- Page 1 ROS Lightning OPERATION AND MAINTENANCE MANUAL 5618 Copley Drive San Diego, CA 92111-7902 TEL: (858) 565-8500 FAX: (858) 565-8808 www.rosys.com 10-00640 REV A...
-
Page 2: Table Of Contents
TABLE OF CONTENTS WARRANTY ........................III CUSTOMER ASSISTANCE ................... IV CHANGE RECORD ......................1 WARNINGS ......................2 DESCRIPTION ......................2 PART NUMBER CONFIGURATION ............... 3 PRODUCT SPECIFICATIONS ................2 ................... 2 ENERAL PECIFICATIONS ......................3 IGHT UTPUT INSTALLATION/ GENERAL FUNCTIONALITY............3 CONNECTOR WIRING/CONFIGURATIONS ............ -
Page 3: Warranty
The laws of the State of California shall govern this warranty. In the event the defect is determined to be within the terms of this warranty then ROS agrees to repair and/or replace (at ROS' discretion) the product or defective portion at no charge to the Purchaser. -
Page 4: Customer Assistance
CUSTOMER ASSISTANCE ROS, Inc. uses a worldwide network of stocking distributors and representatives who are familiar with our products and are able to provide assistance during installation and/or operation of these products. If you have any questions or problems with this product that are not covered by this manual or instruction, please contact our agent in your area, or contact us directly by phone or FAX or e-mail. -
Page 5: Change Record
CHANGE RECORD DESCRIPTION DATE SEE EC-01258 12DEC12 SEE EC-01564 15APR13 10-00640 REV A... -
Page 6: Warnings
LEDs on the market; which when integrated with various 6000m housing options makes it the most flexible light on the market. Available in power inputs from 24VDC up to 120VAC, the ROS Lightning will support many power inputs. At these various power inputs the lamp typically draws about 150 watts of power and generates an astounding 10,000 lumens. -
Page 7: Part Number Configuration
3 PART NUMBER CONFIGURATION FLOOD PART OR SPOT DIMMING MATERIAL POWER CONNECTOR NUMBER CONTROL 10-20075 A = ALUMINUM 1 = 24VDC F=FLOOD A=0-5 VDC 2 = 120VAC S=SPOT 01=MCBH-4-MP SS SUBCONN B=0-10 VDC 02=LPMBH-4-MP BRASS IMPULSE 03=BH-4-MP BRASS SUBCONN C=RS485* 04=SEANET 101 SS SCHILLING 07=5507-1503 SS SEACON D=PHASE... -
Page 8: Product Specifications
24VDC – RS-485, 0-5VDC, 0-10VDC, Dimming Control Modes None (full on) 120VAC – Phase Control, 0-5VDC, 0-10VDC, None (full on) Control System Half duplex RS-485 (standard), Supported baud rates 9.6K, 19.2K, 57.6Kbps (factory set) Communication Protocol ROS 21-30022 10-00640 REV A... -
Page 9: Light Output
To install your new LED lamp, use the bolt pattern provided on the back of the lamp or an available ROS mounting clamp. Note that your connector configuration will have a specific wiring configuration. The wiring for your lamp will be designated on the supplied test certification, but the standard wiring configuration can be found in Section 5. -
Page 10: Connector Wiring/Configurations
6 CONNECTOR WIRING/CONFIGURATIONS NOTE: For DC Units 4 Pins are required for RS-485 Lamps and 3 Pins are required for Analog Control Lamps. NOTE: For AC Units 5 Pins are required for RS-485 and Analog Control Lamps CAUTION: Do not apply power to RS-485 pins as it will damage the RS-485 driver electronics. -
Page 11: Routine Maintenance
SS SUBCONN 7 ROUTINE MAINTENANCE The ROS Lightning is intended to be maintenance free. Be sure to clean your lamp with fresh water after each deployment. A visual inspection is always helpful in assessing the integrity of the lamp. In the event the lamp stops working, please contact ROS customer service.
