- Page 1 ROS SCE-X 36:1 COLOR ZOOM CAMERA OPERATION AND MAINTENANCE MANUAL SERIAL NUMBER: __________ SALES ORDER: __________ 5618 Copley Drive San Diego, CA 92111-7902 TEL: (858) 565-8500 FAX: (858) 565-8808 www.rosys.com 53-04127A 05FEB08...
- Page 2 STANDARD ORDERING FORMAT FOR THE SCE-X-36 CAMERAS 53-04127A 05FEB08...
-
Page 3: Table Of Contents
TABLE OF CONTENTS WARRANTY ........................... V CUSTOMER ASSISTANCE ......................VI CHANGE RECORD ........................VII DESCRIPTION ........................1 SCE-X, 36:1 CAMERA SPECIFICATIONS ................3 POWER ............................3 CAMERA PERFORMANCE DATA ....................3 DIMENSIONS ..........................4 WEIGHT ( ) ......................4 LESS CONNECTOR MATERIALS .......................... - Page 4 CAMERA OPERATIONAL CHECKS ..................19 CAMERA TROUBLESHOOTING ....................19 MAINTENANCE ........................21 APPENDIX ............................ 22 53-04127A 05FEB08...
-
Page 5: Warranty
(d) This warranty shall be governed by the laws of the State of California. In the event the defect is determined to be within the terms of this warranty, then ROS agrees to repair and/or replace (at ROS' discretion) the product or defective portion at no charge to the Purchaser. -
Page 6: Customer Assistance
CUSTOMER ASSISTANCE ROS, Inc. uses a worldwide network of stocking distributors and representatives who are familiar with our products and are able to provide assistance during installation and/or operation of these products. If you have any questions or problems with this product that are not covered by this manual or instruction, please contact our agent in your area, or contact us directly by phone or fax or email. -
Page 7: Change Record
CHANGE RECORD DESCRIPTION DATE Initial Release 05FEB08,BAL 53-04127A 05FEB08... -
Page 8: Description
1 DESCRIPTION The SCE-X, 36:1 is a high performance miniature Color Zoom camera intended for use in shallow water applications. The SCE-X, 36:1 is rated to 70 meters water depth. The camera has been designed from the outset with an eye towards simple, straightforward operation and maintenance. - Page 9 Focus position, Zoom position, and Exposure Settings. A wiring diagram (Drawing No. 53-04126) outlining the basic interconnections within the SCE-X, 36:1 Camera is included in the Appendix of this manual. 53-04127A 05FEB08...
-
Page 10: Sce-X, 36:1 Camera Specifications
SCE-X, 36:1 CAMERA SPECIFICATIONS POWER Operating voltage: 11 - 30 VDC, 350mA (max) CAMERA PERFORMANCE DATA Sensor: 1/4" EXview HAD CCD Pixels: 380,000 (NTSC) 440,000 (PAL) Resolution: 470 TVL minimum (NTSC) 460 TVL minimum (PAL) Scene illumination: 1/60s mode: 1.4 lux typical Signal to Noise Ratio: >50 Db... -
Page 11: Dimensions
ENVIRONMENTAL Operating Temperature: 0ºC to +50 C (32ºF to 122ºF) Storage Temperature: C to +60 Depth Rating: 70 m (230 ft) STANDARD SCE-X CONNECTORS 2.7.1 Impulse AG-306 Endbell Connector: IMPULSE AG-306 Inline Mating Connector: IMPULSE AG-206 with sleeve Pin 1... -
Page 12: Camera Interconnections
Differential modes of operation. 2.8.2 Cameras with RS-232 Control (Option) SCE-X, 36:1s can be furnished with interconnections for remote control from a computer terminal or any device that can send RS-232 messages. On these cameras all of the operating functions including focus, zoom and exposure can be controlled from the computer through two conductors, utilizing standard RS-232 serial data communication. -
Page 13: Other Configurations
2.8.2 above and 3.6 below. CAMERA MODE SELECTION The SCE-X, 36:1 Camera is designed to operate in a variety of operating modes that determine what input control signals are required and what output signals will be delivered. The selection of operating modes is normally made at the factory and may on occasion require changing at the customer facilities. - Page 14 accomplish these changes. The internal electronics assembly must be temporarily removed from the housing and changes made. The Mode Selection Board is clearly accessible so that the switches can be operated easily. There are two separate DIP switch assemblies on the board labeled S1 and S2. S1 has 8 and S2 has 6 individual switches.
- Page 15 53-04127A 05FEB08...
