F u j i t s u
Remote Control User's Guide
I N S T R U C T I O N S
This user's guide contains information on using the Fujitsu Remote
Control with systems running Microsoft® Windows® XP Media
Center Edition as the operating system. The remote control can be
used with a system running Windows XP Media Center Edition,
whether the system has an internal TV tuner or not.
You are strongly advised to read this manual to familiarize yourself
with the features of the remote control.
Determining Your System Configuration
Your remote control can be used with your computer whether you
have a TV tuner or not. If you do not have a TV tuner, you can use
the remote control to operate the Windows XP Media Center
Edition features, such as playing DVDs, listening to music, or
viewing digital photo albums.
If you have a TV tuner installed, you can use the remote to control
the channel and volume, pause live TV, and record TV programs.
Figures 1, 2, and 3 illustrate the three ways your system can be
configured:
No TV Tuner
■
■
TV Tuner with direct signal
■
TV Tuner with signal routed through set-top box
C o m p u t e r
S y s t e m s
Advertisement
Related Manuals for Fujitsu N6110 - LifeBook - Pentium M 1.86 GHz
Summary of Contents for Fujitsu N6110 - LifeBook - Pentium M 1.86 GHz
- Page 1 Remote Control User’s Guide I N S T R U C T I O N S This user’s guide contains information on using the Fujitsu Remote Control with systems running Microsoft® Windows® XP Media Center Edition as the operating system. The remote control can be used with a system running Windows XP Media Center Edition, whether the system has an internal TV tuner or not.
- Page 2 To dedicated USB port Remote Control IR Receiver Remote Control Figure 1. Configuration with no TV Tuner RF Coaxial cable to cable connector or antenna To designated USB port Antenna Adapter Cable Remote Control IR Receiver Remote Control Figure 2. Configuration with TV Tuner and Direct Signal...
- Page 3 RF Coaxial cable to cable connector or antenna Set-top box RF Coaxial cable to TV signal out jack Infrared Blaster Remote Control IR Receiver Antenna To designated Adapter USB port Cable Remote Control Figure 3. Configuration with TV Tuner and Routed Signal Items included in Remote Control Package Before using the remote control, make sure the following items are included in the remote control package (Figure 4).
- Page 4 2 AA Alkaline Optical Remote Batteries Control IR Receiver Remote IR Blaster Cable Control Figure 4. Remote Control and Accessories Use only the remote control that came with ■ this package when operating Media Center Edition. No cables or accessories other than those ■...
-
Page 5: Installing Batteries
Installing Batteries Properly insert batteries using the correct ■ polarities (+, -). If they are incorrectly inserted, damage to the remote control could result. If you do not intend to use the remote ■ Warning control for an extended period of time, remove the batteries. - Page 6 Connecting optical remote control IR receiver The USB ports that can be used to connect the optical remote control IR receiver cable are labeled “IR Remote”. Use only the labeled ports to ensure optimal performance of the remote control. Connect the USB connector on the end of the remote control to one of the USB ports on your computer that are labeled “IR Remote”...
- Page 7 Connecting infrared control cable The infrared control cable is for when you are using a television connected to a set-top box, such as a cable vision box. The cable should be installed covering the infrared receiver of the set-top box. Connect the infrared control cable to either of the jacks on the rear side of the optical remote control receiver.
- Page 8 Infrared control cable Light emitter Infrared receiver Set-top box Figure 9. Applying light emitter to set-top receiver To optical remote control receiver Figure 10. Set-top box with light emitter attached...
- Page 9 BIOS. To do so, perform the following steps: 1. Turn on or restart your notebook. 2. Press the [F2] key once the Fujitsu logo appears on the screen. This will open the main menu of the BIOS Setup Utility with the current settings displayed.
-
Page 10: Using The Remote Control
Using the remote control To use the remote control to operate Media Center Edition, you must use the remote control receiver included with the remote control. The system infrared port cannot be used to operate the remote control. Note the following when using the remote control: The receiver should be placed in a location where it is not ■... - Page 11 Effective distance/location for remote control (Figure 11) Horizontal (left and right from center-point): Approximately 45 degrees Vertical (left and right from center-point): Approximately 45 degrees Distance from remote control to receiver: 3 meters max. 3 meters 3 meters Figure 11. Effective distance/location of remote control...
-
Page 12: Remote Control Features
Remote control features Each button on the remote control is explained in this section. Figure 12. Remote control buttons... - Page 13 Label Purpose Pressing this button displays the “My Pic- Pictures tures” menu on the screen. Pressing this button displays the “My My Music Music” menu on the screen. Pressing this button displays the “My TV” My TV menu on the screen. Pressing this button while in television Record mode brings up a menu from which you...
- Page 14 Label Purpose Pressing this button will clear the numbers Clear or letters input on the screen one by one. Pressing this button while the computer is active will normally put the computer into standby. Pressing this button while the computer is in standby will take the com- puter out of standby.
- Page 15 Label Purpose Pressing this button will cause the program Skip or DVD being viewed to jump to the next chapter. Pressing this button will display all relevant More information on replaying DVD-VIDEO, CD music, or recorded programs on screen. Pressing this button will select or execute the item where the cursor is placed.
- Page 16 For technical support call 1-800-8fujitsu or send e-mail to: 8fujitsu@us.fujitsu.com Fujitsu and the Fujitsu logo are registered trademarks of Fujitsu, Ltd. Microsoft and Windows are registered trademarks of the Microsoft Corporation. All other trademarks mentioned herein are the property of their respective owners.
