- Page 1 MV-LED II AC (L200 NUCLEAR) OPERATION AND MAINTENANCE MANUAL 5618 Copley Drive San Diego, CA 92111-7902 TEL: (858) 565-8500 FAX: (858) 565-8808 www.rosys.com 10-00635 REV C...
-
Page 2: Table Of Contents
TABLE OF CONTENTS WARRANTY ........................III CUSTOMER ASSISTANCE ................... IV CHANGE RECORD ......................1 DESCRIPTION ......................2 PRODUCT SPECIFICATIONS ................3 ................... 3 ENERAL PECIFICATIONS ......................4 IGHT UTPUT INSTALLATION/ GENERAL FUNCTIONALITY............4 ROUTINE MAINTENANCE ..................5 TROUBLSHOOTING ....................5 10-00635 REV C... -
Page 3: Warranty
The laws of the State of California shall govern this warranty. In the event the defect is determined to be within the terms of this warranty then ROS agrees to repair and/or replace (at ROS' discretion) the product or defective portion at no charge to the Purchaser. -
Page 4: Customer Assistance
CUSTOMER ASSISTANCE ROS, Inc. uses a worldwide network of stocking distributors and representatives who are familiar with our products and are able to provide assistance during installation and/or operation of these products. If you have any questions or problems with this product that are not covered by this manual or instruction, please contact our agent in your area, or contact us directly by phone or FAX or e-mail. -
Page 5: Change Record
CHANGE RECORD DESCRIPTION DATE Initial release 08FEB12 SEE EC-02192 11FEB15 SEE EC-02682 15DEC16 10-00635 REV C... -
Page 6: Description
It is designed to run continuously underwater. The MV-LED II provides a typical light intensity of 2000 Lux at one meter, a typical color temperature of 6300ºK, and consumes 65 watts of power (typical). ROS has released this product in hard anodized aluminum. -
Page 7: Product Specifications
2 PRODUCT SPECIFICATIONS 2.1 General Specifications Mechanical Housing Material Hard Anodized 6061-Al Window Material Optical Grade Acrylic; TSC-3 Quartz (Nuclear Only) Mounting Options Optional Mounting Collar Weight in Air 2.5 lb (1.13kg) Weight in Salt Water 1.5 lb (.67 kg) Luminance at 1m in air 2000 Lux Thermal Protection... -
Page 8: Light Output
2.2 Light Output 3 INSTALLATION/ GENERAL FUNCTIONALITY Operation of the MV-LEDII requires an input voltage between 0 and 120 VAC. The lamp draws 65 (typical) Watts of power at maximum light intensity. Mount the lamp in any orientation using optional Mounting Collar. 10-00635 REV C... -
Page 9: Routine Maintenance
The MV-LED II is intended to be maintenance free. Be sure to clean your lamp with fresh water post dive. A visual inspection is always helpful in assessing the integrity of the lamp. In the event the lamp stops working, please contact ROS customer service. For troubleshooting see section 5.