- Page 16 The following illustrations show several typical combinations of mode selection with the corresponding switch positions: SELECTION: BIPOLAR INPUTS 1 2 3 4 5 6 7 8 SELECTION: UNIPOLAR (OR DIFFERENTIAL) INPUTS SELECTION: BIPOLAR INPUTS & BAL VID OUTPUT SELECTION: UNIPOLAR (OR DIFFERENTIAL) INPUTS AND BALANCED VIDEO OUTPUT 4 5 6 SELECTION: RS-232 CONTROL...
-
Page 17: Camera Operation
EXPOSURE CONTROL The SCE-X, 36:1 camera provides operation over a wide range of scene illumination. To achieve this wide range the camera achieves Exposure Control through composite operation of the iris, video gain, and shutter modes. For most operations automatic exposure mode is used to optimize the camera for the existing illumination. -
Page 18: Zoom Control
Angle position in air, the MOD is the front window. FOCUS CONTROL The SCE-X, 36:1 camera is normally energized and normally operated in Auto-Focus mode. This provides nearly ideal focusing when the camera is aimed at different scenes and tracks while the zoom control is actuated. In some instances where there are objects in a scene at different distances and there is a need for focusing on specific objects, operation in a Manual Focus Mode may be required. -
Page 19: Image Flip Control
Again, some users may prefer to develop their own software allowing customized and added sophistication. LONG LINE AMPLIFICATION (LLA) As delivered, the SCE-X, 36:1 camera is set up for normal composite video output over a relatively short length (<500-ft) of coaxial cable, typically RG-59/U. 53-04127A 05FEB08... -
Page 20: Adjust Lla In Bipolar/Unipolar/Differential Mode
RF carriers in a commercial home cable TV network. These RF cables are not suitable for baseband video of the type generated by the SCE-X, 36:1 camera. The GOOD QUALITY RG-59 cables for this camera must be selected with good performance in video transmission. -
Page 21: Adjust Lla In Rs-232 Mode
As described in the Computer Control section, the camera can be configured to be controlled via RS-232 commands. When the camera is operated in this configuration, some RS-232 commands can be sent in order to query and adjust the LLA setting. Please Contact ROS for more details. 3.10 OVERLAY CONTROL The camera overlay can be turned off or displayed at different positions on the screen. - Page 22 Each new setting is saved in the flash memory of the microcontroller interface and the overlay position is retained through power cycles. Upon power up the camera overlay will display the current mode of operation (e.g. BIPOLAR). After all settings are displayed the camera overlay will go off. NOTE: Even in the OFF mode, the overlay will automatically be activated when the user enters LLA adjust mode (in the upper left corner).
-
Page 23: Theory Of Operation
Board assemblies are shown on Wiring Diagram (Drawing 51-11106). 4.1.1 Reverse Polarity Protection Power to the SCE-X, 36:1 camera is received through pin 3 with respect to pin 1 of universal interface connector J1. CR1 serves as a steering diode to prevent damage from accidentally reversed power connections to the camera. -
Page 24: Video Signals
incoming control signals. The outputs of the inverters are logic levels and are sent to a microcontroller. The microcontroller decodes the logic signals and sends RS- 232 messages to the camera module to enable the selected control function. The microcontroller messages to the camera are conditioned by the MAX332 (U5) and then sent to the camera through J7 pins 5 and 6. -
Page 25: Microcontroller
Many times a quick call to the ROS Technical Support Department will help in restoring operation with minimum effort. Most failures in the field turn out to be cabling problems, and the camera is typically the least likely cause. -
Page 26: Camera Disassembly
This is normally Pin 2 on the standard connector, and exits the ROS controller on the middle pin of the BNC connector on the rear panel. Normal resistance should only be a few ohms unless the system cable is extremely long. - Page 27 11 VDC < Input Voltage < 30 VDC Variations in voltage from those tabulated above may be helpful in analyzing a fault. If camera operation is less than satisfactory at this point, ROS's Technical Services Department should be contacted for assistance.
-
Page 28: Maintenance
6 MAINTENANCE Maintenance of the camera is typically limited to cleaning, and maintenance of the O-ring seals on the window and rear end plate. The acrylic window should only be cleaned with a commercial lens cleaner or with a mild soap and water. Use only a soft cloth or lens tissue to avoid scratching the surfaces. -
Page 29: Appendix
APPENDIX SCE-X 36:1 CAMERA DRAWINGS 53-04125 Top Assembly, SCE-X, 36:1 53-04128 Installation, SCE-X, 36:1 53-04126 Wiring Diagram, SCE-X 36:1 52-26634 Protocol, RS-232 Communication, UIB 53-04127A 05FEB08...
