Steel 3-Pin ATV
Implement Attachment
Instructions for ATV-3PT-2140
GENERAL GUIDELINES & SAFETY
• It is the user's responsibility to read and follow all instructions.
• Keep these instructions with the product at all times and review before each use.
• It is the responsibility of this product's owner to furnish the instructions to any person that borrows
or purchases the product
• Inspect the product before use to ensure it is assembled properly and all parts are in safe working
order and free of defects
• Never modify this product in any way
• All circumstances cannot be addressed in these instructions. Please use common sense and practice
general safety measures when using this product
• Parts and/or instructions are subject to change without notice
• ALWAYS read your ATV's Owner's Manual regarding the use of after market accessories and safe
operation of your ATV
• ALWAYS make sure you wear safety gear while operating your ATV/UTV
• ALWAYS read and understand the manufacturer's WARNINGS & INSTRUCTIONS before using the
ATV/ UTV 3-Pin System
• Maintain the WARNINGS & INSTRUCTIONS for later review as needed, for instructions on usage
to anyone borrowing or using your ATV/ UTV 3-Pin System, or to pass on when selling the unit.
• Never exceed the manufacturer's weight rating of your ATV/UTV hitch. If you are unsure, always
refer to the ATV/UTV Owner's Manual
• Operating an ATV with accessories or additional implements secured to the ATV may effect the
handling of the ATV, including braking, steering, stopping and turning
• DO NOT exceed 5 MPH when operating or traveling with implements attached to your ATV
Excessive speeds can result in loss of control and can cause serious personal injuries or death
• Never operate your ATV/UTV on steep inclines while using the 3-Pin System, tipping or roll overs
can occur
• Never carry passengers on your ATV unless your ATV is designed to carry more than one person
• ALWAYS keep hands and feet away from all implements while operating the ATV
• Never get under or between any implement while operating the ATV
• ALWAYS maintain proper balance and weight distribution of you ATV, you may need to add
weight to the opposite end of the A TV to counter weight the load
091321
1-888-651-3431
Page 1
Advertisement
Table of Contents
Related Manuals for Black Widow ATV-3PT-2140
Summary of Contents for Black Widow ATV-3PT-2140
- Page 1 Steel 3-Pin ATV Implement Attachment Instructions for ATV-3PT-2140 GENERAL GUIDELINES & SAFETY • It is the user’s responsibility to read and follow all instructions. • Keep these instructions with the product at all times and review before each use. • It is the responsibility of this product’s owner to furnish the instructions to any person that borrows or purchases the product •...
- Page 2 • ALWAYS be aware of pinch to prevent injury • ALWAYS inspect all nut and bolt assemblies, hardware, and components for damaged, missing, or loose part. Inspect for any structural damage to product (return to factory for repair or discard product if any damage is found) •...
- Page 3 USE/INSTALLATION Step 1. Attach the 3-Pin System to the ATV’s 2” receiver and pin into place. Step 2. To raise and lower the 3-Pin System, work the ratchet handle #7 both ways. to change directions, flip the ratchet lock on the ratchet gear.
- Page 4 PRODUCT WARRANTY & LIABILITY GENERAL PRODUCT WARRANTY: Products purchased from the Authorized Dealer (original place of purchase) or Merchant (“Dealer”) will be free of defects in material and workmanship at the time of receipt, and will meet the specifications stated at the place of purchase transaction or online at the Dealer’s website, under normal use and service when correctly installed, operated and maintained.
