- Page 1 MV-LED II DC OPERATION AND MAINTENANCE MANUAL 5618 Copley Drive San Diego, CA 92111-7902 TEL: (858) 565-8500 FAX: (858) 565-8808 www.rosys.com 10-00609 REV D...
-
Page 2: Table Of Contents
TABLE OF CONTENTS WARRANTY ........................III CUSTOMER ASSISTANCE ................... IV CHANGE RECORD ......................1 DESCRIPTION ......................2 PRODUCT SPECIFICATIONS ................3 ................... 3 ENERAL PECIFICATIONS ..................... 4 IGHT ISTRIBUTION ................4 IGHT UTPUT VS IMMING ONTROL INSTALLATION/ GENERAL FUNCTIONALITY............5 CONNECTOR WIRING .................... -
Page 3: Warranty
The laws of the State of California shall govern this warranty. In the event the defect is determined to be within the terms of this warranty then ROS agrees to repair and/or replace (at ROS' discretion) the product or defective portion at no charge to the Purchaser. -
Page 4: Customer Assistance
CUSTOMER ASSISTANCE ROS, Inc. uses a worldwide network of stocking distributors and representatives who are familiar with our products and are able to provide assistance during installation and/or operation of these products. If you have any questions or problems with this product that are not covered by this manual or instruction, please contact our agent in your area, or contact us directly by phone or FAX or e-mail. -
Page 5: Change Record
CHANGE RECORD DESCRIPTION DATE Initial release 03FEB12 SEE EC-01134 28AUG12 SEE EC-01333 19APR13 SEE EC-02192 11FEB15 10-00609 REV D... -
Page 6: Description
DESCRIPTION The MV-LED II is a 24VDC LED spotlight designed to illuminate underwater scenes for video recording, and general underwater illumination. It is designed to run continuously underwater. The MV-LED II provides a typical light intensity 7500 Lux at one meter, a typical color temperature of 6300K, and consumes 45 watts of power (typical). -
Page 7: Product Specifications
1.8A, 48W Nominal Input Voltage Ranges 24 to 30 VDC 24VDC – RS-485 Dimming Control Modes 0-5VDC 0-10VDC Control System Half duplex RS-485 (standard), Supported baud rates 9.6K, 19.2K, 57.6Kbps (Set at Factory) Communication Protocol ROS 21-30022 10-00609 REV D... -
Page 8: Light Distribution
2.2 Light Distribution 2.3 Light Output vs. Dimming Control 10-00609 REV D... -
Page 9: Installation/ General Functionality
3 INSTALLATION/ GENERAL FUNCTIONALITY Operation of the MV-LED II requires an input voltage between 24 and 30 VDC. The lamp draws 45 Watts (typical) of power at maximum light intensity. Mount the lamp in any orientation using either the optional mounting clamp or your own mounting clamp. The MV-LED II is protected from an over temperature condition. -
Page 10: Connector Wiring
10% of the maximum light output. When the internal temperature returns to the safe operating range the light will return to full intensity. During this self regulating temperature protection the MV-LED II will not respond to commands to increase light. If the MV-LED II internal temperature reaches 63.5ºC it will reduce its intensity to 0% until the temperature returns to the safe operating range. -
Page 11: Routine Maintenance
The MV-LED II is intended to be maintenance free. Be sure to clean your lamp with fresh water after each deployment. A visual inspection is always helpful in assessing the integrity of the lamp. In the event the lamp stops working, please contact ROS customer service. For troubleshooting see Section 7. -
Page 12: Bill Of Material
7 BILL OF MATERIAL Figure 1 (MV-LED II DC) PART DESCRIPTION ROS PART NUMBER FRONT PORT RETAINER 10-00506-01 (Aluminum) 10-00606-01 (Titanium) HOUSING 10-00508-01 (Aluminum) 10-00607-01 (Titanium) DRIVER 10-00562-01 ENDBELL Connector Dependant, Contact Factory CONNECTOR See Connector Layout ENDBELL O-RING 60-20031-4... -
Page 13: Reference Documents
8 REFERENCE DOCUMENTS DOC NUMBER ROS DOCUMENT DESCRIPTION 10-00234 APPLICATION NOTE, INTERCONNECTING RS-485 COMPONENTS 10-00551 WIRING DIAGRAM, MV-LED RS485 10-00567 WIRING DIAGRAM, MV-LED DC 21-30022 RS-485 COMMUNICATION PROTOCOL 10-00609 REV D...
