)] [HL-DT-ST DVDRAM GMA-4080N-(P] [None] [English (US)] -/Space Change Values Enter Select Sub-Menu Figure 1. Main Menu...
  • Page 5 Table 1: Fields, Options and Defaults for the Main Menu Note that the parameters listed in the following table may vary depending upon your system’s configuration. Menu Field Options Primary Master: Selects Primary Master submenu Primary Slave Selects Primary Slave submenu Serial ATA Port 0 Selects Serial ATA Port 0 submenu...
  • Page 6 L i f e B o o k N S e r i e s N o t e b o o k B I O S Primary Master Submenu of the Main Menu The Primary Master submenu identifies what ATA devices are installed. Main Primary Master [FUJITSU MHV2100AT-(PM)] Type: Total Sectors: Maximum Capacity:...
  • Page 7 Table 2: Fields, Options and Defaults for the Primary Master Submenu of the Main Menu Menu Field Options ■ Transfer Mode: Standard ■ Fast PIO 1 ■ Fast PIO 2 ■ Fast PIO 3 ■ Fast PIO 4 ■ FPIO 3 / DMA 1 ■...
  • Page 8 L i f e B o o k N S e r i e s N o t e b o o k B I O S Primary Slave Submenu of the Main Menu The Primary Slave submenu allows you to configure secondary ATA devices. Main Primary Slave [HL-DT-ST DVDRAM GMA-4080N-(PS)] Type:...
  • Page 9 Table 3: Fields, Options and Defaults for the Primary Slave Submenu of the Main Menu Menu Field Options ■ Maximum Display only Capacity: ■ Multi-Sector Disabled Transfers: ■ 2 Sectors ■ 4 Sectors ■ 8 Sectors ■ 16 Sectors ■ LBA Mode Disabled Control:...
  • Page 10 L i f e B o o k N S e r i e s N o t e b o o k B I O S Serial ATA Port 0 Submenu of the Main Menu The Serial ATA Port 0 submenu indicates whether serial ATA Port 0 devices are auto-typed at boot time. Main Serial ATA Port 0 [None] Type:...

  • Page 11: Advanced Menu - Setting Device Feature Controls

    ADVANCED MENU – SETTING DEVICE FEATURE CONTROLS The Advanced Menu allows you to: Set the keyboard and mouse features. ■ Select between the display panel and an external ■ CRT display or video projector. Enable or disable compensation for your display. ■...
  • Page 12 L i f e B o o k N S e r i e s N o t e b o o k B I O S Table 5: Fields, Options and Defaults for the Advanced Menu Menu Field Description USB Features When selected, opens the USB Features submenu to allow you to enable or disable the legacy support and SCSI SubClass support (e.g., floppy disk drive, external optical drive).
  • Page 13 Keyboard Features Submenu of the Advanced Menu The Keyboard Features submenu is for enabling or disabling the NumLock feature. Main Advanced Keyboard Features Numlock: Help Exit Table 6: Fields, Options and Defaults for the Keyboard Submenu of the Advanced Menu Menu Field Options ■...

  • Page 14: Video Features Submenu Of The Advanced Menu

    L i f e B o o k N S e r i e s N o t e b o o k B I O S Video Features Submenu of the Advanced Menu The Video Features Submenu is for setting the display parameters. Main Advanced Display:...

  • Page 15: Internal Device Configurations Submenu Of The Advanced Menu

    Internal Device Configurations Submenu of the Advanced Menu The Internal Device Configuration submenu allows the user to configure other internal devices. Main Advanced Internal Devices Configurations Serial ATA Controller: IDE Controller: LAN Controller: Help Exit Table 8: Fields, Options and Defaults for the Internal Device Configuration Submenu of the Advanced Menu Menu Field Options ■...

