1500 LBS AIR / MANUAL ATV/MOTORCYCLE LIFT
INSTALLATION MANUAL
BW-1500AO-V2
Please read this instruction manual carefully before use.
IMPORTANT
PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFETY
INSTRUCTIONS AND WARNINGS. USE THE PRODUCT CORRECTLY AND WITH
CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY
CAUSE DAMAGE TO PROPERTY AND/OR PERSONAL INJURY. PLEASE KEEP
THIS INSTRUCTION MANUAL SAFE FOR FUTURE USE.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Black Widow BW-1500AO-V2
Summary of Contents for Black Widow BW-1500AO-V2
- Page 1 1500 LBS AIR / MANUAL ATV/MOTORCYCLE LIFT INSTALLATION MANUAL BW-1500AO-V2 Please read this instruction manual carefully before use. IMPORTANT PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFETY INSTRUCTIONS AND WARNINGS. USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE TO PROPERTY AND/OR PERSONAL INJURY.
- Page 2 1. SAFETY INSTRUCTIONS AND WARNINGS 1.1 Use a qualified person to maintain the lift in good condition. Keep it clean for best and safest performance. 1.2 The maximum load is 1500lbs. DO NOT exceed this rated capacity. 1.3 Use this lift for lifting purpose only. DO NOT use it for any other purpose it is not designed to perform.
- Page 3 2. SPECIFICATIONS Capacity …………………1500Lb (680Kg) Width …………1200mm (47-1/4”) Length …………2000mm (78-3/4”) Minimum Height…………181.5mm (7-5/32”) Maximum Height…………820mm (32-9/32”) Air Pressure ………… 0.75-0.85Mpa Air Inlet Fitting…………1/4inch NPT 3. ASSEMBLY Unpack the lift and check contents with list below. Should there be any damaged or missing parts, contact your supplier immediately.
- Page 4 5. OPERATING INSTRUCTIONS WARNING! Ensure that you read, understand and apply the safety instructions and warnings before use. WARNING! Do not attempt to overload the lift. 5.1 Position the lift in a suitable area, turning the adjusting screw (25) down to make sure the lift is stable and level on the surface, checking that the surface on which the lift will stand is solid and flat (preferably concrete).
- Page 5 6. MAINTENANCE 6.1 When not in use, the lift must be stored in the lowest position in a dry location to minimize ram and piston corrosion. 6.2 Keep the lift clean and wipe off any oil or grease. Lubricate all moving parts. 6.3 Periodically check the ram and piston for signs of corrosion.
