Black Widow BW-1000A Instructions

Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

General Guidelines
•
It is the user's responsibility to read and follow all instructions.
•
Keep these instructions with the product at all times and review before each use.
•
It is the responsibility of this product's owner to furnish the instructions to any person that borrows or purchases the product.
•
Inspect the product before use to ensure it is assembled properly and all parts are in safe working order and free of defects.
•
Never modify this product in any way.
•
All circumstances cannot be addressed in these instructions. Please use common sense and practice general safety mea-
sures when using this product.
•
Parts and/or instructions are subject to change without notice.
Safety
•
A qualified person should maintain the lift, keeping it in good condition. Keep it clean for best and safest performance.
The maximum load is 1000 lbs. DO NOT exceed this rated capacity.
•
•
Connect the foot-operated air valve to maximum 100psi air supply. DO NOT exceed this rated air pressure.
•
Use this lift for lifting purposes only. DO NOT use it for any other purpose it is not designed to perform.
•
Keep children and unauthorized persons away from the work area.
•
Remove loose clothing. Remove ties, watches, rings, and other loose jewelry, and contain long hair.
•
Wear ANSI approved safety goggles when operating the lift.
•
Do not mount the table when in an elevated position.
•
The foot-operated air valve should be at least 3 feet away from the air lift during raising and lowering operation.
•
Only use this lift on a surface that is stable, level, dry, and not slippery, and capable of sustaining the load. Keep the surface
clean, tidy, and free from unrelated materials and ensure that there is adequate lighting.
•
Before lifting a motorcycle, ensure the weight of the motorcycle has been fully supported by the lift platform. DO NOT put the
rear wheel of the motorcycle on the ramp and DO NOT use the ramp to support the weight of the motorcycle when
lifting. The ramp is only used to help you wheel the motorcycle onto the platform when the lift is at its lowest position.
•
DO NOT ride a vehicle onto the lift. Ensure the motorcycle is adequately secured to the lifting platform with appropriate
straps before lifting.
•
Keep the safety bar (11) in position at all times except when lowering the lift.
•
Before lowering the lift, ensure that there are no obstructions underneath and that all persons are standing clear.
•
Always keep your hands and feet away from moving parts.
•
The lift must be in the lowered position when moving. DO NOT attempt to transport a load on the lift.
•
DO NOT use the lift if damaged, any suspect parts are noted, or it has been subjected to a shock load.
•
DO NOT operate the lift when you are tired or under the influence of alcohol, drugs, or any intoxicating medication.
•
DO NOT allow untrained persons to operate the lift.
•
DO NOT make any modifications to the lift.
•
Recommended for indoor use only. DO NOT expose the lift to rain, snow, or excessive moisture.
•
If the lift needs repairing and/or there are any parts which need to be replaced, have it repaired by authorized technicians
and only use the replacement parts supplied by the manufacturer.
Rev. 120814
Instructions for
Part # BW-1000A
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BW-1000A and is the answer not in the manual?

Questions and answers

Related Manuals for Black Widow BW-1000A

Summary of Contents for Black Widow BW-1000A

  • Page 1 Instructions for Part # BW-1000A General Guidelines • It is the user’s responsibility to read and follow all instructions. • Keep these instructions with the product at all times and review before each use. • It is the responsibility of this product’s owner to furnish the instructions to any person that borrows or purchases the product.

  • Page 2: Specifications

    Specifications • Capacity: 1000 lbs (454 kg) • Width: 24” (610mm) • Length: 78-3/4” (2000mm) • Min Height: 7-1/16” (180mm) • Max Height: 32-9/32” (820mm) • Air Pressure: 90-100PSI • Air Inlet Fitting: 1/4” NPT Assembly Use the exploded drawing as your guide to assemble. Lay all parts and assemblies out in front of you before beginning.

  • Page 3: Exploded Drawing

    Exploded Drawing Rev. 120814 Page 3...

  • Page 4: Before Each Use

    Before Each Use 1. Check and make sure the four stay bolts (30) are tight. 2. Check and ensure the clevis pins (12) are secured on the safety bar. 3. Check and ensure the wheels (50) are in their tracks. Operating Instructions Warning! Loads must be centered on platform at all times.
  • Page 5 Product Warranty and Liability GENERAL PRODUCT WARRANTY: Products purchased from the Authorized Dealer (original place of purchase) or Merchant (“Dealer”) will be free of defects in material and workmanship at the time of receipt, and will meet the specifications stated at the place of purchase transaction or online at the Dealer’s website, under normal use and service when correctly installed, operated and maintained.