  • Page 16: Cpu Features Submenu Of The Advanced Menu

    L i f e B o o k N S e r i e s N o t e b o o k B I O S CPU Features Submenu of the Advanced Menu The CPU Features Submenu provides options for enabling or disabling the SpeedStep® Technology feature. Main Advanced SpeedStep(R) Technology:...
  • Page 17 Table 9: Fields, Options and Defaults for the CPU Features Submenu of the Advanced Menu Menu Field Options ■ XD Bit Disabled functionality: ■ Enabled Default Description [Enabled] Allows the user to enable and disable the Execute Disable Bit functionality. Execute Disable Bit allows the processor to classify areas in memory where application code can and cannot execute.

  • Page 18: Usb Features Submenu Of The Advanced Menu

    L i f e B o o k N S e r i e s N o t e b o o k B I O S USB Features Submenu of the Advanced Menu The USB Features Submenu provides options for enabling or disabling legacy USB support. Main Advanced Legacy USB Support:...

  • Page 19: Miscellaneous Configurations Submenu Of The Advanced Menu

    Miscellaneous Configurations Submenu of the Advanced Menu The Miscellaneous Configurations Submenu provides options for enabling or disabling the power button, the Wake Up On LAN feature, and the Wake Up On USB feature, and for enabling or disabling the system beep. Main Advanced Miscellaneous Configurations...

  • Page 20: Event Logging Submenu Of The Advanced Menu

    L i f e B o o k N S e r i e s N o t e b o o k B I O S Event Logging Submenu of the Advanced Menu The Event Logging Submenu configures event logging features for DMI events. Main Advanced Event Log Capacity:...

  • Page 21: Security Menu - Setting The Security Features

    SECURITY MENU – SETTING THE SECURITY FEATURES The Security menu allows you to set up the data security features of your notebook to fit your operating needs and to view the current security configuration. Follow the instructions for Navigating Through the Setup Utility to make any changes.

  • Page 22: Menu Field

    L i f e B o o k N S e r i e s N o t e b o o k B I O S Table 13: Fields, Options and Defaults for the Security Menu Menu Field Options Supervisor –—...

  • Page 23: Hard Disk Security Submenu Of The Security Menu

    Hard Disk Security Submenu of the Security Menu The Hard Disk Security Submenu is for configuring hard disk security features. Main Advanced Primary Master Password Is: Serial ATA Port 0 Password Is: Set Primary Master Password: Set Serial ATA Port 0 Password: Password Entry on Boot: Help Exit...

  • Page 24: Owner Information Submenu Of The Security Menu

    L i f e B o o k N S e r i e s N o t e b o o k B I O S Owner Information Submenu of the Security Menu The Owner Information Submenu is for setting owner information. Note that the owner information and foreground and background colors cannot be set without having entered a Supervisor password.

  • Page 25: Boot Menu - Selecting The Operating System Source

    Turns on and off booting with a truncated set of Power On Self Test. (Fewer tests mean faster turn on.) [Disabled] Turns on and off display of test results instead of Fujitsu logo screen during Power On Self Test. [Enabled] This field is not active unless the Supervisor’s Password has...

  • Page 26: Boot Device Priority Submenu Of The Boot Menu

    1. Insert the drive into a USB port and power up the system. 2. When the Fujitsu logo appears, press the [F2] key. 3. Go to the Boot tab and scroll down to Boot Device Priority and press the [Enter] key.
  • Page 27 Table 17: Fields, Options and Defaults for the Boot Device Priority Submenu of the Boot Menu Menu Field Description +Floppy Disk Drive The boot selections determine the order in which the BIOS searches for the operating system during a startup sequence.

  • Page 28: Info Menu - Displays Basic System Information

    L i f e B o o k N S e r i e s N o t e b o o k B I O S INFO MENU - DISPLAYS BASIC SYSTEM INFORMATION The Info menu is a display only screens that provides the configuration information for your notebook.

  • Page 29: Exit Menu - Leaving The Setup Utility

    EXIT MENU – LEAVING THE SETUP UTILITY The Exit Menu is used to leave the setup utility. Follow the instructions for Navigating Through the Setup Utility to make any changes. (See Navigating Through The Setup Utility on page 2 for more information.) Main Exit Saving Changes Exit Discarding Changes...
