- Page 1 DIMMABLE SOLID STATE UNDERWATER LED LAMP Q-LED II 120VAC/160VDC OPERATING AND MAINTENANCE MANUAL SERIAL NUMBER: __________ SALES ORDER: __________ 5618 Copley Drive San Diego, CA 92111-7902 TEL: (858) 565-8500 FAX: (858) 565-8808 www.rosys.com 10-00328 REV C...
-
Page 2: Warranty
This warranty shall be governed by the laws of the State of California. In the event the defect is determined to be within the terms of this warranty, then ROS agrees to repair and/or replace (at ROS’s discretion) the product of defective portion at no charge to the Purchaser. -
Page 3: Customer Assistance
CUSTOMER ASSISTANCE ROS, Inc. uses a worldwide network of stocking distributors and representatives who are familiar with our products and are able to provide assistance during installation and/or operation of these products. If you have any questions or problems with this product that are not covered by this manual or instruction, please contact our agent in your area or contact us directly by phone or fax or E-mail. -
Page 4: Table Of Contents
TABLE OF CONTENTS WARRANTY ........................II CUSTOMER ASSISTANCE ................... III INTRODUCTION ...................... 1 GENERAL DESCRIPTION ..................2 LAMP OPERATION ....................3 POWER ......................3 TEMPERATURE PROTECTION ..............3 RECOMMENDED OPERATION ............... 3 SPECIFICATIONS ....................3 ELECTRICAL ....................3 PERFORMANCE ....................4 MECHANICAL .................... -
Page 5: Introduction
1 INTRODUCTION This manual describes the installation and operation of the ROS Model Q-LED II underwater light. This lamp utilizes a high output LED light array. This product line represents the latest generation of LED array powered models. This version of the Q- LED has the same profile than the previous model with the exception that the connector is higher on the Q-LED II. -
Page 6: General Description
The LED light engine is secured in the housing via a special assembly. The forward end of the Q-LED II is sealed with an o-ring between the housing and a deepwater-rated window. The rear side of the Q-LED II is sealed by the connector o-ring. Another o-ring seals the base to the main housing. -
Page 7: Lamp Operation
3 LAMP OPERATION 3.1 POWER Operation of the Q-LED II requires an input voltage between 0 – 120VAC 50/60Hz. The lamp draws 150 VA of power at maximum light intensity. Maximum light intensity is measured at 120 VAC. They begin to output light at 70 VAC (typical). -
Page 8: Performance
PERFORMANCE Lamp Type: Ultra High-intensity White LED Array Light Color Temperature: 5,600° K (typical) Illumination Life: 50,000 hours at 100% intensity After 50,000 hours of operation within specifications, the LED array will deliver a maximum of 70% of the original maximum output. Dimming: AC Powered - Light is dimmed via input voltage or AC phase control... - Page 9 Figure 1: Typical 120 VAC Q-LED II Normalized Light Output vs. Input Voltage Figure 2: Typical 120 VAC Q-LED II Input Current vs. Input Voltage 10-00328 REV C...
-
Page 10: Mechanical
MECHANICAL Housing Material: Anodized 6061-T6 Aluminum Housing Finish: White powder coated enamel finish Operating Depth: 4,000m (~13,000 ft), (6,000m optional) Operating Temperature: Operates in water temperatures of -2 to 40°C (28.4 to 104°F) Mounting: Four ¼ -20 tapped holes in base on 2.0 in [50.8mm] bolt circle equally spaced at 90 degrees Size (w/o connector): 7.61in [193.4mm] (H) x 2.50in [63.5mm] (W) x 2.50in... -
Page 11: Connector Wiring
6 CONNECTOR WIRING The Q-LED II can be configured with any of the 11 standard underwater connector options. Alternate customer-specified connectors and wiring standards are available, and details of these configurations are normally included in a manual addendum. Customer waiver required due... -
Page 12: Installation And Operation
Please contact the factory immediately if damage has occurred during shipping. 7.1 OPERATIONAL CHECK After unpacking your Q-LED II, a brief operational check should be made prior to installation of the unit. The following procedure is recommended: Place the light on a table with the connector up. -
Page 13: Installation
7.2 INSTALLATION The Q-LED II can be operated at any attitude. The unit should be installed by securely mounting the light housing to a stable surface. The threaded ¼- 20 tapped mounting holes are an integral feature of the Q-LED II; mounting clamps are not required. Refer to installation outline drawing (ROS P/N 10-00369) for specific installation dimensions.
